ASTM A182 F11 CL2 Forgings Alloy Steel Sockolet High Pressure Pipe Fittings
ASTM A182 F11 CL2 Forgings Alloy Steel Sockolet High Pressure Pipe Fittings
ASTM A182 F11 CL2 Forgings Alloy Steel Sockolet High Pressure Pipe Fittings
ASTM A182 F11 CL2 Forgings Alloy Steel Sockolet High Pressure Pipe Fittings
ASTM A182 F11 CL2 Forgings Alloy Steel Sockolet High Pressure Pipe Fittings
ASTM A182 F11 CL2 Forgings Alloy Steel Sockolet High Pressure Pipe Fittings
Specifications
Brand Name :
YUHONG
Model Number :
ASTM A182 F11 CL2 Alloy Steel Sockolet
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Place of Origin :
CHINA
MOQ :
1PC
Payment Terms :
L/C,T/T
Delivery Time :
7 DAYS
Packaging Details :
Ply-wooden Case / pallet
Product Name :
Sockolet
Dimensions :
ANSI, ASTM, ASME, BS, DIN, EN
Standard :
ASTM A182/ ASME SA182
Material :
F5, F9, F11, F12, F22, F91
Size :
As Buyer's Drawing Requirements or Standard
Shape :
Can Custom, As Buyer's Drawing Requirements
Class :
3000#, 6000#, 9000#
High Light :
ASTM A182 F11 Cl2 Forged Fittings, Alloy Steel Sockolet
Description

ASTM A182 F11 CL2 Alloy Steel Forged Sockolet for High Pressure Service

A Sockolet is a type of branch connection fitting manufactured by a company called Bonney Forge (now part of PCC Energy Group). The name has become generic, much like "Kleenex" for tissues. It is used to create a 90-degree branch from a main run pipe without the need for a separate tee fitting.
  • Design: It has a socket-weld outlet on the branch side and a butt-weld connection on the run side (the header). The branch pipe is inserted into the socket and fillet-welded.
  • Purpose: It provides a strong, reinforced branch connection that is ideal for small-bore piping (typically NPS 2" and below) in high-pressure systems. It is more compact and offers better flow characteristics than a threaded coupling or a saddle-type connection.

ASTM A182 F11 CL2 Alloy Steel Forged Fitting Sockolet Equivalent Grade

Brand Name Ravne No. Mat. No. DIN EN AISI
13CRMO44 762 1.7335 13CrMo44 13CrMo4-5 A 182 Grade F11

ASTM A182 F11 CL2 Alloy Steel Forged Fitting Sockolet Chemical Composition (%)

C Si Mn Cr Mo P S
0.1-0.2 0.5-1.0 0.3-0.8 1.0-1.5 0.44-0.65 0.04 max 0.04max

Comparison Table: F11 vs. Common Alternatives

Feature ASTM A182 F11 CL2 ASTM A105 (Carbon Steel) ASTM A182 F22 (Grade 22) ASTM A182 F316L (Stainless)
Primary Use High-Temp Steam & Process Low-Temp Utility Services Higher Temp/Pressure than F11 Corrosion Resistance
Key Elements 1.25% Cr, 0.5% Mo Carbon, Manganese 2.25% Cr, 1.0% Mo 17% Cr, 12% Ni, 2.5% Mo
Temp Range Up to ~1000°F (538°C) Up to ~800°F (427°C) Up to ~1200°F (649°C) Varies (for corrosion)
Main Advantage Balanced strength & weldability Low Cost Superior Creep Strength Excellent Corrosion Resistance
Weldability Good (with pre/PWHT) Excellent Requires careful procedure Excellent

Specification
Standard Types Class Rating/Schedule Ends Size
ASME B16.11 90°Elbow/ 45°Elbow/ Tee/ Cross/Pipe Cap/ Half Coupling/Full Coupling 3000LB/6000LB Threaded 1/4''~4''
Socket-welding 1/8''~4''
90°Elbow/ 45°Elbow/ Tee/ Cross/Half Coupling/Full Coupling 9000LB Socket-welding 1/2''~2''
Street Elbow 3000LB Threaded 1/8''~2''
6000LB 1/8''~1-1/2''
Lateral Tee 3000LB Socket-welding 1/4''~2''
6000LB 1/2''~1-1/2''
3000LB Threaded 3/8''~2‘’
6000LB 1/2''~2''
9000LB 1/2''~1-1/2''
Flush Bushing/Hex Bushing/Hex Plug/Round Plug/Square Plug 3000LB/6000LB Threaded 1/8''~4''
MSS SP79 Reducer Inserts 3000LB/6000LB/9000LB Socket-welding 3/8‘’x1/4''~2x1/2''
MSS SP83 Union 3000LB Socket-welding/Threaded 1/8''~3''
MSS SP95 Concentric/Eccentric Swaged Nipples See Below Note1 1/4‘’~12''
Bull Plugs Threaded 1/8''~12''
MSS SP97 Weldolet STD, XS, Sch 160/XXS Butt-welding 1/8''~36‘’ or larger
Sockolet 3000LB/6000LB Socket-welding 1/8''~6''
Threadolet 3000LB/6000LB Threaded 1/8''~6''
Nipolet XS/XXS Plain/Threaded 1/2''~2''
Elbolet 3000LB/6000LB Socket-welding/Threaded 1/4''~2''
STD/XS/160/XXS Butt-welding 1/4''~2-1/2'' or larger
Latrolet 3000LB/6000LB Socket-welding/Threaded 1/2''~2''
STD/XS/160/XXS Butt-welding 1/2''~2-1/2''
Flangolet,Nipolet,Sweepolet,etc. available as per client' demands.
