Steel Tank Shell Weld Planisher Longitudinal Flatten Planishing Machine
Steel Tank Shell Weld Planisher Longitudinal Flatten Planishing Machine
Steel Tank Shell Weld Planisher Longitudinal Flatten Planishing Machine
Steel Tank Shell Weld Planisher Longitudinal Flatten Planishing Machine
Steel Tank Shell Weld Planisher Longitudinal Flatten Planishing Machine
Steel Tank Shell Weld Planisher Longitudinal Flatten Planishing Machine
Steel Tank Shell Weld Planisher Longitudinal Flatten Planishing Machine
Steel Tank Shell Weld Planisher Longitudinal Flatten Planishing Machine
Specifications
Brand Name :
Trancar Industries
Model Number :
TCM-LF
Certification :
CE/ISO
Place of Origin :
China
MOQ :
1 set
Price :
USD 9000-25000 Dollar per set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
20 sets per Month
Delivery Time :
35 work days
Packaging Details :
Custom design plywood box
Product name :
Steel tank longitudinal welding seams planishng machine
Color :
Yellow/Red/White etc
Voltage :
380V 400V 415V etc
Provide :
ODM & OEM
Description

Steel tank longitudinal welding seams planishng machine long welding seam planishing

TCM-LF automatic welding seam planishing machine is designed for steel tank shell welded seams surface treatment before polishing such as flatten & crush & planishing treatment after welding,and to make steel tank with better surface thus to get higher quality Ss tanks.It’s mainly for crushing steel tank longitudinal welded seams & lines,crushing tank vertical welded joints and planishing vessel longitudinal welding seams.It is widely applied in the industries of pharmaceuticals,chemical,environmental purification,food & beverage, water filtration,etc.

Steel tank longitudinal welding seams planishng machine parameter:

Normal configuration(customer design acceptable)

Steel metal tank size

Tank shell diameter

≧ 500 mm

Tank / Welded Seam Length

1800 mm /Custom design

Tank shell Max.Weight

1 Ton / 2 Ton / 5 Ton /10 Ton

Flatten Roller Move Speed

≧2500 mm/minute

Welded Seam Width

50-70mm / Based on demands

Flatten machine size

Machine Dimension

2000*900*3200mm

Operating pressure

12 Mpa

Input total Power

/

5 kw

Power Supply

380V 415V / 50Hz 60HZ / 3p or Customization

Machine Weight

/

2200kg

Color

Grey/Green/Blue/Red/Yellow Custom design

Steel Tank Shell Weld Planisher Longitudinal Flatten Planishing Machine

Contact Trancar Industries for more welds flatten planishing machine and solutions.
