Automatic PLC Weld Planisher For Steel Sheet Tank Shell Surface Longitudinal planishing machine
Automatic PLC Weld Planisher For Steel Sheet Tank Shell Surface Longitudinal planishing machine
Automatic PLC Weld Planisher For Steel Sheet Tank Shell Surface Longitudinal planishing machine
Automatic PLC Weld Planisher For Steel Sheet Tank Shell Surface Longitudinal planishing machine
Automatic PLC Weld Planisher For Steel Sheet Tank Shell Surface Longitudinal planishing machine
Automatic PLC Weld Planisher For Steel Sheet Tank Shell Surface Longitudinal planishing machine
Automatic PLC Weld Planisher For Steel Sheet Tank Shell Surface Longitudinal planishing machine
Automatic PLC Weld Planisher For Steel Sheet Tank Shell Surface Longitudinal planishing machine
Automatic PLC Weld Planisher For Steel Sheet Tank Shell Surface Longitudinal planishing machine
Automatic PLC Weld Planisher For Steel Sheet Tank Shell Surface Longitudinal planishing machine
Automatic PLC Weld Planisher For Steel Sheet Tank Shell Surface Longitudinal planishing machine
Automatic PLC Weld Planisher For Steel Sheet Tank Shell Surface Longitudinal planishing machine
Specifications
Brand Name :
Trancar Industries
Model Number :
TCM-LP
Certification :
CE/ISO
Place of Origin :
China
MOQ :
1 set
Price :
USD 20000-60000 Dollar per set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
10 sets per Month
Delivery Time :
50 work days
Packaging Details :
Standard Export Package
Product Name :
Steel sheet tank shell surface longitudinal welds planisher
Dimension :
5800x900x1800 mm
Weight :
4500 kg
Color :
Blue/Red/Grey
Voltage :
380V 400V 415V etc
Usage A :
Crushing steel sheet surface longitudinal welds
Condition :
100% new
Warranty :
1 year
Provide :
ODM & OEM
Usage B :
Crushing steel tank shell surface long welding seam
Description

PLC automatic welds planisher for Steel sheet tank shell surface longitudinal welds finishing with CE from Trancar Industries

TCM-LP automatic welding seam planishing machine weld planisher is designed for steel tank shell and steel sheet surface longitudinal welded seams surface treatment before polishing such as flatten & crush & planishing treatment after welding,and to make steel tank or steel sheet with better surface thus to get higher quality Ss tanks.It’s mainly for crushing steel tank longitudinal welded seams & lines,crushing tank vertical welded joints,planishing steel sheet long welding line and planishing vessel longitudinal welding seams.It is widely applied in the industries of pharmaceuticals,chemical,environmental purification,food & beverage,water filtration,etc.

Automatic PLC Weld Planisher For Steel Sheet Tank Shell Surface Longitudinal planishing machine

Automatic PLC Weld Planisher For Steel Sheet Tank Shell Surface Longitudinal planishing machine

Automatic PLC Weld Planisher For Steel Sheet Tank Shell Surface Longitudinal planishing machine

Automatic PLC Weld Planisher For Steel Sheet Tank Shell Surface Longitudinal planishing machine

Steel tank longitudinal weld planisher parameter:

Normal configuration(customer design acceptable)
Steel metal tank size Tank shell diameter ≧ 1000 mm
Tank / Welded Seam Length Max. 4000 mm / 5000mm Custom design
Tank shell Max.Weight 1 Ton / 2 Ton / 5 Ton /10 Ton
Flatten Roller Move Speed 0.05~2m/min
Welded Seam Width 50-70mm / Based on demands
Flatten machine size Machine Dimension 5800*900*1800mm
Operating pressure 21 Mpa
Input total Power / 28 kw
Power Supply 380V 415V / 50Hz 60HZ / 3p or Customization
Machine Weight / 4500kg
Color Grey/Green/Blue/Red/Yellow Custom design

Hefei Trancar Industries welds planisher package & delivery:

Automatic PLC Weld Planisher For Steel Sheet Tank Shell Surface Longitudinal planishing machine

Automatic PLC Weld Planisher For Steel Sheet Tank Shell Surface Longitudinal planishing machine

Custom design service is available,contact Trancar industries for more welds planishing machine and solutions:

Automatic PLC Weld Planisher For Steel Sheet Tank Shell Surface Longitudinal planishing machine
