Heat Exchanger Tube Stainless Steel Seamless Tube Durable Pickled Annealed Tube for Cooling System
Heat Exchanger Tube Stainless Steel Seamless Tube Durable Pickled Annealed Tube for Cooling System
Heat Exchanger Tube Stainless Steel Seamless Tube Durable Pickled Annealed Tube for Cooling System
Heat Exchanger Tube Stainless Steel Seamless Tube Durable Pickled Annealed Tube for Cooling System
Heat Exchanger Tube Stainless Steel Seamless Tube Durable Pickled Annealed Tube for Cooling System
Heat Exchanger Tube Stainless Steel Seamless Tube Durable Pickled Annealed Tube for Cooling System
Heat Exchanger Tube Stainless Steel Seamless Tube Durable Pickled Annealed Tube for Cooling System
Heat Exchanger Tube Stainless Steel Seamless Tube Durable Pickled Annealed Tube for Cooling System
Specifications
Brand Name :
YUHONG HOLDING GROUP
Model Number :
TP304/304L , TP316L , TP310S, TP316Ti, TP321/321H , TP347 , TP317
Certification :
ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Place of Origin :
CHINA, JAPAN, THAILAND, UK, USA
MOQ :
100KGS
Price :
NEGOTIABLE
Payment Terms :
L/C, T/T
Supply Ability :
ACCORDING TO CUSTOMER'S REQUEST
Delivery Time :
10-15 DAYS
Packaging Details :
PLY-WOODEN CASE OR PALLET
Spec :
ASTM A213/A213M-2013 , ASME SA213/SA213M-2013 , A789 , SA789
Material :
TP304/304L , TP316L , TP310S, TP316Ti, TP321/321H , TP347 , TP317
Type :
Straight Tube , U Bend Tube, Coil Tube
Surface :
Bright Annealed, Pickled And Annealed , Polished
Package :
PLY-WOODEN CASE
Description

Heat Exchanger Tube Stainless Steel Seamless Tube Durable Pickled Annealed Surface,Straight/U Type/Coil Tube for Cooling

Specification:

ASME SA213/A213: Standard Specification for Seamless Ferritic and Austenitic Alloy-

Steel Boiler, Superheater and Stainless Steel Heat Exchanger Tubes.

ASTM A249 / A249M:Standard Specification for Welded Austenitic Steel Boiler, Superheater

Heat-Exchanger, and Condenser Tubes.

ASTM A789/A789M, ASME SA789/SA789M Seamless and Welded Ferritic/Austenitic Stainless Steel Tubing for General Service

Other Standard:DIN 17456 , DIN 17458, EN10216-5, GOST 9940-81, GOST 9941-81, JIS-G3463,...

Material Grade:

Size Range:

Production Outside Diameter Wall Thickness
Heat Exchanger Tube 6.00mm to 101.6mm 0.5mm to 8mm

Final Finishing

Solution Annealed & Pickled/Bright Annealed.

Type of Tubes:

U-bend & Straight.

Some of the quality tests carried out by us includes:

Corrosion Test Conducted only when specially requested by the client
Chemical Analysis Test done as per required quality standards
Destructive / Mechanical Testing Tensile | Hardness | Flattening | Flare | Flange
Reverse-bend and Re. flat tests Carried out in full compliance with relevant standards & ASTM A-450 and A-530 norms, which ensures trouble-free expansion, welding & use at customers end
Eddy Current Testing Done to detect homogeneities in subsurface by using Digital Flaw-mark Testing System
Hydrostatic Testing 100% Hydrostatic Testing carried out according to ASTM-A 450 norms for checking tube leakage, and biggest pressure we can support 20Mpa/7s .
Air Under Pressure Test To check any evidence of air leakage
Visual Inspection After passivation, every single length of tubes & pipes is subjected to thorough visual inspection by trained staff for detecting surface flaws & other imperfections


Supplementary Testing : Apart from the above mentioned tests, we also carry out on the manufactured products supplementary testing. The tests conducted under this include:

  • Eddy Current Testing
  • O.P Testing
  • Radiography Testing
  • Corrosion Testing
  • Micro Testing
  • Macro Testing
  • IGC Testing
  • Ultrasonic testing
  • Liquid Penetrate testing

Heat Exchanger Tube Stainless Steel Seamless Tube Durable Pickled Annealed Tube for Cooling System
