Specifications
Brand Name :
YUHONG
Model Number :
SA213 TP304L Stainless Steel Tube
Certification :
ISO 9001/TUV/PED
Place of Origin :
China
MOQ :
300 KGS
Price :
Negotiable
Payment Terms :
T/T, L/C AT SIGHT
Supply Ability :
1000 TONS / month
Delivery Time :
Depends on order quantity
Packaging Details :
Wooden case / Steel frame wooden case with plastic cap
Standard :
ASTM A213 / ASME SA213
Material :
TP304L (UNS S30403) – low carbon for better weldability
Finish :
Bright annealed (BA), ultra-smooth internal and external surfaces
Advantages :
Superior corrosion resistance, High dimensional accuracy
Description

SA213 TP304L Austenitic Stainless Steel Tube, Cold-Drawn And Bright Annealed, Ideal For Heat Exchangers/Condensers

Overview of Bright Annealed A213 TP304L Stainless Steel Seamless Tube

Bright Annealed A213 TP304L seamless tubes are high-quality, austenitic stainless steel tubes manufactured to ASTM A213 specifications. Made from TP304L, a low-carbon variant of 304 stainless steel, these tubes are cold-drawn and bright annealed in a controlled atmosphere to achieve a smooth, reflective, oxide-free surface finish.

The bright annealing process enhances corrosion resistance, cleanliness, and dimensional precision, making these tubes ideal for heat exchangers, condensers, instrumentation lines, and high-purity applications in industries like pharmaceuticals, food processing, and petrochemicals.

Advantages of A213 TP304L BA Tube:

  • Superior corrosion resistance

  • High dimensional accuracy

  • Hygienic and easy to clean

  • Suitable for high-temperature service

Technical Parameters and Specifications

Parameter Category Range/Requirement
Outer Diameter 3.175mm~42mm (1/8"~1.5")
Wall Thickness 0.45mm~3.0mm (Tolerance ±10%)
Length 3m/6m (fixed-length), customizable
Pressure Capacity 80~180 MPa
Applicable Standards ASTM A213/A269, ASME BPE, JIS G3459, etc.

Chemical Composition of SS304L (UNS S30403)

Element

Content (%)

Carbon (C)

≤ 0.035

Manganese (Mn)

≤ 2.00

Phosphorus (P)

≤ 0.045

Sulfur (S)

≤ 0.030

Silicon (Si)

≤ 1.00

Chromium (Cr)

18.0 – 20.0

Nickel (Ni)

8.0 – 12.0

Nitrogen (N)

≤ 0.10

Iron (Fe)

Balance

Mechanical Properties of SS304L (UNS S30403)

Property

Value

Tensile Strength (min)

485 MPa (70 ksi)

Yield Strength (min)

170 MPa (25 ksi)

Elongation (min)

35%

Hardness (max)

90 HRB (Rockwell B)

Modulus of Elasticity

~193 GPa (28 × 10⁶ psi)

Density

8.0 g/cm³

Melting Point

~1400–1450 °C (2550–2640 °F)

Typical Applications

  • Heat exchangers and condensers
  • Food, beverage, and pharmaceutical piping
  • Instrumentation and control tubing
  • Ultra-high-purity gas and fluid transfer systems
