Agricultural Machinery Automated Powder Coating Line
Agricultural Machinery Automated Powder Coating Line
Specifications
Brand Name :
Hongshun
Model Number :
HS-AS660CPP
Certification :
CCC/CE
Place of Origin :
Dongguan
MOQ :
1 set
Price :
$50000-100000/Set
Payment Terms :
L/C,T/T
Supply Ability :
5 sets/month
Delivery Time :
50 days
Packaging Details :
film
Workpiece name :
Agricultural Machinery Parts
Maximum workpiece size can be used :
L800*W600*H800mm maximum product size
conveying speed :
4-5min
Control the power :
Single phase AC220V-50Hz single phase + ground wire
Drive Power :
Three-phase AC380V-50Hz three-phase five-wire system
Description

Agricultural Machinery Automated Powder Coating Line


Automated Powder Coating Line Overview:

The Agricultural Machinery Automated Powder Coating Line is engineered to deliver durable, high-performance finishes for agricultural equipment, combining efficiency with rugged protection. This fully automated system streamlines the coating process—from pre-treatment to curing—ensuring uniform, adhesion-strong powder application across diverse machinery components, including frames, gears, and housings.


Designed to withstand harsh agricultural environments, the coating resists corrosion, UV damage, and abrasion from dirt, chemicals, and heavy use, extending equipment lifespan. The automated workflow minimizes manual intervention, ensuring consistent quality across high-volume production while reducing waste and operational costs.


Ideal for tractors, harvesters, and farm implements, this line adapts to varying component sizes and geometries. By merging robust protection with efficient automation, it empowers agricultural machinery manufacturers to enhance product durability and market appeal, meeting the demands of tough farming conditions.


Process flow of Automated Powder Coating Line For Reference:

Loading⇒ Spray pre-degreasing and residue removal⇒main degreasing by swimming + ultrasonic + heating cleaning ⇒ Spray water washing (I) ⇒ Spray water washing (II) ⇒ Activation by swimming ⇒ spray washing (3) ⇒ spray washing (4), swim lay type passivation, spray washing (5) ⇒ spray washing (6) ⇒ pure water cleaning + adjustable automatic blow water, drop of water, dehydration drying furnace, natural cooling, online roast ⇒ under a belt anti-pull installation baked ⇒ on a PP board make automatic coating powder spraying cabinet⇒ hurricane recovery Powder supply center ⇒ Secondary recovery system ⇒ Grinding cabinet ⇒ Curing oven drying ⇒ Natural cooling⇒ QC inspection ⇒ Unloading ⇒ Packaging


Time of each pretreatment process of Automated Powder Coating Line:

project

Spray pre-oil removal

Swimming type main oil removal

Spray washing 1

Spray washing 2

time

1.5min

4-5min

1.5min

1.5min

project

The swimming style main activated

Spray washing 3

Spray washing 4

Swimming type passivation

time

4-5min

1.5min

1.5min

4-5min

project

Spray washing 5

Spray washing 6

Pure water wash

time

1.5min

1.5min

1.5min




Our typical customers:

Agricultural Machinery Automated Powder Coating LineAgricultural Machinery Automated Powder Coating LineAgricultural Machinery Automated Powder Coating Line



To meet your company's technical requirements while addressing the diverse and comprehensive needs of the coating industry, our design integrates technologies from multiple leading domestic spray painting manufacturers. The system incorporates versatile equipment configurations and operational efficiency considerations, featuring fully automated material handling and intelligent control systems. These innovations streamline maintenance and management processes, reduce labor requirements, expand workspace capacity, enhance production productivity, and minimize potential workpiece damage during processing.
