Polyester Polyamide Mother Yarn Warping Machine 750 M Min
Polyester Polyamide Mother Yarn Warping Machine 750 M Min
Polyester Polyamide Mother Yarn Warping Machine 750 M Min
Polyester Polyamide Mother Yarn Warping Machine 750 M Min
Polyester Polyamide Mother Yarn Warping Machine 750 M Min
Polyester Polyamide Mother Yarn Warping Machine 750 M Min
Polyester Polyamide Mother Yarn Warping Machine 750 M Min
Polyester Polyamide Mother Yarn Warping Machine 750 M Min
Polyester Polyamide Mother Yarn Warping Machine 750 M Min
Polyester Polyamide Mother Yarn Warping Machine 750 M Min
Polyester Polyamide Mother Yarn Warping Machine 750 M Min
Polyester Polyamide Mother Yarn Warping Machine 750 M Min
Specifications
Place of Origin :
China
Packaging Details :
Wooden package
Supply Ability :
100 Set/Sets per Month
Price :
$25,000.00/sets 1-1 sets
Brand Name :
ZYTT
Certification :
CE
MOQ :
1 set
Delivery Time :
30 days
Model Number :
358
Applicable Industries :
Manufacturing Plant
Showroom Location :
India
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
New Product 2022
Warranty of core components :
1 Year
Core Components :
PLC, Motor
Condition :
New
Production Capacity :
98%
PowerMain motor :
7.5KW AC frequency conversion control
Warranty :
1 Year
Key Selling Points :
High-accuracy
Machine type :
Warping Machine
After Warranty Service :
Video technical support
Local Service Location :
India
Model :
358
Port :
shanghai
Description
ZYTT-358 Mother Yarn Warping Machine
Product Introduction
358 Mother yarn warping machine is suitable yarn such as polyester polyamide etc. The mother yarn is made of a number of monofilament The advantages of this machine can save material cost, workroom space e and improve production efficiency.
This machine is mainly composed by creel, yarn guider back drawing rollers, tension roller, split yarn collection board, front drawing roller and warper head.
Each strand of mother yarn is tensioned by a torque motor to get an initial tension, the back drawing rollers draws the mother yarn from the creel to the yarn collection board through several tension rollers. The yarn is split from the collection board; the front drawing rollers draw the monofilament to the beam.
Machine Specification & Advantages
Warper beam size21" x Ф30" (inch ),21"x Ф21"(inch)
Warper capacityat customer's opinion.
Warp liner speed50-750(m/min).
Leveling rollertwo sets of servo (or inverter) control with three-roller positively.
Main motor7.5KW AC frequency conversion control
Control modecomputer real-time control, touch screen and
man-computer interface.

Product Features
1. Advanced model , intelligently distinguish human-computer interface, all date is saved automatically.
2. Speed tracking servo control and automatic control detection mechanism.
3. Computer real-time testing, intelligently control tension.
4. Load and unload beams pneumatically driving, go up and down straightly, move stable and fix accurately.
5. Main shaft is driven pneumatically so braking is fast and stable
6. Warping Tension is same similar, wave is small and the beam is smooth.
