Computerized Tricot Warp Knitting Machine Raschel Jacquard Machine E18 E22
Computerized Tricot Warp Knitting Machine Raschel Jacquard Machine E18 E22
Computerized Tricot Warp Knitting Machine Raschel Jacquard Machine E18 E22
Computerized Tricot Warp Knitting Machine Raschel Jacquard Machine E18 E22
Computerized Tricot Warp Knitting Machine Raschel Jacquard Machine E18 E22
Computerized Tricot Warp Knitting Machine Raschel Jacquard Machine E18 E22
Computerized Tricot Warp Knitting Machine Raschel Jacquard Machine E18 E22
Computerized Tricot Warp Knitting Machine Raschel Jacquard Machine E18 E22
Computerized Tricot Warp Knitting Machine Raschel Jacquard Machine E18 E22
Computerized Tricot Warp Knitting Machine Raschel Jacquard Machine E18 E22
Computerized Tricot Warp Knitting Machine Raschel Jacquard Machine E18 E22
Computerized Tricot Warp Knitting Machine Raschel Jacquard Machine E18 E22
Specifications
Place of Origin :
China
Price :
$24,000.00/sets 1-1 sets
Certification :
CE
MOQ :
1 set
Delivery Time :
30 days
Brand Name :
ZYTT
Applicable Industries :
Manufacturing Plant
Condition :
New
Product Type :
sheet Blanket
Type :
Terry
Production Capacity :
100%
Power :
4 W
Knitting Style :
Warp
Knitting Method :
Double
Computerized :
Yes
Weight :
8500 KG
Dimension(L*W*H) :
5530x6900x3300
Warranty :
1 Year
Key Selling Points :
High-accuracy
Gauge :
12 GG, 16 GG, 18GG, 16GG, E16 E18 E22
Knitting width :
90inch 138inch. ..
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Marketing Type :
Ordinary Product
Warranty of core components :
1 Year
Core Components :
Motor
Speed :
800RPM
Number of bars :
5 bars
Working width :
90" 100" 100" 110" 138"
Application :
Fabric
Control system :
Electronic Computerized System
Motor :
Servo Motor
Product :
blanket
Local Service Location :
India
After sales Service Provided :
Video technical support
Port :
shanghai
Description
Jacquard Mesh Tricot Raschel Warp Knitting Machine
Computerized Tricot Warp Knitting Machine Raschel Jacquard Machine E18 E22
Computerized Tricot Warp Knitting Machine Raschel Jacquard Machine E18 E22

Computerized Tricot Warp Knitting Machine Raschel Jacquard Machine E18 E22

Application:

The machine are mainly used to produce long plush fabric, high quality mat, garment, plush toy, artificial fur and blanket etc.

Features:

Adopting the oil-soaking conjugate cam, Disc CAM make up flowers. roller active let-off, laser stop, EBA let-off, the machine have the advantages of high-speed and stable-running. Pile height is 5-60mm.

Main Specification:

Working Needle: Individual Latch Needle

Guage: E16, E18, E22, E24

Number of guide bars: 5 guage bars(4 groud bars, 1 terry bar)

The distance between knock-over bar: 10-120mm
