Rida Combo 4G+GPS Antenna for Vehicle application
Rida Combo 4G+GPS Antenna for Vehicle application
Rida Combo 4G+GPS Antenna for Vehicle application
Rida Combo 4G+GPS Antenna for Vehicle application
Rida Combo 4G+GPS Antenna for Vehicle application
Rida Combo 4G+GPS Antenna for Vehicle application
Rida Combo 4G+GPS Antenna for Vehicle application
Rida Combo 4G+GPS Antenna for Vehicle application
Rida Combo 4G+GPS Antenna for Vehicle application
Rida Combo 4G+GPS Antenna for Vehicle application
Rida Combo 4G+GPS Antenna for Vehicle application
Rida Combo 4G+GPS Antenna for Vehicle application
Specifications
Supply Ability :
400000pcs per month
Connectivity :
as requirement
Brand Name :
RIDA Antennaer
VSWR :
<1.5
LNA Gain :
28dBi
Impedance :
50Ω
MOQ :
20
Place of Origin :
Guangdong, China
Frequency :
GPS GLONASS BEIDOU 4G 5G WIFI
Cable Length :
3M(Customizable)
Model Number :
RG00110B
Packaging Details :
opp bag single pcs
Polarity :
vertical
Service :
OEM/ODM
Delivery Time :
10-15days
Material :
PC
Certification :
ISO9001/IATF16949
Type :
GPS/GNSS Antenna
Description
Products Description
Rida Combo 4G+GPS Antenna for Vehicle application
Rida Combo 4G+GPS Antenna for Vehicle application
Rida Combo 4G+GPS Antenna for Vehicle application

Waterproof, corrosion and high temperature resistance tests, comprehensive quality inspection reports. Ensure the normal use of the product in various environments.
(For more test reports, please contact)

Product Parameters
GNSS specifications

Center Frequency *
1575.42MHz±3 MHz / 1561MHz / 1602MHz
V.S.W.R
<1.5
Band Width
±5 MHz
Attenuation
fo±100MHz>30dB
Impendence
50 Ω
Peak Gain
>3dBic, Based on 7×7cm ground plane
Gain Coverage
>-4dBic at –90°<0<+90°(over 75% Volume)
Polarization
Right-handed Circular(RHCP)
LNA Gain(Without cable) *
28dBi
Noise Figure
1.5dB
V.S.W.R
<1.65
DC Voltage
2.7V-5.0V±0.5V
DC current
15mA Max(5V DC)
2G/3G/4G/5G specifications

Frequency Range *
600-6000MHz
V.S.W.R
<1.5
Band Width
±90/280 MHz
Gain *
3.0dBi
Polarization
Vertical
Radiation
Omni directional
Max Input power(W)
50 W
Impendence
50 Ω
2.4/5.8Ghz WIFI specifications

Frequency Range *
2300-2500/5700-5900MHZ
V.S.W.R
<1.5
Band Width
±100 MHz
Gain *
3.0dBi
Polarization
Vertical
Radiation
Omni directional
Max Input power(W)
50 W
Impendence
50 Ω
