26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
Specifications
Brand Name :
THLB
Model Number :
26650-3600mAh-3.2V
Place of Origin :
China
MOQ :
100 pieces
Price :
$2.03/pieces 100-9999 pieces
Application :
Toys, Power Tools, Home Appliances, Consumer Electronics, Boats, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems
Weight :
94g
Type :
26650 LiFePO4 Lithium Battery Cell
Voltage :
3.2V
Capacity :
3600 mAh
Max. Continuous Discharge Current :
3C
Charge Voltage :
3.65V
Charge Current :
0.5C
Charge Mode :
CC, CV
Charge voltage :
0~45degree
Discharge voltage :
-20~60 degree
size :
26.3x65.2mm
Anode Material :
LFP
Battery Size :
26650-3600mAh-3.2V
The charging ratio :
0.5C, 1C
The discharge rate :
1C, 2C, 3C
Storage Type :
Normal
Electric Energy :
11.52 Wh
Packaging Details :
Standard Packaging
Delivery Time :
7-15 Working Days
Description
26.3x65.2mm Lithium Ion Rechargeable Battery THLB 3.2V 26500 3600mAh Normal Storage Type Flat Top
Product Parameters
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
No.
Item
Standard
Note
1
Standard Capacity
3600mAh
0.5C,( current value of 4500mA at 1C)
2
Min Capacity Range
3500mAh
0.5C
3
Standard Voltage
3.2 V
4
Alternating Internal Resistance
≤18mΩ
5
Charge Conditions
Cut-off Voltage
3.65±0.05V
constant-current charge to 3.6V at 0.5C,constant voltage charge to stop until 0.01C mA
Cut-off Current
0.01C
6
Max. Charging Current
3.6A
7
Discharge Cut-off Voltage
2.0V
8
Standard Discharge Current
3.6A
9
Fast Discharge Current
1.8A
10
Max. Continuous Discharge Current
10.8A
11
Pulse Discharge Current
15A,5s
12
Cycle Characteristic
1500times(100%DOD)
the residual capacity is no less than 80% of
rated capacity at 1C rate.
2500 times(80%DOD)
4000 times(50%DOD)
13
Working Temperature
Charge:0°C~45°C
Discharge:-20°C~60°C
14
Storage Temperature
-20°C ~ 45°C
Short-term storage (< 3 months)
15
Battery Weight
91g (Approx.)
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
Our Company
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
Packing & Delivery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
26500 3600mAh THLB Battery 3.2V Normal Storage 0.5C Flat Top Battery
FAQ

Q1. Can I have few free samples for evaluation?

A: Yes, free samples are ok, but not covering shipping cost

Q2. What about the lead time?

A: Samples needs 3-5 days

B: Mass production time is approx 2-3 weeks

Q3. Do you have any MOQ limit for bulk order?

A: MOQ=100pcs

Q4. How do you ship the goods and how long does it take to arrive?

A: Samples and small quantity trial order: Courier shipping with door to door; normally 6-10 days

B: Big quantity bulk order: Air shipping or Sea shipping

Q5. How to proceed an order for Lithium ion cell?

A: Pls confirm the cell models that you are interested in

B: We send cell specifications and best quotation to you for reference

C: You confirm the quotation and inform quantity or issue PO, we will send PI accordingly

D: After deposit or full payment confirmed, production started

Q6. Is it OK to print my logo on lithium ion cell product?

A: Yes. OEM is welcomed

Q7: Do you offer guarantee for the products?

A: Yes, 3-5 Years Warranty
