Specifications
VSWR :
<1.5
Mounting Method :
Adhesive or Magnet
Model Number :
RG00110B
Packaging Details :
opp bag single pcs
Gain :
30±2dB
Service :
OEM/ODM
Place of Origin :
Guangdong, China
Brand Name :
RIDA Antennaer
Supply Ability :
400000pcs per month
Material :
ceramic and plastic
Connector :
Fakra/SMA/or customized
Impedance :
50Ω
Cable Length :
3 Meters(Customizable)
datasheet :
Provided
Delivery Time :
10-15days
Frequency Range :
1575.42MHz & 1561MHz & 1602MHz
MOQ :
3
Certification :
ISO9001/IATF16949
Type :
GPS/GNSS Antenna
Description
Overview
This is a GPS/GNSS antenna designed for intelligent telematics vehicle equipment. The antenna's can be customized combination function can be customized based on actual needs, enabling the equipment to provide data acquisition, remote control, security services, and other functionalities.

Options
-Antenna performance : -Connector : 1. GPS GNSS single/multi-band 1. SMA male/female 2. 3G/4G(MIMO)/5G/WIFI/BT 2. Fakra(purple/yellow/green/blue/others) 3. 433/868/915Mhz 3. Others -Wire length : -Mounting Methods : 1. 3m (default) 1. Adhesive (default) 2. Others 2. Magnetic


Rida GPS/GNSS antenna manufacturer for Car Radio Vehicle Multimedia Player

Rida GPS/GNSS antenna manufacturer for Car Radio Vehicle Multimedia Player

Rida GPS/GNSS antenna manufacturer for Car Radio Vehicle Multimedia Player

Rida GPS/GNSS antenna manufacturer for Car Radio Vehicle Multimedia Player


Product Parameters & Customizable Range

GPS
Center Frequency
1575.42MHz±3 MHz
V.S.W.R
<1.5
Band Width
±5 MHz
Attenuation
fo±100MHz>30dB
Impendence
50 Ω
Peak Gain
>3dBic, Based on 7×7cm ground plane
Gain Coverage
>-4dBic at –90°<0<+90°(over 75% Volume)
Polarization
Right-handed Circular(RHCP)
GPS LNA Specifications
LNA Gain(Without cable)
28dBi
Noise Figure
1.5dB
V.S.W.R
<1.65
DC Voltage
2.7V-5.0V±0.5V
DC current
15mA Max(5V DC)
LTE Specifications
Frequency Range
698-2700MHz
V.S.W.R
<1.5
Band Width
±90/280 MHz
Gain
3.0dBi
Polarization
Vertical
Radiation
Omni directional
Max Input power(W)
50 W
Impendence
50 Ω
WIFI specifications
Frequency Range
2300-2500MHZ/5700-5900MHZ
V.S.W.R
1.5:1
Band Width
±100 MHz
Gain
2-3dBi
Polarization
Vertical
Radiation
Omni directional
Max Input power(W)
50 W
Impendence
50 Ω
