High Pesrmeability 300g PP Nonwoven Geotextile Drainage Fabric Road Pavement Separates subsoil aggregate layers
High Pesrmeability 300g PP Nonwoven Geotextile Drainage Fabric Road Pavement Separates subsoil aggregate layers
High Pesrmeability 300g PP Nonwoven Geotextile Drainage Fabric Road Pavement Separates subsoil aggregate layers
High Pesrmeability 300g PP Nonwoven Geotextile Drainage Fabric Road Pavement Separates subsoil aggregate layers
Specifications
Brand Name :
SZ
Model Number :
SZGT
Certification :
CE,ISO
Place of Origin :
CHINA
MOQ :
100000 Sqaure Meter
Price :
$0.3-$2.0/SQM
Payment Terms :
L/C,T/T
Supply Ability :
20000 Square meter per day
Delivery Time :
5 -8 days
Packaging Details :
By roll, paper pipe + black PE shrinkage membrane + woven bag ( waterproof & UV resistance)
Product Name :
High Pesrmeability 300g PP Nonwoven Geotextile
Application :
Road Pavement
Function :
Drainage Fabric Separates subsoil aggregate layers
Geotextile Type :
Non Woven
Color :
White or Black
Material :
PP(polypropylene) PET (polyester)
Weight :
300g/sqm
Thickness :
0.5-2.5 mm
Width :
1-6 m
Length :
50-100 m
Description

High Pesrmeability 300g PP Nonwoven Geotextile Drainage Fabric Road Pavement Separates subsoil aggregate layers



Drainage PP Nonwoven Geotextile Applications :


  • French Drains / Subsurface Drainage: Prevents soil migration while allowing water to flow into perforated pipes.

  • Landfill Leachate Systems: Filters contaminants while maintaining drainage.

  • Retaining Wall Drainage: Reduces water pressure behind walls.

  • Road & Pavement Drainage: Separates subsoil from aggregate layers.

  • Erosion Control: Used in slopes and ditches to manage water flow.

Advantages Over Other Geotextiles:

  • Better Clog Resistance compared to woven geotextiles.

  • Higher Flow Rates due to random fiber arrangement.

  • Cost-Effective for filtration and separation roles.




Drainage PP Nonwoven Geotextile Advantages Over Other Geotextiles:


  • Better Clog Resistance compared to woven geotextiles.

  • Higher Flow Rates due to random fiber arrangement.

  • Cost-Effective for filtration and separation roles.



Certifications & Compliance:

Our 300g PP nonwoven geotextile meets or exceeds the following standards:

  • ISO 9001:2015 Quality Management System
  • CE Marking for construction products
  • ASTM D6241 Standard Specification for Nonwoven Geotextiles
  • EN 13249 Geotextiles for roads and paved areas




High Pesrmeability 300g PP Nonwoven Geotextile Drainage Fabric Road Pavement Separates subsoil aggregate layers

High Pesrmeability 300g PP Nonwoven Geotextile Drainage Fabric Road Pavement Separates subsoil aggregate layers


300g Polypropylene Non Woven Geotextile Application & Function :


  1. Road & Railway Construction:
    Separation layer between subgrade and aggregate base
    Reinforcement for weak subsoils
    Prevention of intermixing between soil layers
  2. Drainage Systems:
    Filtration layer in drainage applications
    Protection for geomembranes
    Landfill leachate collection systems
  3. Erosion Control:
    Slope stabilization
    Riverbank and coastal protection
    Land reclamation projects
  4. Other Applications:
    Foundation reinforcement
    Retaining wall backfill
    Pond and canal lining protection



High Pesrmeability 300g PP Nonwoven Geotextile Drainage Fabric Road Pavement Separates subsoil aggregate layers

Staple fibers needle punched non woven geotextile Parameters

No.

Item

Parameters

Nominal strength(kN/m)

7

9

11

15

19

22

25

28

34

40

45

1

Breaking strength≥(kN/m)

7

9

11

15

19

22

25

28

34

40

45

2

Elongation at break(%)

40——100

3

Tearing strength≥(kN)

0.21

0.25

0.31

0.40

0.50

0.58

0.67

0.75

0.85

1.00

1.30

4

CBR puncture resistance ≥(kN)

1.1

1.4

1.7

2.3

2.90

3.3

3.8

4.2

5.4

6.2

7.8

5

Strong Grip≥(kN)

0.4

0.5

0.6

0.8

1.0

1.25

1.5

1.7

2.15

2.8

3.7

6

Thickness≥(mm)

1.0

1.2

1.5

1.9

2.2

2.6

3.0

3.3

4.0

4.5

6.0

7

Equivalent Pore size O90( O95)(mm)

0.07-0.3

8

Vertical permeability coefficient(cm/s)

1.0×(100—10-2)

9

Anti-ultraviolet intensity retention rate≥(%)

80%

10

Unit Weight≥(g/m2)

100

125

150

200

250

300

350

400

500

600

800

11

Unit Weight Tolerance(%)

±5

±4

±3

12

Width Tolerance(%)

±0.05



Yixing Shenzhou 300g Polypropylene Non Woven Geotextile Installation Guide:


Site Preparation:

Clear area of debris, sharp objects, and vegetation


Roll Placement:

Unroll geotextile with machine direction (MD) parallel to anticipated stress direction


Overlap Requirements:

Minimum 300mm side laps and 500mm end laps


Anchoring:

Secure edges with staples or backfill immediately
Cover Material Placement: Place fill material carefully to avoid damage


If you have more question ,welcome to contact with Yixing Shenzhou !!!
