Electric Winch with 153 1 Gear Ratio and 0.5ton-100ton Lift Capacity
Electric Winch with 153 1 Gear Ratio and 0.5ton-100ton Lift Capacity
Electric Winch with 153 1 Gear Ratio and 0.5ton-100ton Lift Capacity
Electric Winch with 153 1 Gear Ratio and 0.5ton-100ton Lift Capacity
Electric Winch with 153 1 Gear Ratio and 0.5ton-100ton Lift Capacity
Electric Winch with 153 1 Gear Ratio and 0.5ton-100ton Lift Capacity
Specifications
Brand Name :
Juling
Model Number :
DJFY
Place Of Origin :
China
Remote Control :
Included
Max Force lb :
1125-13500
Mounting Type :
Universal
Maximum Lifting Height :
As Your Requires
Engine :
Electric Engine 220V
Customized Support :
OEM
Gear Ratio :
153:1
Structure :
Electric System
Description

Product Description:

The Electric Winch by Juling Winch is a top-of-the-line product designed to provide safe and reliable work in various lifting applications. With a gear ratio of 153:1, this winch is capable of handling heavy loads efficiently and effectively. Weighing only 25 Lbs, it is lightweight yet sturdy, making it easy to transport and install.

Item

Specification parameter

Model

DJFY-5*16

DJFY-20*8

DJFY-30*20

DJFY-50*19/10

DJFY-60*2

Ambient temperature

-25℃∽40℃

Specification of lubricating oil

GL-5,80w-90. Freezing point -60

Max Force lb

1125

4500

6750

11250

13500

Max speed ft/s

0.88

0.44

1.1

1.1/0.55

0.11

Rated power H.P

2

5.4

14.7

24.8/14.7

5.4

Rope capacity ft

130

260

390

390

165

Wire rope diameter in

0.24

0.55

0.63

0.75

0.787

Overall dimension:

L*W*H(in)

27.6*11*13

49*23.5*24

46*30*24

57.5*32*26.6

53*32*26


Packing and Shipping:

Product Packaging and Shipping for Electric Winch:

The Electric Winch is carefully packaged to ensure safe delivery to your door. It is securely enclosed in a sturdy cardboard box with ample padding to prevent any damage during transit.

Shipping Details:

- Shipping Method: Standard Ground Shipping

- Delivery Time: 3-5 business days

- Shipping Cost: $20


FAQ:

Q: What is the brand name of this Electric Winch?

A: The brand name of this Electric Winch is Juling.

Q: What is the model number of this Electric Winch?

A: The model number of this Electric Winch is DJFY.

Q: Where is this Electric Winch manufactured?

A: This Electric Winch is manufactured in China.

Q: What is the weight capacity of this Electric Winch?

A: The weight capacity of this Electric Winch is X pounds.

Q: Does this Electric Winch come with a warranty?

A: Yes, this Electric Winch comes with a X-year warranty.
