Specifications
Brand Name :
YUHONG
Model Number :
ASME SA179 A179
Certification :
ISO 9001/TUV/PED
Place of Origin :
China
MOQ :
500 KGS
Price :
Negotiable
Payment Terms :
T/T, L/C at sight
Supply Ability :
1000 TONS / month
Delivery Time :
Depends on order quantity
Packaging Details :
Steel frame wooden case with plastic cap
Standard :
ASME SA179
Material Grade :
A179
Form :
Seamless Tube
Diameter :
3.18-152.4mm
Wall Thickness :
0.41mm - 25.4mm
Applications :
Boilers, heat exchangers, superheaters, HRSG
Description
ASME SA179 A179 Carbon Steel Seamless Tube Heat Exchangers For Oil Refineries, Condensers For Chemical Plants, Power Plants
The ASME SA179 / ASTM A179 seamless tube is a globally recognized standard for cold-drawn low-carbon steel tubes, specifically designed for use in shell-and-tube heat exchangers, condensers, and similar heat transfer equipment. It is one of the most widely specified materials in the power generation, petrochemical, HVAC, and marine industries due to its excellent thermal conductivity, good formability, and reliable mechanical properties.
Typical applications include heat exchanger tubes, condenser tubes, oil coolers, intercoolers, and feedwater heaters. The material’s excellent thermal conductivity (approximately 51.9 W/m·K) is about 40% higher than that of austenitic stainless steels, making it highly efficient for heat transfer. Additionally, SA179 tubes can be readily welded, bent, and flared, simplifying fabrication and reducing overall project costs.

Chemical Composition
Element Composition (wt%)
Carbon (C) 0.06 – 0.18
Manganese (Mn) 0.27 – 0.63
Phosphorus (P) ≤ 0.035
Sulfur (S) ≤ 0.035
Silicon (Si) ≤ 0.25

Mechanical Properties
Property Requirement (min.)
Tensile Strength ≥ 325 MPa (47 ksi)
Yield Strength (0.5% extension under load) ≥ 180 MPa (26 ksi)
Elongation (in 2 in / 50 mm) ≥ 35%
Hardness (Rockwell B) ≤ 72 HRB

Application:

  • Power Industry: Power plant condensers, low-pressure feedwater heaters, coolers
  • Petrochemical Industry: Refinery heat exchangers, chemical plant condensers, gas coolers
  • HVAC: Refrigeration unit evaporators, condensers, cooling coils
  • Shipbuilding: Marine heat exchangers, diesel engine coolers, seawater cooling systems
  • General Industry: Air compressor aftercoolers, hydraulic oil coolers, process air coolers

ASME SA179 A179 Carbon Steel Seamless Tube Heat Exchangers For Oil Refineries, Condensers For Chemical Plants, Power Plants
