ASME SB163 UNS N02201 Seamless Nickel Alloy Tube For Heat Exchanger And Condenser
ASME SB163 UNS N02201 Seamless Nickel Alloy Tube For Heat Exchanger And Condenser
ASME SB163 UNS N02201 Seamless Nickel Alloy Tube For Heat Exchanger And Condenser
ASME SB163 UNS N02201 Seamless Nickel Alloy Tube For Heat Exchanger And Condenser
ASME SB163 UNS N02201 Seamless Nickel Alloy Tube For Heat Exchanger And Condenser
ASME SB163 UNS N02201 Seamless Nickel Alloy Tube For Heat Exchanger And Condenser
ASME SB163 UNS N02201 Seamless Nickel Alloy Tube For Heat Exchanger And Condenser
ASME SB163 UNS N02201 Seamless Nickel Alloy Tube For Heat Exchanger And Condenser
Specifications
Brand Name :
YUHONG
Model Number :
ASME SB163 UNS N02201 (Alloy 201)
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Place of Origin :
China
MOQ :
100 KGS
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
According to Clients' Requirement
Delivery Time :
30 - 60 Work Days
Packaging Details :
Plywood Case
Specification :
ASTM B163, ASME SB163
Material Grade :
UNS N02201 (Alloy 201)
Outer Diameter :
6.35 - 88.9mm
Wall Thickness :
0.5 - 5mm
Length Per Piece :
6 Meter Or As The Client's Request
Tube Ends :
Plain Ends, Bevelled Ends, Threaded Ends
Description

ASME SB163 UNS N02201 Seamless Nickel Alloy Tube For Heat Exchanger And Condenser

ASME SB163 UNS N02201 Seamless Nickel Alloy Tube refers to a seamless tube manufactured from a pure, low-carbon nickel alloy (UNS N02201), produced in accordance with the ASME SB163 specification. ASME SB163 is the material specification that is commonly used for seamless tubes in heat transfer applications. UNS N02201 (also known as Nickel 201, Alloy 201) is a wrought, commercially pure nickel alloy (99.0% min Ni) with a controlled maximum carbon content of 0.02%. Unlike UNS N02200 (Nickel 200), the low carbon content in N02201 prevents the precipitation of graphite at temperatures between 300°C to 600°C (572°F to 1112°F). This ensures the tube maintains excellent ductility and corrosion resistance in high-temperature environments where carbon precipitation would otherwise lead to material failure. ASTM B163 UNS N02201 nickel alloy seamless tubes are widely used for heat exchangers, condensers, oil furnace, petrochemical industry, and so on.

Chemical Composition:

Element Weight %
Nickel (Ni) 99.0% min
Carbon (C) 0.02% max
Iron (Fe) 0.40% max
Manganese (Mn) 0.35% max
Silicon (Si) 0.35% max
Sulfur (S) 0.01% max
Copper (Cu) 0.25% max

Mechanical Properties:

Property Requirement
Tensile Strength (min) 345MPa (50ksi)
Yield Strength (0.2% offset, min) 105MPa (15ksi)
Elongation (in 50 mm / 2", min) 35%
Hardness (Typical, HRB) 45 - 70HRB (Annealed condition)

Key Advantages & Features:

  • High-Temperature Stability
  • Exceptional Corrosion Resistance
  • High Thermal Conductivity: Ideal for heat exchangers
  • Excellent Fabricability: Can be easily welded, brazed, formed, and machined

Different Surface Finishes:

Finish Type Description Typical Application
Annealed & Pickled Oxide scale removed via acid bath; dull, matte gray appearance. General heat exchangers, chemical processing.
Bright Annealed Annealed in a controlled atmosphere; clean, shiny, oxide-free surface. Food processing, electronics.
Polished Mechanically polished to specific Ra (roughness) values (e.g., 0.4 µm Ra). Hygienic lines, decorative or ultra-clean systems.

Different Applications:

  • Chemical Processing
  • Electronics & Semiconductors
  • Aerospace Industry
  • Marine Engineering
  • Battery Manufacturing
  • Synthetic Fiber Production

ASME SB163 UNS N02201 Seamless Nickel Alloy Tube For Heat Exchanger And Condenser
