Specifications
Brand Name :
Yangtze
Model Number :
6-GFM-38
Place of Origin :
China
Certification :
CE/TUV/ISO/ROHS/MSDS
MOQ :
1 unit
Price :
negotiable
Packaging Details :
Pallet+Carton box
Delivery Time :
7-20 days
Payment Terms :
L/C, T/T, Western Union,Credit Card
Supply Ability :
10000 units/week
Sealed Type :
Sealed Storage Battery
Cycle Life :
1500 Times
Voltage :
12V
Terminal :
M8/M10
Operating Temperature :
-20℃~60℃
Battery Case :
ABS Plastic Battery Box
Maintenance Type :
Free
Self-discharge :
≤3%/Month
Description

Product Description:

AGM Gel Battery is the most advanced and reliable Gel Battery on the market, featuring Absorptive Glass Mat (AGM) technology. Sealed and maintenance-free, this battery has a 12V voltage, an ABS Plastic Battery Box, and is designed for sealed storage. Its self-discharge rate is incredibly low at ≤3%/Month, and it is suitable for operation in temperatures ranging from -20℃ to 60℃. AGM Gel Battery is the perfect choice for customers looking for an Advanced Glass Battery, an Absorptive Glass Mat Battery, and an Advanced Gel Mat Battery.

Features:

  • Product Name: AGM Gel Battery
  • Battery Case: ABS Plastic Battery Box
  • Operating Temperature: -20℃~60℃
  • Voltage: 12V
  • Terminal: M8/M10
  • Cycle Life: 1500 Times
  • Technology: Absorbed Glass Mat Battery (AGM), Absorptive Glass Mat Battery (AGM), Absorptive Glass Battery Mat (AGM)

12V 38Ah Absorbed Glass Mat Battery With ABS Plastic Battery Box 1500 Times Cycle Life

12V 38Ah Absorbed Glass Mat Battery With ABS Plastic Battery Box 1500 Times Cycle Life

1. Functional Parameter 5. Environment Temperature
Nominal Voltage 12V Discharge Temperature -15~50
Nominal Capacity (10 hour rate) 38Ah Charge Temperature 0~40
Number of Cells 6cells Storage Temperature -15~40
2. Rated Capacity at 25 (77° F) 6. Inner Resistance & Max . Discharge Current
10 hour rate (0.1C, 10.8V) 38Ah Fully Charged battery at 25 (77° F) 9.6mΩ
3 hour rate (0.25C, 10.8V) 29.1Ah Max. Discharge Current 570A (5s)
1 hour rate (0.55C, 10.5V) 21Ah Short Circuit Current 1900A
3. Capacity affected by Temperature (10 hour rate) 7. Self-discharge at 25 (77° F)
40 (104° F) 103% Capacity after 3 month storage 91%
25 (77° F) 100% Capacity after 6 month storage 82%
0 (32° F) 85% Capacity after 9 month storage 73%
-15 (5° F) 65% Capacity after 12 month storage 64%
4. Dimension and Weight 8. Constant voltage charging at 25 (77° F)
Length 197mm Cyclic use 14.4~14.9V
Width 165mm Maximum charging current 9.5A
Height 170mm Temperature compensation -30mV/
Total Height 170mm Float use 13.6~13.8V
Reference Weight 11.8kg Temperature compensation -20mV/

12V 38Ah Absorbed Glass Mat Battery With ABS Plastic Battery Box 1500 Times Cycle Life


12V 38Ah Absorbed Glass Mat Battery With ABS Plastic Battery Box 1500 Times Cycle Life12V 38Ah Absorbed Glass Mat Battery With ABS Plastic Battery Box 1500 Times Cycle Life12V 38Ah Absorbed Glass Mat Battery With ABS Plastic Battery Box 1500 Times Cycle Life12V 38Ah Absorbed Glass Mat Battery With ABS Plastic Battery Box 1500 Times Cycle Life

12V 38Ah Absorbed Glass Mat Battery With ABS Plastic Battery Box 1500 Times Cycle Life12V 38Ah Absorbed Glass Mat Battery With ABS Plastic Battery Box 1500 Times Cycle Life12V 38Ah Absorbed Glass Mat Battery With ABS Plastic Battery Box 1500 Times Cycle Life12V 38Ah Absorbed Glass Mat Battery With ABS Plastic Battery Box 1500 Times Cycle Life

Applications:

AGM Gel Battery, manufactured by Yangtze and branded with the model number 6-GFM(G)-65, is a reliable and dependable absorbed glass mat battery. It is certified with CE/TUV/ISO/ROHS/MSDS, and its minimum order quantity is 1 unit. The price is negotiable and the packaging details are pallet+carton box. The delivery time is 7-20 days, and the payment terms are L/C, T/T, Western Union and Credit Card. The company is capable of supplying up to 10000 units/week and the maintenance type is free. It comes with M8/M10 terminal, 12V voltage, ABS plastic battery box, and sealed storage battery. AGM Gel Battery is an advanced glass battery, a gel battery, and an absorbed glass battery.

Packing and Shipping:

AGM Gel Battery packaging and shipping:

Packaging: AGM Gel Battery should be packaged in strong cardboard boxes or other sturdy containers to ensure the battery is not damaged during transportation. Inner packaging should be lined with foam or other cushioning material for extra protection. Special instructions should be included for hazardous materials.

Shipping: AGM Gel Battery can be shipped by either ground or air. Ground shipping may be cheaper, but can take longer. Air shipping is usually more expensive but can get the battery more quickly. Special instructions should be given for hazardous materials.

FAQ:

AGM Gel Battery FAQs
  • Q: What is the brand name of AGM Gel Battery?
    A: Yangtze.
  • Q: What is the Model Number of AGM Gel Battery?
    A: 6-GFM(G)-65.
  • Q: Where does AGM Gel Battery come from?
    A: China.
  • Q: What certifications are available for AGM Gel Battery?
    A: CE/TUV/ISO/ROHS/MSDS.
  • Q: What is the Minimum Order Quantity for AGM Gel Battery?
    A: 1 unit.
