Specifications
Max. Length of Workpiece (mm) :
2000
Range of Spindle Speed(r.p.m) :
25 - 2000 r.p.m
Machining Capacity :
Light Duty
Width of bed (mm) :
300
Type :
Horizontal
Spindle Motor Power(kW) :
5.5
Place of Origin :
Henan, China
Brand Name :
TIMAC, Timeway
Model Number :
GH-1840, GH-1860, GH-1880
Voltage :
Customer's Requirement
Dimension(L*W*H) :
225*112*162cm, 280*112*156cm, 330*112*156cm
Weight (KG) :
1965 KG
Warranty :
1 Year
Key Selling Points :
Energy saving
Marketing Type :
Ordinary Product
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Processing capacity :
Light
Automatic Grade :
Semi-automatic
CNC or Not :
Normal
lathe machine :
GH1840, GH1860, GH1880
Max. Swing Diameter :
460
Weight :
1910kg, 2115kg, 2295kg
Power :
5.5KW
Certification :
CE ISO
Max. workpiece length :
1000mm
Spindle bore :
58mm
Condition :
New
Spindle Bore(mm) :
58
Showroom Location :
Egypt, United States, Italy, Brazil, Pakistan, India, Russia, South Korea, UAE, Malaysia, Australia
Applicable Industries :
Machinery Repair Shops, Manufacturing Plant, Other
Core Components :
Bearing, Pump, Gear, Motor, Other
Max. Turned Length (mm) :
2000 mm
Year :
2022
Packaging Details :
wood case (fumigated)
Port :
China port
Supply Ability :
300 Set/Sets per Month
Price :
$9,800.00/sets 1-2 sets
MOQ :
1 set
Description
Products Description
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
Features:
* Triple bearings supporting headstock spindle.
* Adjustable taper roller bearings providing spindle accuracy.
* Precision 'V'-beds & headstock gears are all hardened & ground.
* One piece cast iron base increases rigidity.
* Overload protection on drive motor and coolant system.
* Universal enclosed gearbox incorporating metric & imperial thread capabilities.
* Inching button incorporated on the control panel for convenient spindle speed
selection.
* Foot operated spindle brake with safety cut out switch.
* 300 mm wide induction hardened heavy duty cast iron bed.
* Removable gap bed allowing work piece to swing up to 690 mm.
* Chuck guard fitted with safety micro switch.
* Powered longitudinal and cross feeds.
* Adjustable 4 position length-stop mechanism for accurate repetitive operation.
* Micro adjustable saddle stop.
* Dual calibrated dials incorporating metric & imperial graduations.
* Coolant system with flexible hose enabling operator to manipulate flow direction.
* Oil sight glass for head stock and gearbox.
* Low voltage halogen work light.
* Lubrication pump on saddle oiling slides.
* D1-6 camlock spindle for quick chuck removal.
* 12 spindle speeds from 25-1600 rpm .
* spindle speeds stepless in two grades: 30-600/600-3000 rpm is optional.
* Large 58 mm spindle bore, 80 mm spindle bore is optional.
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
Specification
GH-1840
GH-1860
GH-1880
Swing over bed
460 mm(18")
Swing over cross slide
270 mm(10-3/4")
Swing in gap diameter
690 mm(27-1/8")
Distance between centers
1000 mm(40")
1500 mm(60")
2000 mm(80")
Valid length of gap
165 mm(6-1/2")
Width of bed
300 mm(11-13/16")
Spindle nose
D1-6
Spindle bore
58 mm(2-1/4")
Taper of spindle bore
No.6 Morse
Range of spindle speed
12 changes, 25~2000 r/min
Max. travel of compound rest
128 mm(5")
Max. travel of cross slide
285 mm(11-1/4")
Max. section of tool
25×25 mm(1"×1")
Pitch thread of leadscrew
6 mm or 4 T.P.I.
Longitudinal feeds range
42 kinds, 0.031-1.7 mm/rev(0.0011"-0.0633"/rev)
Cross feeds range
42 kinds, 0.014-0.784 mm/rev(0.00033"-0.01837"/rev)
Metric threads range
41 kinds, 0.1-14 mm
Inch threads range
60 kinds, 2-112 T.P.I.
Diametrical pitches range
50 kinds, 4-112 DP
Module pitches range
34 kinds, 0.1-7 MP
Dia. of tailstock sleeve
60 mm(2-5/16")
Travel of tailstock sleeve
128 mm(5")
Taper of tailstock sleeve
No.4 Morse
Power of main motor
5.5 kw(7.5HP) 3PH
Power of coolant pump
0.1 kw(1/8HP) 3PH
Overall dimension
(L×W×H)
220×108×137 cm
275×108×137 cm
325×108×137 cm
Packing size
(L×W×H)
225×112×162 cm
280×112×156 cm
330×112×156 cm
Net weight
1645 kg
1810 kg
1965 kg
Gross weight
1910 kg
2115 kg
2295 kg
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
· 3 jaw chuck
· 4 jaw chuck
· Dead center
· Face plate
· Steady rest
· Follow rest
· Reduction sleeve
· Oil gun
· Coolant system
· Working light
· Chasing dial indicator
· Quick change tool post
· 2/3 axis DRO
· Living center
· Taper turning attachment
· Chuck guard
· Leadscrew guard
· Tool post guard

GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
Why Choose Us
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
GH 1880 High Speed Precision Lathe Machine with Energy Saving in 2022
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;

Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.

Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )

Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.

Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
