Fireproof Prefab Steel Frame Building with 50 Years Service Life and Customizable Span
Fireproof Prefab Steel Frame Building with 50 Years Service Life and Customizable Span
Fireproof Prefab Steel Frame Building with 50 Years Service Life and Customizable Span
Fireproof Prefab Steel Frame Building with 50 Years Service Life and Customizable Span
Fireproof Prefab Steel Frame Building with 50 Years Service Life and Customizable Span
Fireproof Prefab Steel Frame Building with 50 Years Service Life and Customizable Span
Fireproof Prefab Steel Frame Building with 50 Years Service Life and Customizable Span
Fireproof Prefab Steel Frame Building with 50 Years Service Life and Customizable Span
Specifications
MOQ :
100 PCS
Payment Terms :
T/T in advance
Place of Origin :
Chengdu , China
Brand Name :
Shunyao Supply Chain
Packaging Details :
Bundles
Delivery Time :
5-15 days
Supply Ability :
Excellent
Price :
$40-200
Warranty :
5 Years
Structuralsystem :
Rigid frame / Braced frame
Frametype :
Cold-formed steel / Hot-rolled steel
Application :
Industrial/Commercial
Wallmaterial :
Steel panels / Insulated panels / Cladding
Corrosion Resistance :
High
Labor Costs :
Lower
Design Load :
Wind, Snow, Seismic
Fireresistance :
Fireproof coatings available, typically rated up to 2 hours
Maintenance Costs :
Reduced
Sand Blasting :
Sa 2.5
Thickness Of Panel :
50mm, 75mm, 100mm, 150mm, 200mm, 250mm
Structure :
Frame
Using Life :
50 Years
Product :
Steel Structure
Production :
Finished for direct install support
Features :
Steel Structure For Auto Service Shop
Seismic Resistance :
Good
Productname :
Prefab Steel Frame
Costefficiency :
Competitive
Framematerialgrade :
Q235/Q345
Spanwidth :
Customizable, typically 10-40 meters
Size :
Customized
Keyword :
Light Frame Steel Construction
Product Insulation :
Thermal and Sound Insulation
Structure Type :
Pre-engineered Building
Installation :
Prefabricated components, easy assembly
Description
Fireproof Steel Frame Buildings for Industrial, Commercial & Agricultural Use
Our Fireproof Steel Frame Buildings provide the ultimate solution for modern construction projects requiring high safety standards and structural integrity. Engineered with high-grade steel (Q235/Q355) and treated with advanced intumescent fireproof coatings, these structures are designed to withstand extreme temperatures and protect your assets.
Key Features and Benefits
  • Superior Fire Resistance: Coated with certified fire-retardant paint that expands under heat to insulate the steel core, meeting international building safety codes
  • Versatile Applications: Perfectly suited for industrial manufacturing plants, workshops, logistics centers, commercial shopping malls, office buildings, exhibition centers, aircraft hangars, and agricultural grain storage, poultry sheds, barns, and machinery garages
  • Cost-Effective & Fast Construction: Pre-engineered components allow for 30-50% faster installation compared to traditional concrete buildings
  • Durability: High resistance to wind, snow, and seismic activity with anti-corrosion treatments ensuring long lifespan
Technical Specifications
Parameter Details
Structure Type Portal Frame / Truss Structure / Multi-story Frame
Span 10m - 60m (Clear span without middle columns available)
Eave Height 3m - 30m (Customizable based on requirements)
Wind Load Up to 120 km/h (Or customized to local climate codes)
Snow Load Up to 2.0 kn/m² (Designed according to local snowfall)
Seismic Grade Grade 7 to Grade 9
Service Life 50+ Years
Certification ISO9001, CE, SGS, BV
Component Materials
Component Material Specification
Main Steel Frame Q355B (Low alloy high-strength structural steel) or Q235B
Secondary Frame (Purlins) C-Section or Z-Section Steel (Galvanized)
Roof & Wall Cladding Corrugated Steel Sheet (0.5mm/0.6mm) or Sandwich Panel
Insulation Options Glass Wool, Rock Wool, PU, or EPS Sandwich Panels
Surface Treatment Fireproof Coating, Hot-dip Galvanized, or Anti-rust Painting
Connection Method High-strength Bolts (Grade 10.9s)
Doors & Windows Electric Rolling Doors, Sliding Doors, Aluminum Alloy Windows
Fireproof Prefab Steel Frame Building with 50 Years Service Life and Customizable Span
Cost Calculation Preparation Checklist
  • Dimension: Length, width, height, eave height, roof pitch, etc.
  • Doors and windows: Dimension, quantity, position
  • Local climate: Wind speed, snow load, seismic magnitude etc.
  • Insulation material: Panel type, sandwich materials, sandwich thickness
  • Crane metal structures: If using overhead crane, provide lifting height and lifting weight
  • Import restrictions: Materials not allowed to import to the destination country
  • Special requirements: Fire proofing, insulated roof, or other specific needs
  • Design documents: Existing drawings or pictures for reference
