Specifications
Brand Name :
KeDa
Place of Origin :
shandong china
MOQ :
1
Price :
$80,000/sets >=1 sets
Payment Terms :
T/T,L/C
Delivery Time :
30
Certification :
CE 9001
Model Number :
CSD150；CSD200;CSD250;CSD300;CSD400;CSD450
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Core Components :
Engine, Gearbox
Type :
Cutter Suction Dredger
Power Type :
Diesel
Dredging Depth :
8 m
Draught :
0.85m-15m
Dimension(L*W*H) :
12.5*5.8*1.6M
Weight :
6000 KG
Warranty :
1 Year
After-sales Service Provided :
Engineers available to service machinery overseas
Pump Model :
10/8 Inch
Water Flow :
800 M3/H
Suction Pipeline Diameter :
300MM
Cutter Head Diameter :
950-40MM
Ladder Winches :
JC-4000
Exported Areas :
Africa,Middl East,Southeast,USA,Australia and South American
Product name :
sand suction dredger
Application :
Sand Dredging
Usage :
Port River Lake Sea
Hull Material :
Steel
Width :
4-15m
Colour :
customized
Description

18 inch/450m3/hr sand suction Dredger price/cutter suction dredger sale/barge boats

Diesel Power Cutter Suction Dredger 8m Dredging Depth 100cm Draught

1. Product Application

Cutter Suction Dredger is a special dredging machine with ISO9001:2008. Cutter Suction Dredger is flexible to most kinds of geologic structures and has a lot of obvious advantages:

1) Wide application range: It can be widely used for mining, sand production, reclamation construction, desalting, land reclamation and so on.

2) High efficiency: The max output can reach to 700 m³/h, water flow 800-5000 steer per hour, digging depth is 4-15 meters, and discharge distance is 200-1500 meters.

3) Quick return, high profits: usually, the investor can Achieve profitability within half a year. It is highly efficient with low cost, a good underwater dredging machine.

4) Standard quality: the main body of the machine is strong, durable and low failure rate.

Diesel Power Cutter Suction Dredger 8m Dredging Depth 100cm Draught

2. Basic parameters

Basic CSD Parameter
Model KDCSD200 KDCSD260 KDCSD300 KDCSD350 KDCSD400 KDCSD450 KDCSD500
Dredger Body
Dimensions(L*W*H)m 12.5*4.6*1.3 12.5*5.8*1.6 14.5*5.8*1.8 14.5*5.8*1.8 22*6.4*2 26*7*2 26*7.1*2.2
Engine room(m) 7.5*2.25*1.4 8*2.8*1.6 9*3.2*1.8 9.5*3.2*1.8 12*3.4*2 14*3.4*2 14*3.5*2.2
Dredging data
Standard dredging depth 6-7m 6-8m 8-10m 10-12m 12-14m 12-14m 12-14m
Pump model 8/6” 10/8” 12/10” 12/10” 14/12” 14/12” 450WN
Water flow 450m3/h 800m3/h 1100m3/h 1500m3/h 1900m3/h 2500m3/h 3200m3/h
Suction pipeline diameter(mm/inch) 260 300 350 350 400 450 500
Discharge pipeline diameter(mm/inch) 200 260 300 350 400 450 500
Devices
Total power KW 176kw 258kw 353kw 480kw 640kw 930kw 1200kw
Generator set(kw) 24 24 24 24 24 36 36
Cutter head
Diameter (mm) 850-30 950-40 1100-50 1200-80 1300-110 1500-120 1700-140
Winch(hydraulic)
Ladder winches JC-3000 JC-4000 JC-4000 JC-6000 JC-6000 JC-10000 JC-12000
Swing winch JC-3000 JC-4000 JC-4000 JC-6000 JC-6000 JC-8000 JC-10000
Spuds
Quantity 2 2 2 2 2 2 2
Spuds length*diameter(mm) 8600*273 11000*300 13000*350 15000*377 17000*450 17000*550 17000*600
Spuds weight/pic 900kg 1500kg 2000kg 2500kg 3900kg 4500kg 5000kg

Diesel Power Cutter Suction Dredger 8m Dredging Depth 100cm Draught

3. Pictures Display

Diesel Power Cutter Suction Dredger 8m Dredging Depth 100cm Draught

Diesel Power Cutter Suction Dredger 8m Dredging Depth 100cm Draught

1) Cutter head

Diesel Power Cutter Suction Dredger 8m Dredging Depth 100cm Draught

2) Pump

Diesel Power Cutter Suction Dredger 8m Dredging Depth 100cm Draught

3) Engine

Diesel Power Cutter Suction Dredger 8m Dredging Depth 100cm Draught

4) Winches

Diesel Power Cutter Suction Dredger 8m Dredging Depth 100cm Draught

5) Other parts

Diesel Power Cutter Suction Dredger 8m Dredging Depth 100cm Draught

4. Clients Visting

Diesel Power Cutter Suction Dredger 8m Dredging Depth 100cm Draught

5. Company Introdution

1) mainly produces iron selecting equipment, kinds of dredgers, dredging equipment, sand washing and sand making equipment, gold panning equipment, magnetic separating, and crusher and so on

2) We design produce several of products according to the customers requirement and geographical condition. It is a modern large-scale mineral processing equipment manufacturer for research and development, engineering design, producing installation, commissioning and after sale service.

3) Our company had established and improves the equipment file and service system, concentrating on customer feedback to make the products constantly improved to meet the customers' different needs.
