Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Specifications
Brand Name :
KXD
Model Number :
KXD-EQUIPMENT
Certification :
ISO9001&CE Certification
Place of Origin :
China
MOQ :
200 square meters
Price :
30-80 USD per sqm
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
15000 tons Per Month
Delivery Time :
35-55 days
Packaging Details :
Steel Pallet Or In Bulk
Name :
Steel Frame Prefab House
Material :
Q345 Q235 Steel Structure
Roof :
Sandwich Panel, Galvanized Steel Sheet
Wall :
Sandwich Panel
Door :
Steel Insulation Door
Window :
Aluminum
Connections :
Bolts Connection
Surface Coat :
Galvanized
Beam :
H Section Steel
Column :
H Section Steel
Color :
Custom approval
Dimensions :
Customized
Design :
Customized
Standard :
ASTM, DIN, GB, JIS
After-sale Service :
Onsite Installation, Onsite Inspection, Free spare parts
Application :
Chicken Shed, Piggery House, Cattle Shed etc.
Customization :
Available
Shot Blasting Level :
SA 2.5
Main Structure :
Steel Structure Frame
Tie Beam :
Round Pipe Or Square Tube
Sample Time :
7 Days If Standard Parts We Have
Third Party Test :
SGS, BV, ITS
Foundation Type :
Concrete/Steel
Thickness :
5-28mm
Fireresistance :
Fire-resistant materials used
Quick Built :
Easy Install
Web Width :
7-28mm
Service Life :
20-50 Years
Connection Type :
Bolted, Welded
Description
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Product Specifications
Attribute Value
Name Steel Frame Prefab House
Material Q345 Q235 Steel Structure
Roof Sandwich Panel, Galvanized Steel Sheet
Wall Sandwich Panel
Door Steel Insulation Door
Window Aluminum
Connections Bolts Connection
Surface Coat Galvanized
Beam H Section Steel
Column H Section Steel
Color Customized
Dimensions Customized
Design Customized
Standard ASTM, DIN, GB, JIS
After-sale Service Onsite Installation, Onsite Inspection, Free spare parts
Certification ISO9001&CE Certification
Application Chicken Shed, Piggery House, Cattle Shed etc.
Steel Poultry Shed Specification
  • Main steel structure: Column - Q235,Q355 Welded H Section Steel
  • Beam: Q235,Q355 Welded H Section Steel
  • Secondary Frame: Purlin - Q235 C and Z purlin
  • Knee Brace: Q235 Angle Steel
  • Tie Rod: Q235 Circular Steel Pipe
  • Brace: Q235 Round Bar
  • Maintenance System: Roof Panel - EPS/Glass fiber /Rock wool sandwich panel
  • Wall Panel: Sandwich panel/ Corrugated Steel sheet
  • Place of Origin: Shandong, China
  • Accessories: Window - Aluminium alloy window/ PVC window/Sandwich panel window
  • Door: Sliding sandwich panel door/Rolling mental door/Personal door
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Drinking & Feeding System
  • Steadily regulating, high sensitivity, sufficient and average water supply, water and time saving
  • Standard double ball valve, easy to replace
  • Stable pressure regulation, high sensitivity water supply
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Silo Attributes
Feature Specification
Core Components Cone Plate - Galvanized coating (275g/㎡)
Warranty 1 Year
Design Accept
Weight 628 KG
Application Poultry Farm Used Feed Storage
Place of Origin Shandong, China
Single package size 260X110X150 cm
Brand Name KXD
Life 25-40 Years
Material Galvanized Corrugated Sheets
Function Grain Wheat Corn Storage Silos
Machinery Test Report Provided
Video Outgoing-inspection Provided
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Leakage Dung Board
  • Made from polypropylene material with anti-aging UV resistance
  • Rounded arc non-slip design protects chicken feet
  • Strong bearing capacity, easy cleaning and installation
  • Long service life with no sharp edges
  • Surface mesh structure for optimal fecal leakage
  • Flexible installation for different hen house conditions
  • Specification: 1200mm X 500mm
  • Weight: 2000g
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Environmental System

Environment control system features chicken growth temperature curve, minimum air volume curve, light curve, automatic control crosswise and lengthways ventilation. Controls exhaust fans, heater stoves, curtains, cooling pads, light system and feeding line. The system can be monitored and managed remotely via mobile phone.

Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Heating System
  • Intelligent control with high efficiency and energy saving
  • Fast warming with safe and durable equipment
  • Stable heating effect for livestock and poultry houses
  • Versatile installation options: outside the house, on the floor or suspended indoors
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Quality Standards
  • GB/T1591-2008/2018
  • GB/T11263-2010
  • GB/T 2518-2008
  • GB/T12754-2006
  • GB/T 1228-2006
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Packaging & Loading
  • All components packed in bundles and secured with steel straps
  • Main frame packed in container or shipped as single package
  • Wall and roof panels packed separately to prevent shipping damage
  • All necessary fittings and accessories included in package
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
Our Services
  1. Custom design plans and detailed approval drawings using Tekla, PKPM, 3D3S software
  2. Professional steel structure buildings consultation service
  3. Budget planning and cost estimation
  4. Precision fabrication with meticulous attention to detail
  5. Onsite erection & installation guidance by skilled technicians
  6. Flexible transportation & delivery options per client requirements
Steel Frame Prefab Poultry House with Automated Broiler Farming Equipment
