Specifications
Brand Name :
WSFIVIN
Model Number :
175DML
Certification :
ESR-5419 (ICC-ES)
Place of Origin :
CHINA
MOQ :
1000
Payment Terms :
T/T,L/C,D/P,D/A
Supply Ability :
10000PCS/DAY
Delivery Time :
7-15 days
Packaging Details :
10Pcs./Bundle 250/500Pcs. / Pallet
Product Name :
Lightweight Diamond Lath With Astm C841 Compliance For Walls
Key Words :
Diamond Metal Lath
Raw Material :
Galvanized Steel
Packing :
500pcs/pallet
Thickness :
0.013in 0.35mm
Country Of Origin :
China
Description

Lightweight Diamond Lath With Astm C841 Compliance For Walls

Designed for rapid wall installations, this lightweight diamond lath combines ASTM C841 compliance with precision-crimped steel strands to achieve 15% faster handling while maintaining exceptional structural stability for scratch coats, EIFS, and sheathing systems. Its advanced open-weave geometry enhances mechanical keying across diverse substrates—from masonry block to steel studs—ensuring uniform plaster adhesion that resists cracking under thermal movement. The featherweight G60 galvanized steel maximizes corrosion defense without compromising rigidity, ideal for moisture-prone zones and high-efficiency buildings where mold resistance is critical.

Drywall contractors and architectural specialists specify this material for furring assemblies, stucco applications, and load-bearing perimeter walls across hospitals, schools, and LEED-certified projects throughout North America. Distributors boost margins with compact pallets holding ±600 rolls, while installers benefit from seamless weep channel integration and curbless transitions over insulation. Partner with our technical team for LEED documentation support or custom pre-curved lath solutions for vaulted features and complex geometries—delivering code-compliant finishes faster through bulk project pricing and just-in-time deliveries.

CODE

Wt./Sq.Yd.(lbs)

Sheet Size

Standard Thickness

Pcs./Bundle

Pcs./Pallet

DML1.75

1.75 LBS

27” x 96”

0.35mm

10

500

DML2.5

2.5 LBS

27” x 96”

0.5mm

10

500

DML3.4

3.4 LBS

27” x 96”

0.638mm

10

250

FAQ

1. What is expanded metal lath used for?

It is mainly used as a base for stucco or plaster on walls, ceilings, and soffits. The mesh provides excellent keying for cementitious materials.

2. Does your product meet U.S. and Canadian standards?

Yes. Our expanded metal lath complies with ASTM C847 and CSA standards, and is ICC-ES(5419) certified, ensuring approval for a wide range of North American construction projects.

3. Do you offer different types and weights?

Yes. We offer various rib profiles, mesh patterns, and weights such as 1.75 lbs, 2.5 lbs, and 3.4 lbs per sheet to suit different application needs.

4. What is your MOQ and lead time?

Our minimum order is 2 pallets (total 1,000 sheets, 500 sheets per pallet). Typical lead time is 15–20 working days, depending on order volume and requirements.

5. How is the product packaged for export?

We use standard palletized packaging for safe and efficient container loading and unloading. Custom labels and weather-resistant wrapping are also available upon request.
