SA240 317L / 516 Gr.70 Square Cladded Plate for Reactors 28sqm Max. Size
SA240 317L / 516 Gr.70 Square Cladded Plate for Reactors 28sqm Max. Size
Specifications
Brand Name :
Suntech
Model Number :
E0030
Certification :
EN10204 3.1, EN10204 3.2, DNV, TUV, SGS, etc
Place of Origin :
P.R.China
MOQ :
1 piece
Price :
negotiation
Payment Terms :
L/C, D/A, T/T, D/P, etc
Supply Ability :
35000tons/Year
Delivery Time :
60 working days after received your payment
Packaging Details :
Seaworthy packing
Cladding Material :
SA240 317L
Base Material :
SA516 Gr.70
Size :
(3+28)*3300*5000mm
Max. Size :
28sqm
Production Code :
ASTM B264, ASME SB264
Inner Surface Treatment :
Auto Polished
Description

SA240 317L / 516 Gr.70 Square Cladded Plate for Reactors 28sqm Max. Size

Detailed Product Description:

Explosion Bonded / Bimetallic / Cladded Plate / Super stainless steel clad

Flying Layer: SA240 317L

Base Layer: SA516 Gr.70

Size: (3+28)*3300*5000mm

Packing: seaworthy packing

Product advantage:

-Clad plates provide an economical solution for chemical processing;

-Stainless steel surface contains sufficient chromium to form a passive film of chromium oxide, preventing further surface corrosion by blocking oxygen diffusion to the steel surface and blocks corrosion from spreading into the metal's internal structure;

- Technical consulting on material, thickness suggestion, welding, NDE, etc.


Table for available type of Stainless steel clad plates:

Product Names:

Stainless steel (Duplex) Clad Plate/Sheet, Stainless steel Clad Tube Sheet/ Tube Plate

Production Codes:

ASTM B263, ASME SB263, ASTM B264, ASME SB264, DIN , BS, JIS, GB/T, ISO, etc.

Stainless Steel Grades:

Ferritic Stainless Steel:310, 310S, 410, 410S

Austenitic Stainless Steel:304, 304L, 316, 316L, 321, 316Ti, 317L

Duplex & other high grade stainless steel: 904L,1825, 2205 (S31803), 2507(S32750), N08367 (AL6XN), 254SMo, 926, etc.

Form

Description

Base Layer

Base Layer Grade

Maximum Size

Clad Plate

Stainless (Duplex) / Carbon Steel Clad

Carbon steel plate and forging

SA516 Gr.60(N),Gr.70(N),SA387 Gr.11, Gr.22, SA266, SA350, etc.

(1.5~14)/(6~200) x W(max W 4110) x L(max L 7000)

Titanium / Stainless Steel (Duplex) Clad

Titanium

ASTM/ASME B265 Gr1, Gr2, Gr.3, Gr.5, Gr7, Gr.9, Gr12

(1.5~14)/(6~200) x W(max W 4110) x L(max L 7000)

Aluminum / Stainless Steel / Aluminum Clad

Aluminum

A1050, A1060, A1070, A1100, A5052, etc.

(1.5~40)/(1-5)/(6~200) x W(max W 1000) x L(max L 1000)

Copper/Aluminum /Stainless Steel/ Aluminum/Copper Clad

Aluminum

A1050, A1060, A1070, A1100, A5052, etc.

(1.5~40)/(1-5)/(6~100) x W(max W 1000) x L(max L 1000)

Copper, Naval Brass

C10100, C10200, C11000, C26200, C28000, C46400, C70600, C71500, etc.



Applications:
Petro-chemical, Vacuum Salt Industry, Chlor-alkali, Metallurgical, Food, Light Industry, Medicine, Auto Industry, Electrolytic Aluminum, Fertilizer, Power Industry, Building Materials, Electrolysis Industry, Hydrometallurgy etc.

Competitive Advantage:

  1. Abundant experience: more than one decade of abundant experience in non-ferrous metal cladding and production;

  2. Technical consulting service: technical consulting on material, welding, NDE, etc;

  3. Independent inspection service: in-process inspection, final inspection;

  4. Transportation advantage: 296kms away from Shanghai seaport.
