Specifications
Brand Name :
YUHONG
Model Number :
ASTM B111 C44300 Tube
Certification :
ISO 9001/TUV/PED
Place of Origin :
China
MOQ :
300 KGS
Price :
Negotiable
Payment Terms :
T/T, L/C AT SIGHT
Supply Ability :
1000 TONS / month
Delivery Time :
Depends on order quantity
Packaging Details :
Wooden box with plastic cap
Product Name :
Admiralty Brass seamless Tube
Standard :
ASTM B111/ASME SB111
Material grade :
C44300 / CZ111 / C106 / CuZn28Sn1As (2.0470)
Temper Designation :
O61 Annealed
Description

Admiralty Brass Seamless Tube ASTM B111 C44300, Widely Used In Condenser And Heat Exchanger

Overview of C44300 Tube

ASTM B111 C44300 refers to seamless tubes made from Admiralty Brass, a copper-zinc-tin alloy known for its excellent corrosion resistance, especially in marine and industrial heat exchanger applications. C44300 contains about 70% copper, 28% zinc, and 1% tin, with a small amount of arsenic to prevent dezincification.

These tubes are widely used in condenser and heat exchanger systems, particularly in freshwater and brackish water environments, due to their high thermal conductivity, good strength, and resistance to biofouling and erosion.

Manufactured according to ASTM B111, the tubes are typically supplied in annealed (O61) or light-drawn tempers, making them suitable for tube expansion, bending, and fabrication.

C44300 Admiralty Brass Tube – Overview

UNS Designation

C44300
Common Name Admiralty Brass
Standards ASTM B111 (for seamless condenser and heat exchanger tubes)
Composition ~70% Copper, ~28% Zinc, ~1% Tin, small amounts of Iron
Form Seamless tube (most common), rolled, drawn

Chemical Composition (%) (Typical Range per ASTM B111)

Element

Percentage (%)

Copper (Cu)

70.0 – 73.0

Zinc (Zn)

Remainder (~27–29)

Tin (Sn)

0.9 – 1.2

Iron (Fe)

0.06 max

Lead (Pb)

0.07 max

Mechanical Properties (Annealed Condition)

Property

Value (Typical)

Tensile Strength

310 – 450 MPa

Yield Strength (0.5% ext.)

~125 MPa

Elongation (in 50 mm)

≥ 30%

Hardness

~65 HRB

Key Features of ASTM B111 C44300 tubes

  • Excellent corrosion resistance in fresh, salt, and brackish water.

  • Tin addition improves resistance to dezincification.

  • Good thermal conductivity.

  • Non-sparking, non-magnetic.

  • Easily fabricated, soldered, and brazed.

Applications of ASTM B111 C44300 tubes

  • Heat exchangers

  • Condenser tubes (especially in steam power plants)

  • Seawater cooling systems

  • Desalination units

  • Evaporators
