Product Description:

Features:

• Product Name: Advanced Gel Mat Battery, Absorptive Glass Mat Battery, Absorbed Glass Battery
• Operating Temperature: -20℃~60℃
• Discharge Cut-off Voltage: 10.5V~11.0V
• Float Voltage: 13.5V~13.8V
• Charge Voltage: 14.4V~14.7V
• Cycle Life: 1000 Times





  1. Functional Parameter		5. Environment Temperature
  Nominal Voltage	12V	Discharge Temperature	-15~50℃
  Nominal Capacity (10 hour rate)	200Ah	Charge Temperature	0~40℃
  Number of Cells	6cells	Storage Temperature	-15~40℃
  2. Rated Capacity at 25℃ (77° F)		6. Inner Resistance & Max . Discharge Current
  10 hour rate (0.1C, 10.8V)	200Ah	Fully Charged battery at 25℃ (77° F)	3mΩ
  3 hour rate (0.25C, 10.8V)	153.3Ah	Max. Discharge Current	3000A (5s)
  1 hour rate (0.55C, 10.5V)	110.4Ah	Short Circuit Current	10000A
  3. Capacity affected by Temperature (10 hour rate)		7. Self-discharge at 25℃ (77° F)
  40℃ (104° F)	103%	Capacity after 3 month storage	91%
  25℃ (77° F)	100%	Capacity after 6 month storage	82%
  0℃ (32° F)	85%	Capacity after 9 month storage	73%
  -15℃ (5° F)	65%	Capacity after 12 month storage	64%
  4. Dimension and Weight		8. Constant voltage charging at 25℃ (77° F)
  Length	522mm	Cyclic use	14.4~14.9V
  Width	240mm	Maximum charging current	50A
  Height	219mm	Temperature compensation	-30mV/℃
  Total Height	223mm	Float use	13.6~13.8V
  Reference Weight	59.5kg	Temperature compensation	-20mV/℃






Applications:

Yangtze AGM Gel Battery is a reliable and efficient Absorbed Glass Mat (AGM) battery made in China. It is certified by CE/TUV and has a wide operating temperature range from -20℃ to 60℃. The Float Voltage of this battery is between 13.5V and 13.8V, and the Terminal is M8/M10. Additionally, the Discharge Cut-off Voltage is 10.5V to 11.0V. With its Absorptive Glass Mat (AGM) design, this battery is reliable and efficient, making it ideal for a variety of applications.

Customization:

We offer custom AGM Gel Battery services with the following attributes:

• Brand Name: Yangtze
• Place of Origin: China
• Certification: CE/TUV
• Float Voltage: 13.5V~13.8V
• Cycle Life: 1000 Times
• Operating Temperature: -20℃~60℃
• Type: AGM Gel Battery/Absorptive Glass Mat Battery/Advanced Gel Battery/Absorbent Glass Mat Battery
• Terminal: M8/M10

Packing and Shipping:

AGM Gel Battery packaging and shipping processes involve safely and securely packaging the battery and shipping it to the designated customer. The battery should be packaged in a sturdy, non-conductive container, such as a cardboard box, with plenty of padding to secure the battery in place. The container should be sealed with tape and labeled with the customer’s name and address. The battery should then be transported to the customer using a reliable shipping carrier.
