Specifications
Max. Length of Workpiece (mm) :
1000
Range of Spindle Speed(r.p.m) :
40 - 1800 r.p.m
Machining Capacity :
Medium Duty
Type :
Horizontal
Spindle Motor Power(kW) :
1.5kw/2..4kw
Place of Origin :
Henan, China
Brand Name :
TIMAC
Model Number :
T-1440W
Voltage :
As Customers' Requirement
Dimension(L*W*H) :
1940x760x1520mm
Weight (KG) :
1200 KG
Warranty :
1 Year
Key Selling Points :
High Productivity
Marketing Type :
Ordinary Product
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
CNC or Not :
normal
Max. swing diameter over cross slide :
210mm
Max. swing diameter over gap :
508mm
Spindle bore taper :
MT5#
Machine Type :
Horizontal engine lathe
Max. Swing Diameter :
356mm
Weight :
1200kg
After-sales Service Provided :
Online support
Max. Swing Diameter (mm) :
356
Certification :
CE ISO
Condition :
New
Applicable Industries :
Hotels, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Farms, Retail, Energy & Mining
Showroom Location :
Canada, Turkey, United States, Italy, Mexico, Spain, Australia
Core Components :
Bearing, Pump, Gear, Motor, Gearbox, Engine
Max. Turned Length (mm) :
1000 mm
Spindle Bore(mm) :
40
Packaging Details :
Wooden cases(can be fumigated)
Port :
china port
Supply Ability :
500 Set/Sets per Month
Price :
$8,000.00/sets 1-2 sets
MOQ :
1 set
Description

Horizontal Engine Lathe Machine

T-1236A T-1340A T-1440A T-1340B T-1440B T-1440W

T-1440W 356mm Swing Horizontal Lathe Machine for Versatile Metal Turning Operations

Product Description

Feature:

  • Precision ground and supersonic frequency hardened bed ways.
  • The lathe machine spindle is supported with precision roller bearing;
  • Headstock gears are made of high quality steel, ground and hardened;
  • Removable gap is provided for larger diameter work;
  • Easy operating gear box has various feeds and thread cutting functionCompany Information

T-1440W 356mm Swing Horizontal Lathe Machine for Versatile Metal Turning Operations T-1440W 356mm Swing Horizontal Lathe Machine for Versatile Metal Turning Operations T-1440W 356mm Swing Horizontal Lathe Machine for Versatile Metal Turning Operations

Technical Parameter:

Specification

Unit

T-

1236A

T-1340A

T-1440A

T-1340B

T-

1440B

T-

1440W

Capacity

Center height

mm

150

165

178

150

178

178

Max.swing over bed

mm

300

330

356

300

356

356

Max.swing over cross slide

mm

180

198

224

198

220

210

Max.swing in gap

mm

430

450

476

476

506

508

Distance between centers

mm

910

1000

Spindle

Spindle nose

D4

Spindle bore

mm

38

40

Spindle bore taper

M.T.#5

Spindle speed

rpm

65-1810

(8steps)

70-2000

(8 steps)

45-1800

(16steps)

40-1800

(12steps)

Feed

Longitudinal feed range

mm/rev

0.079-1.291

0.078-1.044

0.067-1.019

0.043-0.653

Cross feed range

mm/rev

0.017-0.276

0.22-0.298

0.018-0.275

0.015-0.220

Threads

Metric threads

mm

0.4-7

0.45-10

0.45-10

0.4-7

Inch threads

T.P.I

4-60

21/4-40

31/2-80

4-112

Tailstock

Tailstock bore taper

M.T.#3

Other

Main motor

kw

1.5

1.5/2.4

Net weight/

Gross weight

kg

540/590

560/600

580/620

495/595

750/880

1200/1300

Packing dimension

mm

1680x750x1420

1940x760x1520

Standard Accessories:

  • 3 jaw chuck
  • 4 jaw chuck
  • Face plate
  • Steady rest
  • Follow rest
  • Oil gun
  • Dead center
  • Changing gears
  • Reduction sleeve
  • Chasing dial indicator
  • Working light
  • Operatoe manual

Optional accessories:

  • Coolant system
  • Foot brake system
  • Digital readout system (DRO)
  • Quick change tool post & holders
  • Taper turning attachment
