Specifications
Brand Name :
Yangtze
Model Number :
OPZS-1000
Place of Origin :
China
Certification :
CE/TUV/ISO/ROHS/MSDS
MOQ :
1 unit
Price :
negotiable
Packaging Details :
Pallet+Carton box
Delivery Time :
7-20 days
Payment Terms :
L/C, T/T, Western Union,Credit Card
Supply Ability :
5000 units/week
Impedance :
≤0.5mΩ
Self Discharge :
≤3%/month
Battery Type :
OPZV&OPZS
Operating Temperature Range :
–40℃ To +60℃
Design Life :
30 Years
Terminal Type :
M6/M8
Float Voltage :
2.25-2.35V/cell
Capacity Range :
200Ah-3000Ah
Description

Product Description:

OPZV OPZS is a state-of-the-art tubular battery specifically designed to meet the demands of today's modern power systems. With a wide operating temperature range of -40℃ to +60℃, this battery is built to last for up to 30 years with a capacity range of 200Ah-3000Ah. Featuring a robust container material made of ABS, the OPZV OPZS battery is designed to provide reliable power for a wide range of applications. Whether you're looking for a reliable battery for your home, business, or industrial application, the OPZV OPZS battery provides long-lasting performance and durability. With its advanced tubular battery design and long design life, the OPZV OPZS battery is the perfect choice for any application, especially those that require a high-capacity battery such as a 3000Ah battery. With its superior performance and rugged construction, the OPZV OPZS battery is the ideal choice for those seeking a reliable and cost-effective power solution.

1. Functional Parameter 5. Environment Temperature
Nominal Voltage 2V Discharge Temperature -15~55
Nominal Capacity (10 hour rate) 1000Ah Charge Temperature -0~45
Designed Floating Life 20 (68° F) 15~20years Storage Temperature -15~45
2. Rated Capacity at 20 (68° F) 6. Inner Resistance & Max . Discharge Current
5 hour rate (177.6A, 1.75V/cell) 888.0Ah Fully Charged battery at 20 (68° F) 0.28mΩ
3 hour rate (257A, 1.75V/cell) 771.0Ah Max. Discharge Current 8000A (5s)
1 hour rate (571A, 1.60V/cell) 571Ah    
3. Capacity affected by Temperature (10 hour rate) 7. Self-discharge at 20 (68° F)
40 (104° F) 103% Capacity after 3 month storage 91%
25 (77° F) 100% Capacity after 6 month storage 82%
0 (32° F) 86% Capacity after 9 month storage 73%
-15 (5° F) 70% Capacity after 12 month storage 64%
4. Dimension and Weight 8. Constant voltage charging at 20 (68° F)
Length 233mm Cyclic use 2.30~2.40V
Width 210mm Maximum charging current 100A
Height 646mm Temperature compensation -5mV/
Total Height 701mm Float use 2.23~2.25V
Reference Weight Without Electrolyte 57.4kg Temperature compensation -3mV/

Tubular 2V 1000Ah OPZV OPZS Battery Customized

Tubular 2V 1000Ah OPZV OPZS Battery Customized


Tubular 2V 1000Ah OPZV OPZS Battery CustomizedTubular 2V 1000Ah OPZV OPZS Battery CustomizedTubular 2V 1000Ah OPZV OPZS Battery Customized

Tubular 2V 1000Ah OPZV OPZS Battery CustomizedTubular 2V 1000Ah OPZV OPZS Battery CustomizedTubular 2V 1000Ah OPZV OPZS Battery CustomizedTubular 2V 1000Ah OPZV OPZS Battery CustomizedTubular 2V 1000Ah OPZV OPZS Battery Customized

Features:

  • Product Name: OPZV OPZS
  • Design Life: 30 Years
  • Float Voltage: 2.25-2.35V/cell
  • Operating Temperature Range: –40℃ To +60℃
  • Battery Type: OPZV&OPZS
  • Container Material: ABS
  • Capacity: 3000Ah
  • Keywords: Batterie OPZV 3000Ah, OPZV Battery, OPZS Battery, ABS Material

Applications:

The Yangtze OPZV-2500 OPZS 2V series batteries are designed for superior performance and maximum reliability. They are ideal for a wide range of applications, such as standby power, renewable energy systems, solar and wind power systems, and telecom applications. Featuring high-quality components and materials, the batteries are certified with CE/TUV/ISO/ROHS/MSDS and come with a terminal type of M6/M8 and container material of ABS. The capacity range is from 200Ah-3000Ah, with a float voltage of 2.25-2.35V/cell and impedance ≤0.5mΩ. The minimum order quantity is one unit and the price is negotiable. The delivery time is 7-20 days and payment terms include L/C, T/T, Western Union, and Credit Card. With a supply ability of 5000 units/week, the Yangtze OPZV-2500 OPZS 2V series batteries are the perfect solution for your power needs.

Customization:

Yangtze OPZV/OPZS 2V Series Battery

Brand Name: Yangtze

Model Number: OPZV-2500

Place of Origin: China

Certification: CE/TUV/ISO/ROHS/MSDS

Minimum Order Quantity: 1 unit

Price: negotiable

Packaging Details: Pallet+Carton box

Delivery Time: 7-20 days

Payment Terms: L/C, T/T, Western Union,Credit Card

Supply Ability: 5000 units/week

Self Discharge: ≤3%/month

Operating Temperature Range: –40℃ To +60℃

Terminal Type: M6/M8

Capacity Range: 200Ah-3000Ah

Design Life: 30 Years

Yangtze OPZV/OPZS 2V series batteries are highly reliable and long-lasting, featuring CE certification, TUV certification, ISO certification, ROHS certification, MSDS certification, L/C payment, T/T payment, western union payment, credit card payment, 200Ah-3000Ah capacity range, –40℃ to +60℃ operating temperature range, M6/M8 terminal type, and ≤3%/month self discharge.

Support and Services:

Technical support and services for OPZV OPZS include:

  • 24/7 online customer service
  • Regular maintenance and repair services
  • Software and hardware updates
  • Troubleshooting and diagnostics
  • Free technical support
  • Installation and setup assistance
  • Warranty and insurance coverage

Packing and Shipping:

OPZV OPZS Packaging and Shipping:

Our OPZV OPZS products are carefully packaged to ensure safe transportation. Each order is packed in a cardboard box, with foam-in-place packaging for extra protection. Before shipping, we inspect our products for any possible defects. For international orders, we use reliable shipping carriers such as DHL, FedEx, and UPS.
