Specifications
Max. Length of Workpiece (mm) :
5000
Range of Spindle Speed(r.p.m) :
3.15 - 315 r.p.m
Machining Capacity :
Heavy Duty
Type :
Horizontal
Spindle Motor Power(kW) :
30
Place of Origin :
Henan, China
Brand Name :
timeway/timac
Model Number :
AL-1600/5000
Dimension(L*W*H) :
6120*2130*2380
Weight (KG) :
20000 KG
Warranty :
1 Year
Key Selling Points :
Competitive Price
Marketing Type :
Hot Product 2022
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Name :
Heavy Duty Horizontal Lathe
Machine Type :
Horizontal Normal Lathe
Model :
AL-1600/5000
Color :
Customrized
After-sales Service Provided :
1 Year (no Human-made Reason)
Distance between centers :
3000mm
Max.swing over bed :
1600mm
Spindle speed :
3.15-315rpm
Spindle bore :
100mm
Bed width :
1100mm
Condition :
New
Spindle Bore(mm) :
100
Applicable Industries :
Building Material Shops, Manufacturing Plant, Printing Shops, Construction works , Energy & Mining
Showroom Location :
Indonesia, Sri Lanka, Japan
Core Components :
Bearing, Pump, Gear, Motor, Gearbox, Engine
Max. Turned Length (mm) :
4800 mm
Packaging Details :
Wooden cases(can be fumigated)
Supply Ability :
150 Set/Sets per Month
Price :
$58,000.00/sets 1-2 sets
MOQ :
1 set
Description
Products Description
High Precision Heavy Duty Horizontal lathe machine
4800mm Max. Turned Length Universal Horizontal Heavy Duty Lathe Machine with 5m Swing

This series horizontal lathe is suitable for processing large sized parts of castings, steels and non-ferrous metals. It can turn outer circle, inner hole, end face, grooving, drilling, boring and nesting, and can turn various internal and external threads, such as metric, inch,modulus and diametrical.
Product Paramenters
Specifications
Unit
AL-1600
Swing over bed
mm
1600
Swing over carriage
mm
1250
Max. length of workpiece
mm
3000/4000/5000/6000/8000/10000/12000
Max. turning length
mm
2800/3800/4800/5800/7800/9800/11800
Span of guideway
mm
1100
Max. weight of workpiece
t
16
Spindle nose
-
A2-15
Spindle bore
mm
100
Taper hole of spindle
-
metric 140
Range of spindle speeds
r/min
foreward: 3.15-315, reversal: 3.5-291
No. of spindle speeds
steps
foreward: 21, reversal: 12
Longitudinal and cross
kinds
56
Feed per revolution
mm/r
long longitudinal:0.1-12, cross:0.05-6, top tool-post：0.025-3
No. and range of metric thread
mm
1-120 (44)
No. and range of inch thread
TPI
28-1/4 (31)
No. and range of module thread
MP
0.5-60 (45)
No. and range of dia. thread
DP
1/2-56 (38)
Distance of spindle and tool plane
mm
53
Tool post swing range
°
±90
Max. travel of cross slide
mm
850
Max. travel of top slide
mm
360
Section of tool shank
mm
50x50
Travel of tool post (per turn of dials)
mm
0.05
Dia. of tailstock quill
mm
260
Travel of tailstock quill
mm
300
Taper hole of tailstock quill
-
Metric 80
Main motor power
kw
30
Length
mm
6120/7120/8120/9120/11120/13120/15120
Width
mm
2130
Height
mm
2380
Details of Accessories:
Standard accessories:
* 4-jaw heavy duty independent chuck
* Steady rest
* Dead center
* 4-station tool post
* Cooling system
* Work lamp
* Electric moving tailstock
* Tools & tool-box
* Leveling wedge and bolts
* Operation manual (English)
Optional accessories:
* Face plate
* 2 or 3-axis DRO
* Chuck guard
* Tool-post guard
* Rear splash guard
* Roller support
* Grinding attachment
Company Introduction
4800mm Max. Turned Length Universal Horizontal Heavy Duty Lathe Machine with 5m Swing
Factory Display：
4800mm Max. Turned Length Universal Horizontal Heavy Duty Lathe Machine with 5m Swing
Factory Profile：
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
Text Introduction：
4800mm Max. Turned Length Universal Horizontal Heavy Duty Lathe Machine with 5m Swing
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
