P10 Outdoor LED Billboard with 6000nit Brightness Magnetic Front Service and 3840Hz Refresh Rate for Quick Maintenance
P10 Outdoor LED Billboard with 6000nit Brightness Magnetic Front Service and 3840Hz Refresh Rate for Quick Maintenance
P10 Outdoor LED Billboard with 6000nit Brightness Magnetic Front Service and 3840Hz Refresh Rate for Quick Maintenance
P10 Outdoor LED Billboard with 6000nit Brightness Magnetic Front Service and 3840Hz Refresh Rate for Quick Maintenance
P10 Outdoor LED Billboard with 6000nit Brightness Magnetic Front Service and 3840Hz Refresh Rate for Quick Maintenance
P10 Outdoor LED Billboard with 6000nit Brightness Magnetic Front Service and 3840Hz Refresh Rate for Quick Maintenance
Specifications
Brand Name :
TBC LED
Delivery Time :
15-25 days
Power Consumption :
950/330 w/sqm
Panel Size :
1000x1000x83mm
Pixel Configuration :
SMD2727
Price :
USD 3000-5000 / Piece
Brightness :
>=6000nit
Refresh Rate :
3840Hz
Protection Level :
IP65
Lifetime :
>=100,000 hours
Viewing Angle :
140°/140°
Panel Material :
Aluminum
Working Temperature :
-40~70°C
Place of Origin :
China
Certification :
CCC, CE, RoHS, FCC, CB, TUV, IEC, BIS
Pixel Matrix per sq.m :
10000
Panel Weight :
22.5Kg
Model Number :
T Series P10-MAG
Module Design :
Magnetic Front Service
MOQ :
1 Piece
Gray Scale :
65536 levels (16 bit)
Payment Terms :
T/T,L/C,PayPal,Western Union
Packaging Details :
Flight case with foam protection, export-grade wooden crate
Pixel Pitch :
P10mm
Supply Ability :
1000 Pieces per Month
Input Voltage :
AC110/240V
Description
P10 Outdoor LED Billboard Magnetic Front Service Module 6000nit Brightness 3840Hz Refresh IP65 for Quick Maintenance
1000×1000×83mm outdoor LED billboard featuring magnetic front service modules for tool-free, rapid on-site maintenance. The P10 pixel pitch with 6000nit brightness delivers clear visibility under direct sunlight.
Key Features
  • Magnetic Front Service Module: Magnetic module design enables tool-free, quick front access for fast on-site maintenance and reduced downtime.
  • 6000nit High Brightness: Ultra-high brightness keeps content vivid and readable even under direct sunlight.
  • IP65 Waterproof Protection: Full weatherproof design protects against rain, dust and harsh outdoor conditions.
  • 3840Hz Flicker-Free Refresh: High refresh rate removes scan lines for broadcast-ready image quality.
  • Efficient Heat Dissipation: Superior thermal design keeps the display stable during long-hour high-brightness operation.
  • 100,000 Hours Lifetime: Durable construction supports long-term outdoor operation with low maintenance.
Technical Specifications
Pixel Pitch P10mm
Brightness ≥6000nit
Pixel Configuration SMD2727
Gray Scale 65536 levels per color (16 bit)
Refresh Rate 3840Hz
Pixel Matrix per sq.m 10000
Viewing Angle 140°/140° (H/V)
Power Consumption (Max/Avg) 950 / 330 w/sqm
Protection Level IP65
Input Voltage AC110/240V
Panel Size (W x H x D) 1000 x 1000 x 83mm
Model Size (W x H) 500 x 250mm
Panel Material Aluminum
Panel Weight 22.5Kg
Module Design Magnetic Front Service
Working/Storage Temperature -40°C to 70°C / -55°C to 120°C
Lifetime ≥100,000 hours
Certifications CCC, CE, RoHS, FCC, CB, TUV, IEC, BIS
Warranty 2 Years

P10 Outdoor LED Billboard with 6000nit Brightness Magnetic Front Service and 3840Hz Refresh Rate for Quick Maintenance

P10 Outdoor LED Billboard with 6000nit Brightness Magnetic Front Service and 3840Hz Refresh Rate for Quick Maintenance

P10 Outdoor LED Billboard with 6000nit Brightness Magnetic Front Service and 3840Hz Refresh Rate for Quick Maintenance

Application Scenarios
  • Commercial Squares & Shopping Malls
  • Traffic Guidance & City Signage
  • Sports Venues & Large-Scale Events
  • Building Facades & Rooftop Advertising
  • Roadside & Highway Billboards
