ASTM A240 304/SUS304 Hot Rolled Stainless Steel Plate No.1 Finish 1.0mmx1x2m For Vessel Maintenance IMPA 671604
ASTM A240 304/SUS304 Hot Rolled Stainless Steel Plate No.1 Finish 1.0mmx1x2m For Vessel Maintenance IMPA 671604
Specifications
Model Number :
SUS304
Material :
304 / SUS304 / UNS S30400 / EN 1.4301
MOQ :
1
Delivery Time :
8 ~ 14 days
Length :
2000 mm
Price :
negotiable
Width :
1000 mm
Packaging Details :
Standard Package
Payment Terms :
T/T
Advantage :
Excellent Corrosion Resistance
Supply Ability :
Adequate production
Application :
Vessel Maintenance etc.
Certification :
ISO,SGS,CE,BIS
Standard :
ASTM A240, ASTM A480, JIS G4304, EN 10088
Place of Origin :
China
Thickness :
1 mm
Brand Name :
JUDE STEEL
Product name :
ASTM A240 304/SUS304 Hot Rolled Stainless Steel Plate
Description
ASTM A240 304/SUS304 Hot Rolled Stainless Steel Plate No.1 Finish 1.0mmx1x2m For Vessel Maintenance IMPA 671604

671604 SUS304 hot-rolled stainless steel plate is a 304 austenitic stainless steel plate that meets the ASTM A240 standard, with excellent corrosion resistance, good welding performance, and processing performance. The product adopts No.1 hot-rolled acid washed surface, suitable for fields such as ship maintenance, marine engineering, chemical equipment, pressure vessels, structural manufacturing, and general industrial equipment. As a ship material corresponding to IMPA Code 671604, it can meet the procurement needs of shipyards, ship maintenance companies, and maritime suppliers.

671604 Stainless Steel Plate Hot Rolled Specifications
Item Specification
Product Name ASTM A240 304/SUS304 Hot Rolled Stainless Steel Plate
IMPA Code 671604
Material Grade 304 / SUS304 / UNS S30400 / EN 1.4301
Standard ASTM A240, ASTM A480, JIS G4304, EN 10088
Manufacturing Process Hot Rolled
Surface Finish No.1 Finish (Pickled & Annealed)
Thickness 1 mm
Standard Size 1000 × 2000 mm
Width 1000 mm
Length 2000 mm
Thickness Tolerance According to ASTM A480 or customer requirements
Flatness ASTM A480 Standard
Edge Type Mill Edge (ME), Slit Edge (SE)
Density 7.93 g/cm³
Heat Treatment Solution Annealed
Processing Services Cutting, Shearing, Laser Cutting, Plasma Cutting, Water Jet Cutting, CNC Machining
Inspection PMI, UT, Thickness Inspection, Dimension Inspection, Surface Inspection, Third-Party Inspection Available
Packaging Standard Export Seaworthy Wooden Pallet or Wooden Case
Application Vessel Maintenance, Shipbuilding, Offshore Engineering, Chemical Processing, Pressure Vessels, Heat Exchangers, Food Processing Equipment, Architectural Structures
Chemical Composition (%) Of SUS304 Stainless Steel Plate ASTM A240 304/SUS304 Hot Rolled Stainless Steel Plate No.1 Finish 1.0mmx1x2m For Vessel Maintenance IMPA 671604
Element Content (%)
Carbon (C) ≤0.08
Silicon (Si) ≤1.00
Manganese (Mn) ≤2.00
Phosphorus (P) ≤0.045
Sulfur (S) ≤0.030
Chromium (Cr) 18.00–20.00
Nickel (Ni) 8.00–10.50
Nitrogen (N) ≤0.10
Iron (Fe) Balance
Physical Properties of ASTM A240 Stainless Steel Plate
Property Value
Density 7.93 g/cm³
Melting Range 1400–1450°C
Modulus of Elasticity 193 GPa
Thermal Conductivity (100°C) 16.2 W/m·K
Specific Heat Capacity (20°C) 500 J/kg·K
Electrical Resistivity (20°C) 0.72 μΩ·m
Coefficient of Thermal Expansion (20–100°C) 17.2 × 10⁻⁶/K
Magnetic Permeability Essentially Non-magnetic (Annealed Condition)
Mechanical Properties of SUS304 No.1 Finish Plate
Property Value
Tensile Strength ≥515 MPa
Yield Strength (0.2% Offset) ≥205 MPa
Elongation (50 mm) ≥40%
Hardness (HB) ≤201 HB
Hardness (HRB) ≤92 HRB
Hardness (HV) ≤210 HV
Reduction of Area ≥60%
Advantages of 671604 SUS304 Hot Rolled Stainless Steel Plate Compared with Other Stainless Steel Plates
Grade Main Advantages Limitations Typical Applications
304 / SUS304 Excellent balance of corrosion resistance, strength, weldability, and cost-effectiveness Not recommended for highly concentrated chloride environments Vessel maintenance, construction, food processing, pressure vessels
201 Stainless Steel Lower cost, higher manganese content Lower corrosion resistance and durability than 304 Decorative panels, indoor applications, furniture
316 / 316L Stainless Steel Superior resistance to chlorides and seawater due to molybdenum addition Higher material cost Marine engineering, offshore platforms, chemical processing
430 Stainless Steel Good oxidation resistance and lower price Ferritic structure with poor weldability and corrosion resistance Household appliances, interior decoration
321 Stainless Steel Titanium stabilized for excellent high-temperature performance More expensive than 304 Exhaust systems, heat exchangers, aerospace components
310S Stainless Steel Outstanding heat resistance up to 1100°C Higher cost and not necessary for general corrosion environments Furnaces, boilers, heat treatment equipment

Why Choose SUS304 Hot Rolled Stainless Steel Plate?
  • Excellent resistance to atmospheric corrosion and many industrial chemicals.
  • Cost-effective compared with 316/316L while offering excellent overall performance.
  • Outstanding weldability and fabrication properties.
  • High strength and toughness for structural applications.
  • Widely accepted international grade with excellent availability.
  • Suitable for marine maintenance, shipbuilding, industrial fabrication, and pressure vessel manufacturing.
Applications of 671604 SUS304 Hot Rolled Stainless Steel Plate

The ASTM A240 SUS304 Hot Rolled Stainless Steel Plate is widely used across industries requiring excellent corrosion resistance, mechanical strength, and fabrication performance.
