AH36 A36 HT Steel Plate SIZE 10 MM THK X 2000 MM X 6000 MM OF MIN YIELD STRESS 355N/mm2
AH36 A36 HT Steel Plate SIZE 10 MM THK X 2000 MM X 6000 MM OF MIN YIELD STRESS 355N/mm2
AH36 A36 HT Steel Plate SIZE 10 MM THK X 2000 MM X 6000 MM OF MIN YIELD STRESS 355N/mm2
AH36 A36 HT Steel Plate SIZE 10 MM THK X 2000 MM X 6000 MM OF MIN YIELD STRESS 355N/mm2
AH36 A36 HT Steel Plate SIZE 10 MM THK X 2000 MM X 6000 MM OF MIN YIELD STRESS 355N/mm2
AH36 A36 HT Steel Plate SIZE 10 MM THK X 2000 MM X 6000 MM OF MIN YIELD STRESS 355N/mm2
Specifications
Brand Name :
Mittel
Model Number :
AH36/DH36/EH36
Certification :
SGS ISO MTC
Place of Origin :
China
MOQ :
100KGS
Price :
0.75 USD/KG
Payment Terms :
L/C, T/T
Supply Ability :
80000KGS
Delivery Time :
7 Working Days
Packaging Details :
Wooden Pallet BOX
Width :
100mm-3500mm
Length :
200-12000mm
Thickness :
1.5-30 mm or Customized
Grade :
AH36 DH36 EH36
Condition :
Hot Rolled
Use :
Shipbuilding
Description

ASTM A131 AH36 steel plate, AH36 steel is a kind of steel for shipbuilding and platform. Shipbuilding steel plate AH36 is the high tensile strength steel. As a professional AH36 shipbuilding steel plate exporter, Bebon international can supply steel plate AH36. ASTM A 131 AH36 shipbuilding steel plates can be used in the manufacture of the ship's hull structure whose weight is below 10000 tons.

AH36 shipbuilding steel plate specification:
Thickness: 4mm to 260mm,
Width: 1200mm to 4000mm
Length: 3000mm to 18000mm.

AH36 steel Chemical Composition %:


Grade

C

max

Si

max

 Mn

P

max

S

max

Als

min

Ti

max

Cu

max

 Cr
max		 Ni
max		 Mo
max		 Nb V
AH36 0.18 0.50 0.90-1.60 0.035 0.035 0.015 0.02 0.35 0.20 0.40 0.08 0.02-0.05 0.05-0.10

Note: Generally speaking CE will be ≤ 0.40%. If the delivery condition is TMPC, the CE will be : ≤ 0.38% (thickness ≤ 50mm),≤0.40%( when the thickness >50-100). Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.

AH36 steel plate Mechanical Property


Grade		 Rm
(MPa)		 Re(MPa) min A% min Akv/J min
AH36 490-630 355 21 E.T °C Thickness (mm)
0 ≤ 50 >50-70 >70-100
L C L C L C
34 24 41 27 50 34

Note: In the list , Rm: .tensile strength,Re: Yield strength,A%: elongation, E.T: experimental temperature,L: lengthways, C: crosswise.

AH36 steel plate Condition Of Delivery


Grade		 Fine grains elements category The thickness of steel
≤ 12 >12.5-20 >20-25 >25-35 >35-50 >50-100
AH36 Nb+V or V Plate/
sheet		 A(50) N(50),CR(50),TM(50) N(50),CR(25),TM(50)
Profile steel N(50),CR(50),TM(50),AR*(25) -
Al or Al+Ti Plate/
sheet		 A(50) AR*(25) -
N(50),CR(50),TM(50) N(50),CR(25),TM(50)
Profile steel A(50) N(50),CR(50),TM(50),AR*(25) -

Note: 1. delivery condition: A =Any ; N=Normalized ; CR=Control Rolled ; TM=TMPC, Temperature - deformation control rolling; AR*= Can be hot rolled with the agreement of Classification Society ; CR*=Can be control rolled with the agreement of Classification Society .
2. The Figure in the ( ) means the sampling volume to do the impact test, the unit is Ton.(-) means without impact test.

AH36 steel plate Contrast in the different standard


ASTM A131M		 TOCT 5521 BS LR GB712
AH36 A36 AH36 A36
