Specifications
Brand Name :
CE+T
Model Number :
Bravo 25 - 48/230-277
Place of Origin :
China
Price :
Inquiry
Payment Terms :
T/T
Supply Ability :
500 sets per month
Delivery Time :
6-8 weeks
Packaging Details :
Wooden cartons
Module :
T621D30201
Dielectric strength DC/AC :
4300 Vdc
Operating T° :
-20°C to 65°C
Storage T° :
-40°C to 70°C
Voltage range :
150 - 293 Vac
Brownout :
1600 W
Power factor :
> 0.99
Nominal Output power :
3 kVA / 2.4 kW @ 230 Vac
Description
Inverter Single Phase Standard System BRAVO 25 48/230 1PH 12KVA Base Unit
Product Overview
The BRAVO 25 - 48/230-277 is a compact and scalable modular inverter delivering pure sine wave AC output. This system provides exceptional AC backup solutions when integrated with DC power systems, utilizing cutting-edge technology for maximum energy efficiency in a compact form factor.
Advanced Technology Features
ECI technology eliminates all single points of failure with full scalability, supporting up to 32 modules in parallel. Achieves high efficiency up to 96% in AC to AC conversion and above 93.7% in DC/AC conversion, significantly reducing operating costs. Systems can be built up to 1.35 MVA capacity.
Inview Monitoring & Control
Our advanced Inview monitoring solution features comprehensive monitoring capabilities to enhance customer experience. Includes advanced scripting tools for customized infrastructure adaptation and control features including comprehensive battery management systems.
Applications
Ideal for all business-critical applications and various AC load types. Modular, scalable design with hot-swappable inverter modules ensures low Mean Time to Repair (MTTR), reduced service costs, and accommodates future expansion requirements.
Key Features
  • Extra AC input for increased efficiency in double conversion operations
  • Wide AC input range up to 293 Vac L-N
  • Up to 12 kVA capacity in 2RU - 19-inch form factor
  • Scalable up to 1.35 MVA using additional synchronization devices
  • Compatible with 1P or 3P infrastructure configurations
  • Full compatibility with Inview S, X and GW monitoring systems
Technical Specifications
