Steel Structure Broiler Chicken House with Automated Feeding System
Steel Structure Broiler Chicken House with Automated Feeding System
Steel Structure Broiler Chicken House with Automated Feeding System
Steel Structure Broiler Chicken House with Automated Feeding System
Steel Structure Broiler Chicken House with Automated Feeding System
Steel Structure Broiler Chicken House with Automated Feeding System
Steel Structure Broiler Chicken House with Automated Feeding System
Steel Structure Broiler Chicken House with Automated Feeding System
Steel Structure Broiler Chicken House with Automated Feeding System
Steel Structure Broiler Chicken House with Automated Feeding System
Steel Structure Broiler Chicken House with Automated Feeding System
Steel Structure Broiler Chicken House with Automated Feeding System
Steel Structure Broiler Chicken House with Automated Feeding System
Steel Structure Broiler Chicken House with Automated Feeding System
Specifications
Brand Name :
KXD
Model Number :
KXD-BROILER
Certification :
ISO9001&CE Certification
Place of Origin :
China
MOQ :
200 square meters
Price :
30-80 USD per sqm
Payment Terms :
,MoneyGram,Western Union,T/T,L/C
Supply Ability :
15000 tons Per Month
Delivery Time :
35-55 days
Packaging Details :
Steel Pallet Or In Bulk
Material :
Q345 Q235 Steel Structure
Roof :
Sandwich Panel, Galvanized Steel Sheet
Wall :
Sandwich Panel
Door :
Steel Insulation Door
Window :
Aluminum
Connections :
Bolts Connection
Surface Coat :
Galvanized
Beam :
H Section Steel
Column :
H Section Steel
Color :
Custom approval
Dimensions :
Customized
Design :
Customized
Standard :
ASTM, DIN, GB, JIS
After-sale Service :
Onsite Installation, Onsite Inspection, Free spare parts
Application :
Chicken Shed, Piggery House, Cattle Shed etc.
Name :
Steel Poultry House
Customization :
Available
Shot Blasting Level :
SA 2.5
Main Structure :
Steel Structure Frame
Tie Beam :
Round Pipe Or Square Tube
Sample Time :
7 Days If Standard Parts We Have
Third Party Test :
SGS, BV, ITS
Foundation Type :
Concrete/Steel
Thickness :
5-28mm
Fireresistance :
Fire-resistant materials used
Quick Built :
Easy Install
Web Width :
7-28mm
Service Life :
20-50 Years
Connection Type :
Bolted, Welded
Description
Steel Structure Broiler Chicken House with Automated Feeding System
Product Specifications
Attribute Value
Material Q345 Q235 Steel Structure
Roof Sandwich Panel, Galvanized Steel Sheet
Wall Sandwich Panel
Door Steel Insulation Door
Window Aluminum
Connections Bolts Connection
Surface Coat Galvanized
Beam H Section Steel
Column H Section Steel
Color Customized
Dimensions Customized
Design Customized
Standard ASTM, DIN, GB, JIS
After-sale Service Onsite Installation, Onsite Inspection, Free spare parts
Certification ISO9001&CE Certification
Application Chicken Shed, Piggery House, Cattle Shed etc.
Steel Structure Poultry House Components
  • Main Steel Frame: H section Column & Beam, Purlins, Support, Angel Steel etc.
  • Roof & Wall Cladding: Roof & Ceiling, Wall Panel, Fiberglass Wool as Roof Insulation, Ridge Tile, Trim Coverage and Screws etc.
  • Door & Window: Steel Insulation Door & Aluminum Window and Trims
  • Fastener: Foundation Bolts, Bolt and Nuts etc.
  • Equipment: Cages (H Type and A Type), Feeding System, Manure-Removing System, Cooling and Ventilation, Lighting System, Environment Controlling System
Steel Structure Broiler Chicken House with Automated Feeding System
Automated Feeding System for Broiler

The broiler pan feeding system consists of drive system, feed hopper, feed transport auger, feed pan, suspension system, anti-perch system and feed level sensor. Its primary function is to transport feed from hopper to every feed pan, and to automatically control the on/off drive system, achieving full automation of the feeding process.

The tray is made of PP-polypropylene pure raw material, designed with 14 grid, 13 speed settings to meet different production quantities for chickens of various ages. Features smooth, V-type design with hanging fastening for convenient disassembly and cleaning. Each tray accommodates 0-55 adult chickens and can also be used for chicks feeding.

Steel Structure Broiler Chicken House with Automated Feeding System
Feeding System Components
  • Vice driver
  • The feed pan
  • Feed tube
  • Augor
  • Side feed box
  • The lifting device
  • Perching prevention device
Steel Structure Broiler Chicken House with Automated Feeding System Steel Structure Broiler Chicken House with Automated Feeding System Steel Structure Broiler Chicken House with Automated Feeding System
  • Silo type and hopper type are the two main feeding lines
  • Feed transport system runs steadily, guaranteeing sufficient feed supply
  • Silo volume can be adjusted based on the specific number of birds per shed (Approximately 0.65 ton/m³)
  • Imported feed level sensor enhances accuracy of feeding transport process
  • Adjustable height feed pans are easy to clean and dismantle
Steel Structure Broiler Chicken House with Automated Feeding System
Feed Pan Specifications
Condition New
Name Broiler Pan Feeder
Warranty 1 Year
Application Poultry Farm Chicken Feeding
Key Sell Points Competitive Price & High Quality
Weight 0.9 KG
Place of Origin Shandong, China
Capacity 15-20 Broiler/Pan
Brand Name KXD
Operation Full-automatic
Material Plastic
Installation Support Online Installing & on-site installation
Package Carton
Feed line 4Pan/3M
Steel Structure Broiler Chicken House with Automated Feeding System Steel Structure Broiler Chicken House with Automated Feeding System
Drinker Nipple Specifications
Condition New
Feature 360 degree outer, Long Service Time, Easy cleaning, High performance
Warranty 1 Year
Application Poultry Drinking
Color Custom
Package 14*13*4.5cm/one pack 28 nipples
Place of Origin Shandong, China
Farm Animals Type Chicken Birds Ducks Geese Turkeys
Brand Name KXD
Operation Full-automatic
Size 3.4cm*1.0cm
Installation Support Online Installing & on-site installation
Weight 0.3 KG
Material 304 Stainless Steel+PP
Steel Structure Broiler Chicken House with Automated Feeding System
Cage Feeding System Options
A Type Cage
  • Hot-dip galvanization technology ensures 15-20 years service life
  • Long service life, high stability, and low equipment cost
  • Semi-Automatic drinking and manure cleaning saves energy and improves efficiency
  • Well ventilated, comfortable environment, easy to operate
  • Low feed-to-egg ratio reduces production costs
  • Ideal for manual or semi-automatic open chicken houses with ≤20k layers
  • Reduces operator time and labor costs while improving performance
H Type Cage
  • Hot-dip galvanization ensures 20-25 years service life
  • Space-saving design increases breeding capacity
  • Fully Automatic drinking, feeding, manure cleaning and egg collection
  • Long service life with high stability and output rate
  • High mechanization improves hygiene with low odor
  • Ideal for large-scale farming operations
Steel Structure Broiler Chicken House with Automated Feeding System
Ground Feeding Equipment
Main Feeding Line

Transfers feed to feeders via delivery system when base hopper is filled. Features large capacity, scientific design, firm structure, low cost and long lifespan.

Broiler Pan Feeding System

The core of feeding system using high quality materials for solid, reliable operation. Provides easy access for birds from day one to flow out.

Nipple Drinking System

Provides fresh, clean water vital for bird growth performance while improving poultry house environment. Essential equipment for standard poultry feeding.

Environment Control System

Windows 2000-based automatic environmental monitoring network system enables centralized monitoring of poultry house conditions.

Steel Structure Broiler Chicken House with Automated Feeding System Steel Structure Broiler Chicken House with Automated Feeding System Steel Structure Broiler Chicken House with Automated Feeding System Steel Structure Broiler Chicken House with Automated Feeding System Steel Structure Broiler Chicken House with Automated Feeding System Steel Structure Broiler Chicken House with Automated Feeding System
Our Comprehensive Service
  1. Custom design plans and detailed approval drawings using Tekla, PKPM, 3D3S software
  2. Professional steel structure buildings consultation service
  3. Budget planning and cost estimation
  4. Precision fabrication with great attention to detail
  5. Erection & installation with on-site technical guidance
  6. Flexible transportation & delivery options
Steel Structure Broiler Chicken House with Automated Feeding System Steel Structure Broiler Chicken House with Automated Feeding System Steel Structure Broiler Chicken House with Automated Feeding System
Packaging & Shipping Information
Product Packaging
  • All components packed in bundles secured with steel straps
  • Main frame packed in container or shipped as single package
  • Wall and roof panels packed separately to prevent damage
  • All necessary fittings and accessories included
Shipping Details
  • Shipped by sea transport
  • Delivery time varies by destination
  • Tracking information provided upon shipment
Steel Structure Broiler Chicken House with Automated Feeding System Steel Structure Broiler Chicken House with Automated Feeding System Steel Structure Broiler Chicken House with Automated Feeding System Steel Structure Broiler Chicken House with Automated Feeding System Steel Structure Broiler Chicken House with Automated Feeding System
