Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705
Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705
Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705
Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705
Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705
Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705
Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705
Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705
Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705
Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705
Specifications
Brand Name :
Eltek
Model Number :
241115.705
Certification :
CE
Place of Origin :
CN
MOQ :
1 piece
Price :
1 USD
Payment Terms :
L/C,T/T
Supply Ability :
3000 pieces per month
Delivery Time :
8-10 weeks
Packaging Details :
cartons
Part No. :
241115.705
BrandA :
Eltek
Model Name :
Flatpack2 48-60V/2000HE
Effciency :
96.5%
Input AC voltage :
80 - 300 VDC
Input DC voltage :
85 - 305 VAC
Output power :
39,9 - 72 VDC
Output Current :
41,7 ADC
Weight :
2 kg
Description
Eltek Rectifier Module Flatpack2 48V-60V 2000W HE
Part No. 241115.705
Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705
Reliable High Efficiency Rectifier
The Flatpack2 48V-60V/2000W HE is a cost-efficient rectifier designed for 48V and 60V lead acid battery systems as well as 48V NiCad applications.
Key Features
  • High efficiency - 96.2%
  • Proven reliability
  • High power density
  • Application flexibility - 2kW to multicabinet installations
  • Modular design - MTTR and LT5mins
  • Accepts DC input (DC/DC converter)
  • Global compliance (CE, UL, NEBS)
  • Marine and offshore certifications
  • Patented technology
Technical Specifications
Model48-60/2000 HE
Part Number241115.705
INPUT DATA
Voltage (nominal)185 - 275 VAC / 185 - 275 VDC
Voltage (operating range)85 - 300 VAC / 80 - 300 VDC
Current (maximum) @ nominal input, full load11.6 ARMS
Frequency45 - 66 Hz / 0 Hz
Power Factor> 0.99 at 50% load or more
THD< 5% at 100% load
ProtectionFuse in L & N, Varistor, Shutdown when input voltage is out of operating range
OUTPUT DATA
Voltage (default)53.5 VDC (67 VDC in 60V mode)
Voltage (adjustable range)39.9 - 72 VDC
Power (maximum) @ nominal input2000 W (@VOUT ≥ 48VDC)
Power @ 85 VAC750 W
Current (maximum) @ nominal input41.6 A (@VOUT < 48VDC)
Hold up time, 1500W output power>20ms; output voltage > 53.5 VDC (60V mode)
Current sharing (10 - 100% load)±5% of maximum current from 10 to 100% load
Static Voltage regulation (10 - 100% load)±0.5%
Dynamic Voltage regulation±5.0% for 10-80% or 80-10% load variation, regulation time < 50ms
Ripple & noise< 150 mVPP , 30 MHz bandwidth / < 2 mVRMS psophometric
ProtectionFuse, Short circuit proof, High temperature protection, Over voltage Shutdown
OTHER SPECIFICATIONS
Efficiency96.2%
Isolation3.0 kVAC - input to output, 1.5 kVAC - input to earth, 500 VDC - output to earth
Operating temperature-40 to +75°C [-40 to +167°F] (5-95% RH non-condensing humidity)
Max output power de-rates above tempto 45°C [113°F] / 1200W @ 75°C[167°F]
Storage temperature-40 to +85°C (-40 to +185°F), humidity 0 - 99% RH non-condensing
Dimensions [WxHxD] / Weight109 x 41.5 x 327mm (4.25 x 1.69 x 13") / 1.950 kg (4.3lbs)
MTBF>350,000 hours (@ Tambient: 25°C)
Design Standards
Electrical safety: EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013, IEC 60950-1:2013 UL 60950-1:2011
EMC: EN 61000-6-1:2007, -6-2:2005, -6-3:2007 + A1:2011, -6-4:2007 + A1:2011, IEC 61000-6-5: 2015, ETSI EN 300 386:2.1.1
Marine: DNVGL-CG-0339
Environment: 2011/65/EU (RoHS) & 2012/19/EU (WEEE)
Product Images
Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705 Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705 Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705 Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705 Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705 Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705 Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705 Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705 Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705 Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705 Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705 Eltek Rectifier Module Flatpack2 48V-60V 2000W HE Part No.241115.705
Comprehensive Telecom Solutions
Our solutions are designed to meet the diverse needs of telecommunication companies worldwide. We conduct detailed site surveys, create professional cost-effective plans aligned with business objectives, and provide 24/7 technical support and maintenance services to ensure smooth telecom network functioning.
Frequently Asked Questions
Can I get product samples and their corresponding prices?
You can obtain samples. The cost of samples is based on the regular price, and you'll be responsible for covering the shipping charges.
How do you resolve quality-related problems?
With over 10 years of industry experience, we value our reputation highly. When a quality problem arises, we conduct detailed investigations and honor our contracts to resolve issues. Our service team provides excellent support.
How reliable is the quality of your products?
Our products are 100% authentic, brand new, and originally packaged. Each product is meticulously tested before shipping to meet stringent quality benchmarks.
For how long is the product guaranteed?
Our products come with a 1-year warranty, during which we address any quality problems related to manufacturing defects.
What's the process for handling defective products?
During the warranty period, if you find any product quality problems, we cover the cost of returning and replacing substandard items.
