ASTM A403 WP316L-S Stainless Steel Buttweld Fittings Conexiones
ASTM A403 WP316L-S Stainless Steel Buttweld Fittings Conexiones
ASTM A403 WP316L-S Stainless Steel Buttweld Fittings Conexiones
ASTM A403 WP316L-S Stainless Steel Buttweld Fittings Conexiones
ASTM A403 WP316L-S Stainless Steel Buttweld Fittings Conexiones
ASTM A403 WP316L-S Stainless Steel Buttweld Fittings Conexiones
ASTM A403 WP316L-S Stainless Steel Buttweld Fittings Conexiones
ASTM A403 WP316L-S Stainless Steel Buttweld Fittings Conexiones
Specifications
Brand Name :
YUHONG
Model Number :
ASTM A403
Certification :
ABS, BV, LR, DNV-GL, KR, CCS , TS, GOST, CCS, TUV, PED
Place of Origin :
CHINA
MOQ :
5 PC
Price :
1-100000 USD
Payment Terms :
L/C, T/T
Supply Ability :
1000 tons/month
Delivery Time :
5-50 days
Packaging Details :
Ply-wooden Case /In Pallet
Product :
Pipe Fittings / Conexiones
Material :
Stainless Steel
Standard :
ASTM A403
Grade :
WP316L-S
Type :
Buttweld Seamless
Packaging :
PLY-WOODEN CASE OR PALLET
Description


ASTM A403 WP316L-S Stainless Steel Buttweld Fittings Conexiones

YUHONG produce and supplies ASTM 403 WP316L Seamless Stainless Steel Buttweld Fittings with high quality and we sell these pipe fittings in more than 70 countries.

ASTM A403 This specification covers wrought stainless steel fittings for pressure piping applications.

Standard ASTM A403
Grades we can offer

WP304/304L/304H,WP316/316L/316H,WP317/317L,WP321/321H
WP347/347H,WP310S,WP316TI,etc
Products ELBOWS,TEES,REDUCERS,CAPS,etc
Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10,etc
Fittings Thickness SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS
Fittings Types

Buttweld Fitting,Seamless Fittings,ERW Fittings,Welded Fittings
Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or as required
Fittings Manufacturing process Push, Press, Forge, Cast, etc
Buttweld Pipe Fittings Test Certificates EN 10204/3.1B,Raw Materials Certificate,100% Radiography Test Report
Third Party Inspection Report, etc


Chemical Composition % (Maximum, unless otherwise indicated)

Grade C Mn P S Si Ni Cr Mo
WP316L 0.03 2.00 0.045 0.03 1.00 10.0-14.0 16.0-18.0 2.00-3.00

For small diameter or thin walls, or both, where many drawing passes are required, a carbon maximum of 0.040 % is necessary in grades TP304L and TP316L. Small outside diameter tubes are defined as those less than 0.500 in. [12.7 mm] in outside diameter and light wall tubes as those less than 0.049 in. [1.24 mm] in average wall thickness.

ASTM A403 WP316L-S Stainless Steel Buttweld Fittings Conexiones


Tensile Requirements

Grade Yield Strength min kis(MPa) Tensile Strength min kis(MPa) Elongation Requirements
WP316L 30(205) 75(515) Longitudinal-28,Transverse-20

Solution Anneal Temperature, min 1900 [1040] °F [°C]B

Application

Oil and gas industry
Pulp and paper industry
Petroleum and Chemical
Power plants
Energy industries
Water waste projects
Fluid piping,etc.

ASTM A403 WP316L-S Stainless Steel Buttweld Fittings Conexiones
