Customizable Dimensions Steel Frame Building with 50+ Years Lifespan and Wind Load Resistance
Customizable Dimensions Steel Frame Building with 50+ Years Lifespan and Wind Load Resistance
Customizable Dimensions Steel Frame Building with 50+ Years Lifespan and Wind Load Resistance
Customizable Dimensions Steel Frame Building with 50+ Years Lifespan and Wind Load Resistance
Customizable Dimensions Steel Frame Building with 50+ Years Lifespan and Wind Load Resistance
Customizable Dimensions Steel Frame Building with 50+ Years Lifespan and Wind Load Resistance
Customizable Dimensions Steel Frame Building with 50+ Years Lifespan and Wind Load Resistance
Customizable Dimensions Steel Frame Building with 50+ Years Lifespan and Wind Load Resistance
Customizable Dimensions Steel Frame Building with 50+ Years Lifespan and Wind Load Resistance
Customizable Dimensions Steel Frame Building with 50+ Years Lifespan and Wind Load Resistance
Specifications
MOQ :
100 PCS
Payment Terms :
T/T in advance
Place of Origin :
Chengdu , China
Brand Name :
Shunyao Supply Chain
Packaging Details :
Bundles
Delivery Time :
5-15 days
Supply Ability :
Excellent
Price :
$40-200
Corrosion Resistance :
High
Product :
Steel Structure
Durability :
50+ years lifespan
Design Parameter :
Wind Load,Snow Load And Earthquake
Design Software :
PKPM, Tekla structures, CAD
Maintenance Costs :
Reduced
Corrosionresistance :
Galvanized or painted coating
Productname :
Steel Frame Building
Thickness Of Panel :
50mm, 75mm, 100mm, 150mm, 200mm, 250mm
Maintenance :
Low maintenance required
Structure :
Frame
Raw Steel Material :
Q235B, Q355B, ASTM A36
Working Scope :
Design,Fabrication, Installation
Material :
High-strength steel
Sustainability :
Eco-friendly
Dimensions :
Customizable length, width, and height
Crane :
Without Or From 1Ton ~300Ton
Building Structure Type :
Light Steel Structure
Main Structure :
Galvanized Light Steel Frames
Structuretype :
Frame
Surface Treatment :
Spray paint
Transportation :
Containerized
Secondary Structure :
Purlin; Brace; Knee Brace etc
Cost :
Moderate to High
Foundationtype :
Concrete slab or pile foundation
Height :
Customizable, typically up to 12 meters
Description
Custom Steel Structure Building Solutions
We design and fabricate customized steel structure components for light and heavy steel structure buildings in portal frame and dome frame configurations. Our expertise includes warehouses, workshops, storage facilities, hangars, agricultural buildings, commercial structures, industrial plants, and specialized infrastructure projects.
Key Advantages
  • Complimentary architectural drawings in 2D & 3D
  • Structural frame design with over 50-year service life
  • Engineered for wind resistance, snow loads, and seismic conditions
  • Compliance with international standards: EN10902, AS4100, AISC-360-05
  • Clear spans up to 60 meters
  • High-strength steel materials: S355JR, Q355B, GR50, AS3678-350
  • Steel portal frame construction with H-beams and I-beams
  • Insulated and single skin roof/wall cladding options
  • Complete industrial gate, entrance, and window systems
  • Bolted assembly without on-site welding
  • Hot-dip galvanized or painted frame options
  • 4-6 week delivery timeframe
  • Full customization available
  • Extensive worldwide market experience
  • Comprehensive overseas construction expertise
Customizable Dimensions Steel Frame Building with 50+ Years Lifespan and Wind Load Resistance
Product Specifications
General Product Details
Products Steel structure workshop
Type As per customer drawings
Main Material Q235B (ASTM A36, S235JR), Q355B
Surface Treatment Painting, Galvanized
Process-Cutting Laser cutting, plasma cutting, flame cutting for intricate shapes
Forming Rolling and bending to meet complex structural designs
Welding MIG, TIG, Submerged arc
Machining Drilling, milling for precise fittings
Component Technical Specifications
Main Steel Structure Q235, Q355B steel, Welded H-type, I-type, Box-type frames
Surface Treatment Sa2.5 grade shot blasting, Alkyd painting, Epoxy zinc-rich painting, or Galvanization per customer requirements
Purlins C-section, Z-section profiles, Electro-galvanized (40g/m2, 60g/m2, 90g/m2, 275g/m2)
Bracing System Cross brace, Column brace, Knee brace, Batter brace, Tie bar
Wall & Roof Cladding Single corrugated galvanized metal sheet or insulated sandwich panels (Rockwool, Fiberglass, EPS, PU)
Doors Electric roller shutter door, Sliding door, Single/Double open door
Windows UPVC / Aluminum windows
Rainspout System Galvanized gutter, UPVC down pipes
Fittings & Accessories Anchor bolt, High-strength bolt, Screw, Trip plate, Sealing glue
Project Planning Information
To help you quickly calculate the cost of steel structures, please prepare the following information:
  • Dimensions: Length, width, height, eave height, roof pitch
  • Doors and Windows: Dimensions, quantity, position
  • Local Climate: Wind speed, snow load, seismic magnitude
  • Insulation Material: Panel type, sandwich materials, sandwich thickness
  • Crane Requirements: Lifting height and weight if overhead crane needed
  • Import Restrictions: Any materials not allowed in your country
  • Special Requirements: Fire proofing, insulated roof, etc.
  • Existing Documentation: Drawings or reference pictures
