SR12-2RS Inch Stainless Ball Bearing with Snap Ring PS2 Grease
SR12-2RS Inch Stainless Ball Bearing with Snap Ring PS2 Grease
SR12-2RS Inch Stainless Ball Bearing with Snap Ring PS2 Grease
SR12-2RS Inch Stainless Ball Bearing with Snap Ring PS2 Grease
Specifications
Brand Name :
SGC
Model Number :
SR12-2RS
Certification :
ROHS
Place of Origin :
CHINA
MOQ :
1000PCS
Price :
Get the Latest Price
Payment Terms :
D/P, L/C, T/T, Western Union
Supply Ability :
50000pcs per month
Delivery Time :
45 days
Packaging Details :
Plastic Tube+Outer Carton
Material :
440
Type :
deep groove ball bearing
Number of row :
Single Row
Structure :
Deep Groove, Snap Ring
Precision rating :
ABEC-3, ABEC-1
Seals type :
2RS
Package :
Plastic Tube and Box
Bore size :
19.05 mm
Outside diameter :
41.275 mm
Hardness :
HRC 58-62
Surface :
harden polished
Lubrication :
PS2
Service :
REM brand or OEM Service
Vibration :
Z1V1
Feature :
Corrosion Resistance
Description

SR12-2RS Inch Stainless Ball Bearing with Snap Ring PS2 Grease

Rubber Seals Type - Anti-Corrosion

Materials: AISI440C Stainless Steel

Hardness: HRC58-62

Preccision Grade: ABEC-1, ABEC-3

Vibration: Z1

Bore Size: 19.05mm

OD: 41.275mm

Width: 11.112mm

Applications:

The bearings are widely used on ocean engineering equipment and ship, food processing machinery, medical equipment, cryogenic engineering, automobile, motorcycle, electric tools, high-speed motor, household appliances and other industries.

Features and Benefits
• The seals are made from an oil and wear-resistant synthetic rubber with a steel reinforcement
• Operating temperature from -40°C to +120°C
• Accepts radial and axial loads
• Both standard and C3 clearance available
• Versatile
SR12-2RS Inch Stainless Ball Bearing with Snap Ring PS2 Grease

Bearing No.
Boundary Dimensions(mm)
Basic Load Ratings
dDWidth(B)ChamferC(N)CO(N)
OpenShields
SSR812.728.5756.357.9380.35.12.38
SSR1015.87534.9257.148.730.363.25
SSR1219.0541.2757.93811.1120.69.385.02
SSR1422.22547.6259.52512.70.6105.85
SSR1625.450.89.52512.70.6105.85
SSR1828.57553.9759.52512.7113.28.3
SSR2031.7557.159.52512.7113.28.3
SSR2234.92563.511.11214.288116.210.5
SSR2438.166.67511.11214.288117.0311.7
