316L Stainless Steel Honed Tube OD 20 Mm ID 16 Mm WT 2 Mm For Hydraulic Cylinders
316L Stainless Steel Honed Tube OD 20 Mm ID 16 Mm WT 2 Mm For Hydraulic Cylinders
Specifications
Model Number :
316L
Length :
1000–12000 mm or Customized
Type :
Round Stainless Steel Tube
Packaging Details :
Standard Package
MOQ :
500kgs
Delivery Time :
8 ~ 14 days
Wall Thickness :
2 mm
Price :
negotiable
Standard :
ASTM A269
Payment Terms :
T/T
Grade :
316L / UNS S31603
OD :
20 mm
Supply Ability :
Adequate production
Product name :
316L Stainless Steel Honed Tube
Brand Name :
JUDE STEEL
Applications :
Hydraulic & Pneumatic Systems etc.
Certification :
ISO,SGS,CE,BIS
Place of Origin :
China
Description
316L Stainless Steel Honed Tube OD 20 Mm ID 16 Mm WT 2 Mm For Hydraulic Cylinders

Honed tubes are widely recognized as hydraulic cylinder tubes because they are the primary material used in the production of hydraulic cylinders. Their precision-honed inner diameter provides excellent surface finish and dimensional accuracy, ensuring smooth piston movement and reliable sealing performance. Since the honing process is mainly applied to the tube's internal bore, they are also commonly referred to as honed ID tubes or ID honed tubing.

Product Specifications Of 316L Stainless Steel Honed Tube
Item Specification
Product Name 316L Stainless Steel Honed Tube
Material Grade 316L / UNS S31603
Standards ASTM A269, ASTM A213, ASTM A312, EN 10216-5
Manufacturing Process Seamless + Cold Drawn + Precision Honed
Outside Diameter (OD) 20 mm
Inside Diameter (ID) 16 mm
Wall Thickness (WT) 2 mm
Length 1000–12000 mm or Customized
ID Tolerance H7 / H8
Inner Surface Roughness Ra ≤ 0.2–0.4 μm
Straightness ≤0.5 mm/m
Surface Finish Honed ID / Bright Annealed or Polished OD
Certificate EN 10204 3.1 MTC
316L Stainless Steel Honed Tube OD 20 Mm ID 16 Mm WT 2 Mm For Hydraulic Cylinders
Material & Composition Of 304 Cold Drawn Seamless Stainless Steel Tube

ID.:16 mm
OD:20 mm

W.T.: 2 mm

Length: 1000–12000 mm or Customized

Material:316L

Product Features Of Hydraulic Cylinder Honed Tube

  • Precision cold drawn seamless construction
  • Honed internal bore for low friction performance
  • Excellent corrosion resistance in marine and chemical environments
  • High dimensional accuracy with H7/H8 tolerance
  • Smooth inner surface (Ra ≤ 0.4 μm)
  • Excellent straightness and concentricity
  • Superior weldability and machinability
  • Long service life under high-pressure conditions

Chemical Composition of 316L Stainless Steel

Element Content (%)
Carbon (C) ≤0.03
Silicon (Si) ≤1.00
Manganese (Mn) ≤2.00
Phosphorus (P) ≤0.045
Sulfur (S) ≤0.030
Chromium (Cr) 16.0–18.0
Nickel (Ni) 10.0–14.0
Molybdenum (Mo) 2.0–3.0
Nitrogen (N) ≤0.10
Iron (Fe) Balance

Mechanical Properties
Property Value
Tensile Strength ≥485 MPa
Yield Strength ≥170 MPa
Elongation ≥40%
Hardness ≤95 HRB
Density 7.99 g/cm³
Elastic Modulus 193 GPa
Precision Honing Performance
Property Value
ID Surface Finish Ra 0.2–0.4 μm
ID Tolerance H7 / H8
Roundness ≤0.02 mm
Straightness ≤0.5 mm/m
Concentricity High Precision
Advantages of Precision Honing
  • Reduced seal wear
  • Lower friction coefficient
  • Improved hydraulic efficiency
  • Stable piston movement
  • Excellent sealing performance
  • Longer cylinder service life
FAQ

1. What is a 316L stainless steel honed tube?

A 316L stainless steel honed tube is a seamless precision tube that undergoes cold drawing and honing to produce a highly accurate inner diameter with an ultra-smooth surface for hydraulic and pneumatic cylinders.

2. Why choose 316L over 304 for hydraulic cylinders?

316L contains molybdenum, providing superior resistance to chlorides, seawater, and corrosive chemicals. It is the preferred choice for marine, offshore, food processing, and chemical industries.

3. What are the dimensions of this honed tube?

This product has an outside diameter of 20 mm, an inside diameter of 16 mm, and a wall thickness of 2 mm. Custom dimensions are also available.

4. What is the inner surface roughness after honing?

The honed inner surface typically achieves Ra 0.2–0.4 μm, ensuring excellent sealing performance and reduced friction.

5. Can you supply customized sizes?

Yes. JUDE STEEL offers customized OD, ID, wall thickness, length, tolerance, and machining services according to customer drawings or technical requirements.

6. What certificates do you provide?

We provide EN 10204 3.1 Material Test Certificates (MTC), PMI reports, UT reports, dimensional inspection reports, and third-party inspection certificates upon request.
