26 Inch Cutter Suction Dredger with Spud Carriage System for 6-15m Dredging Depth
26 Inch Cutter Suction Dredger with Spud Carriage System for 6-15m Dredging Depth
26 Inch Cutter Suction Dredger with Spud Carriage System for 6-15m Dredging Depth
26 Inch Cutter Suction Dredger with Spud Carriage System for 6-15m Dredging Depth
26 Inch Cutter Suction Dredger with Spud Carriage System for 6-15m Dredging Depth
26 Inch Cutter Suction Dredger with Spud Carriage System for 6-15m Dredging Depth
26 Inch Cutter Suction Dredger with Spud Carriage System for 6-15m Dredging Depth
26 Inch Cutter Suction Dredger with Spud Carriage System for 6-15m Dredging Depth
Specifications
Brand Name :
Keda
Model Number :
Cutter Suction Dredger
Certification :
CE/ISO
Place of Origin :
China
MOQ :
1
Price :
71933us
Payment Terms :
T/T
Supply Ability :
60days
Delivery Time :
60
Description
Product descriptions from the supplier

26 Inch Cutter Suction Dredger with Spud Carriage System for 6-15m Dredging Depth

26 Inch Cutter Suction Dredger with Spud Carriage System for 6-15m Dredging Depth

The Cutter Suction Dredger is currently a widely used working ship for dredging project, which integrated with dredging, transporting and unloading.

It uses a cutter device at the front to cut and agitate the sediment of the river, and then uses the suction pipe to transport thetwisted sediment material to the storage place with pump power.

Simple operation, high efficiency and lowest price are the characteristics of the Cutter Suction Dredger

KD-CSD150 KD-CSD200 KD-CSD250 KD-CSD300 KD-CSD350 KD-CSD450
LOA( L*w*h) 13*3.2*1.26m 21*4.7*1.2m 28*5.2*1.5m 34.5*7*2m 34.5*7*2m 36*7.9*2.2m
Design Draught 0.8m 1.0m 1.0m 1.2m 1.4m 1.6m
Working Capacity 450m³/h 850m³/h 1000m³/h 1500m³/h 2500m³/h 4500m³/h
Max Dredging Depth 5m 10m 10m 18m 20m 25m
Suction Pipe Dia. 165mm 250mm 300mm 350mm 385mm 510mm
Discharge Pipe Dia. 150mm 200mm 250mm 285mm 300mm 410mm
Engie Power 75-90kw 150-200kw 250-350kw 450-600kw 600-800kw 1000-1300kw
Output Distance 500m 1000m 1300m 1500m 1500m 2000m
Lift 36m 49m 56m 57m 58m 55m
Total Weight 30t 42t 65t 82t 110t
Company Profile
26 Inch Cutter Suction Dredger with Spud Carriage System for 6-15m Dredging Depth

Qingzhou Keda Environment Protection Machinery Co., Ltd.

Located in Qingzhou City, Shandong Province, is a high-tech enterprise with over 30 national patents focusing on the designing, manufacturing, assembly and operation management of environmental protection projects and equipment with more than 11 years′designing and manufacturing experience.

In the two fields of manufacturing and service providing of waters environmental protection equipment, KEDA is engaged in three industries including the research, development and manufacturing, the equipment assembly and commissioning, and the marketing and after-sales service. KEDA products have been exported to more than 50 countries and areas in Southesat Asia, East Asia, South Asia, South America, Oceania, Africa and East Europe, such as United States, Russia, Indonesia, North Korea, the Philippines, Cambodia, Myanmar, Kyrgyzstanm, Kazakhstan, Brazil, Guyana, Suriname, Congo, Ghana, Nigeria, Zimbabwe, etc.

The products have gained recognition and support from customers both at home and abroad due to KEDA′s leading industry technology, professional manufacturing experience, excellent equipment quality and integrity in management.

KEDA will continue to do the best to create world famous brand in the field of waters environmental protection. Welcome to KEDA for investigation, visit and technique communication.

Our Advantages
  • 1.More than 10 years of production experience in dredgers and mineral processing equipment
  • 2.Strong technical service team, can provide customized services
  • 3.Own design team with 30 patents
  • 4.Industry and Trade Integration Enterprise
  • 5.The factory covers an area of over 22,000 square meters
  • 6. 3 production lines-dredger-cleaning boat-gold mining equipment
