Product Profile: The Economically Durable Floating Head Design
This floating head heat exchanger is specifically configured for processes where the tube-side and shell-side fluids present drastically different corrosivity. Its defining feature is the use of a bimetallic tubesheet, marrying the structural economy of SA350 LF2 forged carbon steel with the localized corrosion resistance of a bonded 316L stainless steel layer. Coupled with a full 316L stainless steel tube bundle, it targets longevity where it matters most.

Structural Breakdown & Specification

Engineering Insight: The Economic Logic of Clad Construction
In process design, material cost often scales non-linearly with alloy performance. A solid 316L tubesheet for a large exchanger is prohibitively expensive. The clad solution applies a minimum thickness (typically 3-10mm) of the corrosion-resistant alloy only to the face and bore holes, where contact with the aggressive tube-side fluid occurs. The backing material (SA350 LF2) provides the necessary mechanical strength at a lower cost. This is not a compromise, but a smart, ASME-codified engineering practice for optimizing capital expenditure (CAPEX) without sacrificing critical service life.

Operational Benefits & Project Value

• CAPEX Optimization: Achieves the corrosion performance of high-grade alloys for the wetted surface while significantly reducing material costs compared to solid alloy construction.

• Lifecycle Integrity: The metallurgically bonded clad interface ensures long-term integrity, superior to weld overlays in withstanding thermal cycling and mechanical stress.

• Unmatched Serviceability: The floating head design permits complete bundle extraction, enabling inspection, cleaning, or repair of both the 316L tubes and the clad tubesheet face without cutting piping on the stationary end.

• Ideal Application Scope: Specifically engineered for offshore seawater cooling (tube-side) with sweet cooling media on shell-side, chemical processes with one highly corrosive stream, or any application with a pronounced corrosion asymmetry between sides.
