Tiger Neo Photovoltaic 680W Solar Panel Monofacial Full Black
Tiger Neo Photovoltaic 680W Solar Panel Monofacial Full Black
Tiger Neo Photovoltaic 680W Solar Panel Monofacial Full Black
Tiger Neo Photovoltaic 680W Solar Panel Monofacial Full Black
Tiger Neo Photovoltaic 680W Solar Panel Monofacial Full Black
Tiger Neo Photovoltaic 680W Solar Panel Monofacial Full Black
Specifications
Brand Name :
Yangtze
Model Number :
YS680M-132 Black
Certification :
CE/TUV/ISO/ROHS/INMETRO
Place of Origin :
China
MOQ :
30 pieces
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union,Credit Card
Supply Ability :
20000 pieces/Week
Delivery Time :
7-20 days
Packaging Details :
Pallet+Carton Box
Solar cell :
Half Cell
Backing Color :
Black
OEM Order :
Acceptable
Rated Power :
680W
Dimension :
2384*1303*35mm
connector :
MC4
Frame :
Anodized Aluminum Alloy
Frame color :
Full black
Cell size :
210*210mm
Operating Temperature :
-40℃ to +85℃
Description

Tiger Neo Half Cell Mono Facial Solar Panel 680W Full Black Solar Photovoltaic Panel

Product Description:

Mono Facial Solar Panel

Our Mono Facial Solar Panel is the best choice for those seeking for a reliable and long-lasting solar energy solution. The Single-sided Sun Panels features the latest Half Cut Technology, Grade A Cells, and a 25-year warranty. The frame is designed with a full black color which is perfect for any environment. The temperature range of our Mono Facial Solar Panel is -40℃~+85℃, making it suitable for all kinds of weather conditions. The Mono Facial Solar Panel is easy to install and maintain, making it the perfect energy-saving solution for home and commercial use.

Features:

  • Product Name: Mono-facial Solar Panel
  • Cell Type: Mono-crystalline
  • Frame Color: Full Black
  • Temperature Range: -40℃~+85℃
  • Cell Number: 132
  • Special Feature: Single-sided Solar Panel

Applications:

Mono Facial Solar Panel – Single-Sided Sun Panel from Yangtze, China

Yangtze’s Mono Facial Solar Panel is a single-sided sun paneling solution that can help homeowners, businesses, and organizations save energy and money. This Mono Facial Solar Panel is manufactured with Half Cut technology, specifically designed for single-sided solar paneling. The cells used in this solar panel are Grade A, and the junction box is IP68.

You can order Mono Facial Solar Panel from Yangtze, China, with a minimum order quantity of 30 pieces. The delivery time is 5-10 days, and payment terms are T/T, L/C, or Credit Card. The cell size is 210*210mm.

Customization:

Customize your Mono-facial Solar Panel needs with Yangtze! Our Mono-facial Solar Panel is available in Mono-crystalline cell type with IP68 junction box. This Single-sided Solar Paneling is perfect for a temperature range from -40℃ to +85℃, with cell size of 210*210mm. Place your order with the minimum order of 30 pieces, and expect delivery within 5-10 days. Payment terms include T/T, L/C, and Credit Card.

Support and Services:

Mono Facial Solar Panel Technical Support and Service

We are committed to providing our customers with the best possible technical service and support for our Mono Facial Solar Panel products. Our services include:

  • Technical advice and support for installation, maintenance and troubleshooting
  • Onsite technical support and repair
  • Online assistance for software/firmware updates
  • Replacement parts and components
  • Warranty and service extensions

If you have any questions or concerns regarding our Mono Facial Solar Panel products, please do not hesitate to contact us.

Packing and Shipping:

Mono Facial Solar Panel Packaging and Shipping:

The Mono Facial Solar Panel is packaged safely in a sturdy cardboard box with internal foam cushioning. The product is then shipped in sealed containers, with necessary safety precautions taken for long-distance shipping.

Tiger Neo Photovoltaic 680W Solar Panel Monofacial Full Black

Model Type
YS660M-132
YS670M-132
YS680M-132
YS690M-132
YS700M-132
Rated Maximum Power at STC
660W
670W
680W
690W
700W
Maximum Power Voltage (Vmp)
38.38V
38.68V
38.98V
39.28V
39.58V
Maximum Power Current (Imp)
17.20A
17.33A
17.45A
17.57A
17.69A
Open Circuit Voltage ( Voc)
45.55V
45.85V
46.15V
46.45V
46.75V
Short Circuit Current (Isc)
18.45A
18.54A
18.66A
18.79A
18.92A
Module Efficiency
21.1%
21.4%
21.7%
22.0%
22.3%
Working Conditions&Working Conditions
Operating Temperature
-40°c~+85°c
Maximum System Voltage
DC 1000V(IEC) / 1500V(IEC)
Maximum Series Fuse
25A
Power Tolerance
0~+5W
Temperature Coefficient of Pmax
-0.35%/°c
Temperature Coefficient of Voc
-0.29%/°c
Temperature Coefficient of Isc
+0.048%/°c
STC(Standard Testing Conditions): lrradiance 1000W/m2 , Cell Temperature 25 'C, Spectra at AMl.5
NOCT (Nominal Operating Cell Temperature): lrradiance 800W/m2 , Ambient Temperature 20 'C, Spectra at AMl.5, Wind at l m/S
