QJP Series Hydraulic Motor Air Capstan Winch 80ml/rev 20 ft/min
QJP Series Hydraulic Motor Air Capstan Winch 80ml/rev 20 ft/min
QJP Series Hydraulic Motor Air Capstan Winch 80ml/rev 20 ft/min
QJP Series Hydraulic Motor Air Capstan Winch 80ml/rev 20 ft/min
QJP Series Hydraulic Motor Air Capstan Winch 80ml/rev 20 ft/min
QJP Series Hydraulic Motor Air Capstan Winch 80ml/rev 20 ft/min
Specifications
Brand Name :
Juling
Model Number :
As Specified in the data
Certification :
API,ISO
Place of Origin :
China
MOQ :
1
Price :
negotiable
Payment Terms :
T/T
Delivery Time :
Stock
Packaging Details :
Wooden Box
Line Speed :
20 ft/min
Gear Ratio :
3:1
Drum Capacity :
24 m
Wire Rope Diameter :
∅8mm
Color :
Yellow Orange or other Colors
Motor Displacement :
80ml/rev
Size :
390*190*340 mm
Net Weight :
260Kg
Cable Length :
50 ft
Power :
HYDRAULIC MOTOR
Drum Size :
2.5" x 5.5
Materials :
steel
Warranty :
12 Months
Usage :
Lifting in Oilfield
Certifications :
CE, ISO
Safety Features :
Emergency Stop Button, Overload Protection
Description

Product Details.

The QJP series air capstan is a new type of pneumatic machinery product, specifically designed for ships, docks, and other relevant application scenarios and environments. Driven by an air motor, it transmits power to the drum.


NUMBERING METHOD

QJP Series Hydraulic Motor Air Capstan Winch 80ml/rev 20 ft/min

① QJP:pneumatic capstan

② Max lifting force in first layer:*10kN ；

③ Max speed:m/min

TECHNICAL PARAMETER

Product Model

QJP-0.5*15

QJP-3*15

QJP-5*15

Maximum Tractive Effort(kN)

5

30

50

Maximum Rope Speed(m/min)

15

15

5-15

Rated Power(kW)

2.6

11

16

Rated Intake Pressure

0.8

0.8

0.8

Rated Air Consumption(m3/min)

≤5

≤11

≤18

Weight(kg)

200

350

500
