CE ASTM Standard PP 400g Nonwoven Geotextile Weak Foundation Reinforcement For Highway Expressway Projects
CE ASTM Standard PP 400g Nonwoven Geotextile Weak Foundation Reinforcement For Highway Expressway Projects
CE ASTM Standard PP 400g Nonwoven Geotextile Weak Foundation Reinforcement For Highway Expressway Projects
CE ASTM Standard PP 400g Nonwoven Geotextile Weak Foundation Reinforcement For Highway Expressway Projects
Specifications
Brand Name :
SZ
Model Number :
SZGT
Certification :
CE,ISO
Place of Origin :
CHINA
MOQ :
100000 Sqaure Meter
Price :
$0.3-$2.0/SQM
Payment Terms :
L/C,T/T
Supply Ability :
20000 Square meter per day
Delivery Time :
5 -8 days
Packaging Details :
By roll, paper pipe + black PE shrinkage membrane + woven bag ( waterproof & UV resistance)
Product Name :
CE ASTM Standard PP 400g Nonwoven Geotextile
Application :
Highway Express Projects
Function :
Weak Foundation Reinforcement
Geotextile Type :
Non Woven
Color :
White or Black
Material :
PP(polypropylene) PET (polyester)
Weight :
400g/sqm
Thickness :
0.5-2.5 mm
Width :
1-6 m
Length :
50-100 m
Description

CE ASTM Standard PP 400g Nonwoven Geotextile Weak Foundation Reinforcement For Highway Express Projects



Why Choose Yixing Shenzhou 400g PP Nonwoven Geotextile?


Manufactured to International Standards:

Compliant with ASTM, ISO, and EN standards


Consistent Quality Control:

Rigorous testing ensures batch-to-batch consistency


Custom Sizes Available:

Standard roll sizes plus custom widths/lengths to suit project needs


Technical Support:

Expert advice on product selection and installation


Competitive Pricing:

High-performance solution at cost-effective rates



Certifications & Compliance:


Our 400g PP nonwoven geotextile meets or exceeds the following standards:

ISO 9001:2015 Quality Management System

CE Marking for construction products

ASTM D6241 Standard Specification for Nonwoven Geotextiles

EN 13249 Geotextiles for roads and paved areas



Key Features & Benefits


  1. Premium Polypropylene Material: Manufactured from 100% virgin polypropylene fibers, our geotextile offers excellent chemical resistance (resistant to acids, alkalis, and solvents), mildew-proof properties, and long-term durability in harsh environments

  2. Optimal Weight & Thickness: At 400 grams per square meter (gsm), this heavyweight fabric provides superior strength and performance for demanding applications

  3. Exceptional Filtration: The nonwoven structure allows for excellent water permeability while preventing soil particle migration

  4. UV Stabilized: Specially treated to resist degradation from sunlight exposure for extended outdoor use

  5. High Tensile Strength: Engineered to withstand significant mechanical stresses during installation and throughout service life


CE ASTM Standard PP 400g Nonwoven Geotextile Weak Foundation Reinforcement For Highway Expressway Projects

CE ASTM Standard PP 400g Nonwoven Geotextile Weak Foundation Reinforcement For Highway Expressway Projects


400g Polypropylene Non Woven Geotextile Application & Function :


  1. Road & Railway Construction:
    Separation layer between subgrade and aggregate base
    Reinforcement for weak subsoils
    Prevention of intermixing between soil layers
  2. Drainage Systems:
    Filtration layer in drainage applications
    Protection for geomembranes
    Landfill leachate collection systems
  3. Erosion Control:
    Slope stabilization
    Riverbank and coastal protection
    Land reclamation projects
  4. Other Applications:
    Foundation reinforcement
    Retaining wall backfill
    Pond and canal lining protection



CE ASTM Standard PP 400g Nonwoven Geotextile Weak Foundation Reinforcement For Highway Expressway Projects

Staple fibers needle punched non woven geotextile Parameters

No.

Item

Parameters

Nominal strength(kN/m)

7

9

11

15

19

22

25

28

34

40

45

1

Breaking strength≥(kN/m)

7

9

11

15

19

22

25

28

34

40

45

2

Elongation at break(%)

40——100

3

Tearing strength≥(kN)

0.21

0.25

0.31

0.40

0.50

0.58

0.67

0.75

0.85

1.00

1.30

4

CBR puncture resistance ≥(kN)

1.1

1.4

1.7

2.3

2.90

3.3

3.8

4.2

5.4

6.2

7.8

5

Strong Grip≥(kN)

0.4

0.5

0.6

0.8

1.0

1.25

1.5

1.7

2.15

2.8

3.7

6

Thickness≥(mm)

1.0

1.2

1.5

1.9

2.2

2.6

3.0

3.3

4.0

4.5

6.0

7

Equivalent Pore size O90( O95)(mm)

0.07-0.3

8

Vertical permeability coefficient(cm/s)

1.0×(100—10-2)

9

Anti-ultraviolet intensity retention rate≥(%)

80%

10

Unit Weight≥(g/m2)

100

125

150

200

250

300

350

400

500

600

800

11

Unit Weight Tolerance(%)

±5

±4

±3

12

Width Tolerance(%)

±0.05



Yixing Shenzhou 400g Polypropylene Non Woven Geotextile Installation Guide:


Site Preparation:

Clear area of debris, sharp objects, and vegetation


Roll Placement:

Unroll geotextile with machine direction (MD) parallel to anticipated stress direction


Overlap Requirements:

Minimum 300mm side laps and 500mm end laps


Anchoring:

Secure edges with staples or backfill immediately
Cover Material Placement: Place fill material carefully to avoid damage


If you have more question ,welcome to contact with Yixing Shenzhou !!!
