Automatic Rotary Screen Printing Machine Textile Printing Machine 100m Min
Automatic Rotary Screen Printing Machine Textile Printing Machine 100m Min
Automatic Rotary Screen Printing Machine Textile Printing Machine 100m Min
Automatic Rotary Screen Printing Machine Textile Printing Machine 100m Min
Automatic Rotary Screen Printing Machine Textile Printing Machine 100m Min
Automatic Rotary Screen Printing Machine Textile Printing Machine 100m Min
Automatic Rotary Screen Printing Machine Textile Printing Machine 100m Min
Automatic Rotary Screen Printing Machine Textile Printing Machine 100m Min
Automatic Rotary Screen Printing Machine Textile Printing Machine 100m Min
Automatic Rotary Screen Printing Machine Textile Printing Machine 100m Min
Automatic Rotary Screen Printing Machine Textile Printing Machine 100m Min
Automatic Rotary Screen Printing Machine Textile Printing Machine 100m Min
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
DGE
Certification :
CE
Packaging Details :
wooden case
Supply Ability :
100 Set/Sets per Year
Price :
$385,000.00/pieces 1-1 pieces
MOQ :
1 set
Delivery Time :
30 days
Plate Type :
Screen Printer
Applicable Industries :
Garment Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Advertising Company, BLANKET PLANT
Usage :
Cloths Printer, Fabric pinter
Automatic Grade :
Automatic
Color & Page :
Multicolor
Voltage :
380v
Dimensions(L*W*H) :
10500*1800*1720mm
Weight :
30000 KG
Warranty :
1 Year
After-sales Service Provided :
Online support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support
Key Selling Points :
High-accuracy
Warranty of core components :
1 Year
Core Components :
Motor, PLC, Engine, INVERTOR
Printing type: :
magnetic ,squeegee cmbination
colors :
6/9/12/16
Product appearance :
knitting,woven fabric prcessing
Printing speed :
100m/min
Application :
Textiles
Keywords :
Rotary printing
After Warranty Service 1 :
Video technical support,Spare parts
Description
Textile rotary printing machine
Machine Specification & Advantages
Nominal width(cm)
180 / 200 / 220 / 240 / 260 / 280 / 300 / 320 / 340 / 360
Number of printing sets
4 / 6 / 8 / 10 / 12 / 14 / 16 sets
Effective printing width (mm)
1620,1850,2050,2250,2450,2650,3050,3250,3450
repeat size
577mm, 640mm, 820mm, 914mm, 1018mm
Alignment accuracy
± 0.1mm
Process speed
4 m / min ~ 100 m / min
Scraping mode
magnetic rod / scraper
Transmission mode
the guide belt adopts German Lenz servo deceleration integrated transmission; The printing unit is independently driven bySchneider servo motor; Other transmission parts are synchronously driven by Japan's Yaskawa AC variable frequency motor.
Installed capacity
165 kW (12 color sets, 4 drying rooms)
Automatic Rotary Screen Printing Machine Textile Printing Machine 100m Min

Advantage 1

The variety has wide printability, with a gram weight range of 60-600g / ㎡, woven, knitted, flannelette and blanket The latest tenth generation of automatic flower alignment system, the lifting speed does not run flowers The overall modular design, scraper and magnetic rod are combined arbitrarily, and the process arrangement is flexible Open chuck structure, convenient and fast network change
Automatic Rotary Screen Printing Machine Textile Printing Machine 100m Min
Automatic Rotary Screen Printing Machine Textile Printing Machine 100m Min

Advantage 2

Special printing magnetic table, magnetic rod pressure stepless adjustment, uniform coloring and strong permeability The printing unit is electrically lifted and lowered as a whole, and the friction plate is changed, which is easy to clean and maintain The guide belt drive has no deviation correction roller, and the unique design ensures smooth operation without deviation German integrated guide belt drive motor reducer, high precision, maintenance free and long service life
