Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Specifications
Brand Name :
THLB
Model Number :
51.2V60Ah LiFePO4 Battery
Place of Origin :
China
MOQ :
2 pieces
Price :
$600/pieces 2-19 pieces
Max Load Quantity(cells) :
4
Cycle Life :
1200 cycles
Application :
Boats, Electric Wheelchairs, Solar Energy Storage Systems, Golf Carts, Electric Power Systems, Electric Bicycles/Scooters
Operating Temperature(℃) :
-20-60
Cathode Materials :
LiFePO4
Type :
LiFePO4
Voltage :
51.2v
Capacity :
60Ah
Category :
Rechargeable Batteries pack
Cycle Characteristic :
1500-2000 times
Working Temperature :
-20°C~60°C
Battery Weight :
46.3±0.1 kg
PCM :
YES
Size :
560x345x240mm
Packaging Details :
Standard Packaging
Delivery Time :
7-15 Working Days
Description
Max Load Quantity 4 Rechargeable Batteries Pack 51.2V 60Ah LiFePO4 Golf Cart Battery Pack Lithium Ion Rechargeable Battery
Product Parameters
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
MAIN KIT INCLUDES
1x 51.2V60Ah LiFePO4 Battery Module
1x 16S-70A PCM
1x Metal casing
PRODUCT SPECIFICATION
Nominal voltage
51.2V
Normal Capacity
60±2Ah( At 0.2C discharge rate)
Max discharge continuous current
≤60A
Discharge cut-off voltage
About 40V
Charge voltage
57.6±1V
Charge current

≤60A
Charge mode
CC/CV,please use special lithium charger
Discharging Inner resistance
≤50mΩ
Charge temperature
0℃～+45℃
Discharge temperature
When the environment temperature is higher than 45℃,please pay attention to ventilation and heat rejection.
humidity
RH≤85%, When the environment humidity is higher than 85%,please pay attention to protect
temperature
0℃～40℃(Capacity 80%)Recommended long-term storage temperature is 15~25℃
humidity
RH≤50%,Easily oxidized components note sealed
Protection function
Over charge protection,Over discharge protection,Temperature protection,Balanced function
Shell material
Metal
Weight
46.3±0.3kg
Size(L*W*H)
(560±1)mm *(345±1)mm *(240±2)mm
Cycle
Standard charge at 0.2C(A), rest 0.5~1 h,discharge at 0.2C to cut off voltage,rest 0.5~1h,repeat the above steps until 1500
cycles.( capacity retention rate≥80%)
Individual Cell Approval
CE / RoHS / UN38.3 / UL 1642 / IEC 62133 / CB / KC / BIS
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Our Company
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Packing & Delivery
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
Rechargeable Lithium Golf Cart Battery Pack THLB 1200 Cycles 51.2V 60Ah
FAQ

Q1. Can I have few free samples for evaluation?
A: Yes, free samples are ok, but not covering shipping cost

Q2. What about the lead time?
A: Samples needs 3-5 days
B: Mass production time is approx 2-3 weeks

Q3. Do you have any MOQ limit for bulk order?
A: MOQ=100pcs

Q4. How do you ship the goods and how long does it take to arrive?
A: Samples and small quantity trial order: Courier shipping with door to door; normally 6-10 days
B: Big quantity bulk order: Air shipping or Sea shipping

Q5. How to proceed an order for Lithium ion cell?

A: Pls confirm the cell models that you are interested in
B: We send cell specifications and best quotation to you for reference
C: You confirm the quotation and inform quantity or issue PO, we will send PI accordingly
D: After deposit or full payment confirmed, production started

Q6. Is it OK to print my logo on lithium ion cell product?
A: Yes. OEM is welcomed

Q7: Do you offer guarantee for the products?
A: Yes, 3-5 Years Warranty
