Specifications
Door :
Sliding/Rolling shutter/Hinged steel/Customized steel door
Customization :
Style,size,Color,Material
Main Structurel Material :
Q355B/ASTM A572 Gr.50/EN S355/JIS SM490
Window :
Aluminum alloy / PVC /Industrial louver window
Brand Name :
HCGG
Life Span :
More Than 50 Years
Supply Ability :
50000 Tons/year
Price :
USD35-75 Square Meter/Negotiable
Secondary Structurel Material :
Q235B / ASTM A36/ EN S235JR / JIS SS400
Surface treatment :
Hot-dip galvanized Zinc-rich primer + top coat Anti-corrosion coating
Service Life Time :
50+ Years
After-sale Service :
Online Technical Support, Onsite Installation,Onsite Training,Onsite Inspection,Installation Drawings Support
Service Life :
20-50 Years
Purlin :
C.Z Shape Steel Channel
Certification :
CE/ISO 9001/ISO 3834/ISO 14001/ISO 45001
Payment Terms :
L/C,T/T,Western Union,.pay
Seismic and Wind Resistance Rating :
Designed according to local seismic codes/Wind：0.3-1.1 KN/㎡/81-150 mph
MOQ :
200 square meters
Other Material :
Q460 / ASTM A572 Gr.65 /EN S460 / JIS SM570
Roof and Wall panel :
EPS/Rock wool/PU / PIR sandwich panel,Corrugated/Trapezoidal steel sheet/Customized
Place of Origin :
Henan,China
Delivery Time :
20-45days
Project Solution Capability :
CAD graphic design, 3D Tekla modeling design, total solution for projects,One-stop steel structure solution,Project-based supply
Column and Beam :
Welded H-section/Hot-rolled H-beam/Box column
Description
Steel H Beam Prefabricated Steel Structure 4S Car Dealership Showroom Storage Warehouse Building Construction
Our prefabricated steel structure 4S showroom is a high-performance, customizable building system tailored for automotive sales, display, after-sales service, and parts storage. It adopts factory-prefabricated, on-site bolted assembly, enabling fast construction, large-span column-free space, and strong adaptability to global climate and seismic conditions, while meeting the premium brand image display requirements of car dealerships.
Steel H Beam Prefabricated Steel Structure 4S Car Dealership Showroom Storage Warehouse Building Construction
Product Specification & Parameters
Category Specifications (4S Car Showroom)
Main Steel Structure Material: Q345B/Q235B H-section steel columns/beams, box columns for large spans; Connection: High-strength bolted (no on-site welding, fast & precise); Surface Treatment: Hot-dip galvanizing/epoxy zinc-rich triple coating (anti-corrosion life ≥ 20 years); Seismic Grade: Up to 9-degree, Wind Resistance: 150–180 km/h, Service Life: ≥50 years
Roof & Wall Systems Roof: Rock wool/PU sandwich panels, standing-seam metal roof (waterproof, thermal insulation, soundproof); Walls: Glass curtain wall (frameless full glass for facades), aluminum composite panels, rock wool sandwich panels; Thermal Insulation: K-value ≤ 0.35 W/(m²·K); Fire Rating: Roof/wall up to Class A
Functional Openings & Accessories Doors: Large sliding vehicle doors, sectional overhead doors for service bays, automatic glass entrance doors, customized; Windows: Aluminum alloy thermal-break windows, frameless display windows, customized
Standard Span & Layout Exhibition Hall: 8–12 m column spacing, column-free large open area for vehicle display; Service Workshop: 6–8 m bay spacing, load-bearing floor for lifts (≥ 5 t/m²); Mezzanine Office/Customer Lounge: Optional 2nd floor/mezzanine with steel floor decking, Customized
Construction Cycle Factory prefabrication: 3–4 weeks; On-site installation: 4–6 weeks (60% faster than traditional concrete structures); Full turnkey project: 8–12 weeks
Certifications ISO, CE, SGS, compliance with local building codes (AISC, Eurocode 3, GB50017)
Key Product Advantages
  • Visual Design Enhances Brand Image: Fully customizable facades (curtain walls, metal panels, LED brand logo) meet global automotive brand standards, creating a high-end, modern showroom image to attract customers.
  • Exceptional Spatial Flexibility: The large-span, column-free design maximizes vehicle display space, while modular steel structure components facilitate easy future expansion without large-scale modifications.
  • Rapid Deployment and Cost-Effectiveness: Prefabricated components reduce on-site construction time, minimizing downtime and accelerating market entry. Lightweight steel structures reduce foundation costs, especially on soft soil sites.
  • Durability and Environmental Performance: High corrosion resistance, excellent earthquake and wind resistance; 100% recyclable steel and energy-efficient insulation panels reduce long-term operating energy costs, meeting green building standards.
  • Integrated Service and After-Sales: A one-stop solution from design, manufacturing, transportation, installation to commissioning.
Our Services
One-stop steel structure solutions: design, manufacturing, installation
  • Design drawings
  • Steel structure fabrication for construction
  • Supply of all materials required for the building system
  • Direct installation
Materials We Supply
  • All structural steel for construction
  • Various structural steel connecting bolts and nuts
  • Wall panels and roof panels: single-layer steel plates and sandwich panels (EPS, PU, glass wool, and rock wool)
  • Fixed windows and sliding windows
  • Roller shutters, sliding doors, fire doors, etc.
  • Skylights
  • Turbine ventilation systems and ridge ventilation systems
  • Downspouts and drainpipes, etc.
