ZTE ZXDU88 S402 (V6.0) system is a DC power supply system with large capacity, consisting of multiple racks and providing –48 VDC for switching equipment, data products etc.
ZXD5000 rectifiers are installed in the rectifier rack (RECR), It uses advanced switching rectifier technology, with rated input three-phase AC 380VAC, and rated output power is 6kW. The rectifier peak efficiency is higher than 96.2%.
Features of Rectifier ZXD5000 Module:
High efficiency, saving more power
The peak efficiency of the module is higher than 96.2%,and in the sleep mode, the rectifier output power consumption is lower than 4W.
High power density, saving space and rental
The power density of the rectifier is 25.52W/in3 to save space, helping form a large-capacity power system up to 120kW in one rack.
High compatibility with Powerful expansion capacity
The full output is 360kW and the max configuration of ZXDU88 S402 system consists of four DC distribution racks, three rectifier racks and four AC distribution racks.
Digital design, high Reliability
Rectifier adopts DSP+MCU double digital circuit control and the system adopts CAN+RS485 double bus control. So the system is more reliable and the transmission speed is faster.
Specification
Type | Telecom Power |
|
Model Number | ZXD5000 V6.0 |
|
Place of Origin | China |
|
Brand Name | ZTE |
|
Use | Telecom |
|
input | 380v 50/60hz |
|
dcouput | 53.5v 6000w |
|
weight | 6kg |
|














Solutions
We provide a full spectrum of solutions for telecommunication firms, whether they are based in China or have a global presence. Our services encompass site surveys, the development of professional plans that are customized to customer requests, technical support, and maintenance services. With a talented team and a worldwide network of trusted partners, we offer a unique blend of expertise and reliability.
FAQ :
-
-
- Q: What information comes with the product samples?
A: Along with the sample, you'll receive a detailed product breakdown. This includes a bill of materials listing every component and its origin, a performance data sheet with test results from our in - house labs, and a user manual highlighting all the features and functions. You'll also get access to our online support portal, where you can find additional technical resources and troubleshooting guides.
- Q: How are quality issues traced back to product components?
A: We use a combination of barcode tracking and component - level serialization. When a quality issue arises, our team can quickly identify the specific batch of raw materials, the production line it passed through, and even the individual components involved. This detailed traceability enables us to pinpoint the root cause and implement targeted improvements.
- Q: What makes your products truly 100% original?
A: Each product is accompanied by a certificate of authenticity, which verifies the origin of all components. We have strict anti - counterfeiting measures in place, including holographic labels and unique product identifiers that can be scanned to access detailed product history. Additionally, our products are manufactured in - house, ensuring complete control over the production process.
- Q: What does the one - year warranty cover in terms of product parts?
A: The warranty covers all internal and external components of the product. This includes circuit boards, motors, sensors, and any software - related features. If any of these parts fail due to manufacturing defects within the warranty period, we'll repair or replace them free of charge, ensuring your product remains fully functional.
- Q: How are defective products inspected to identify the root cause?
A: Defective products are sent to our advanced diagnostic lab. Here, technicians use microscopic imaging to check for component - level defects, run electrical impedance tests to detect wiring issues, and perform software debugging to identify any coding glitches. Once the root cause is determined, we use this information to prevent similar problems in future production runs.
