Heat Exchanger Tube, ASTM A213 T9 Alloy Steel Seamless U Bend Tube For Fired Heaters
Heat Exchanger Tube, ASTM A213 T9 Alloy Steel Seamless U Bend Tube For Fired Heaters
Heat Exchanger Tube, ASTM A213 T9 Alloy Steel Seamless U Bend Tube For Fired Heaters
Heat Exchanger Tube, ASTM A213 T9 Alloy Steel Seamless U Bend Tube For Fired Heaters
Heat Exchanger Tube, ASTM A213 T9 Alloy Steel Seamless U Bend Tube For Fired Heaters
Heat Exchanger Tube, ASTM A213 T9 Alloy Steel Seamless U Bend Tube For Fired Heaters
Heat Exchanger Tube, ASTM A213 T9 Alloy Steel Seamless U Bend Tube For Fired Heaters
Heat Exchanger Tube, ASTM A213 T9 Alloy Steel Seamless U Bend Tube For Fired Heaters
Specifications
Brand Name :
YUHONG
Model Number :
ASTM A213, ASME SA213 T9
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Place of Origin :
China
MOQ :
500 KGS
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
According To Clients' Requirements
Delivery Time :
15 - 90 Work Days
Packaging Details :
Ply-Wooden Case / Iron Case
Standard :
ASTM A213, ASME SA213
Material Grade :
T9
Product Name :
Alloy Steel U Bend Tube
Type :
Seamless
Technique :
Cold Drawn
Sizes :
As Per Client's Request
NDT :
HT, ET, UT , PT
Applications :
Heat Exchanger, Boiler, Petroleum, Condenser, Etc.
Description

Heat Exchanger Tube, ASTM A213 T9 Alloy Steel Seamless U Bend Tube For Fired Heaters

ASTM A213 T9 Alloy Steel U Bend Tubes are seamless ferritic alloy steel tubes designed to withstand high temperatures and pressures. They are made of a type of steel which contains small amounts of carbon, manganese, and silicon, as well as large amounts of chromium and molybdenum, to provide excellent resistance to oxidation, corrosion, and deformation at high temperatures. T9 Alloy Steel U Bend Tubes are commonly used in boilers, super heaters, heat exchangers in power plants or other industrial environments.

Benefits:

T9 Alloy Steel U Bend Tubes offer high temperature strength, excellent resistance to corrosion and oxidation, good weldability and formability, and they are cost effective compared to other high-temperature alloys. Thus, they are usually used in high-pressure and high-stress environments such as boilers, heat exchangers & power plants.

Specification:

Specification ASTM A213, ASME SA213
OD Size 1/8" To 30"
WT Schedule 20 To Schedule XXS
Length As Customer’s Request
Ends Plain Ends, Beveled Ends, threaded Ends
Process Seamless - Hot Rolled, Cold Drawn

Heat Exchanger Tube, ASTM A213 T9 Alloy Steel Seamless U Bend Tube For Fired Heaters

Equivalent Material:

STANDARD WERKSTOFF NR. UNS
T9 1.7386 S50400

Chemical Composition:

C, % 0.15 max
Mn, % 0.3-0.6
P, % 0.025 max
S, % 0.025 max
Si, % 0.25-1
Cr, % 8-10
Mo, % 0.9-1.1

Mechanical properties:

Material Tensile Strength (Mpa) Yield Strength (Mpa) Elongation(%) Hardness(HRB)
T9 ≥415 ≥205 ≥30 ≤85

Applications:

Water Supply Systems

Fabrication Industry

Boiler and Heat Exchangers

Oil and Gas Plants

Transportation Systems

Food Processing Industry

Fabrication Industry

Chemical Industry

Plumbing Equipments

Heating Equipments

Power Plants

Paper & Pulp Plants

Heat Exchanger Tube, ASTM A213 T9 Alloy Steel Seamless U Bend Tube For Fired Heaters
