CCS ABS DNV LR Certification EH36 Marine Steel Plate Ship Plank Marine Plate
CCS ABS DNV LR Certification EH36 Marine Steel Plate Ship Plank Marine Plate
CCS ABS DNV LR Certification EH36 Marine Steel Plate Ship Plank Marine Plate
CCS ABS DNV LR Certification EH36 Marine Steel Plate Ship Plank Marine Plate
CCS ABS DNV LR Certification EH36 Marine Steel Plate Ship Plank Marine Plate
CCS ABS DNV LR Certification EH36 Marine Steel Plate Ship Plank Marine Plate
Specifications
Brand Name :
BAOSTEEL WISCO JIGSTEEL
Model Number :
EH36
Certification :
SGS,BV
Place of Origin :
CHINA
MOQ :
5 TON
Price :
550-650 USD
Payment Terms :
T/T
Supply Ability :
5000TONS every month
Delivery Time :
7 - 15 days
Packaging Details :
Export packing or as required
Name :
ship steel plate
material :
A D E F grade
length :
6-11m
width :
1500-2500mm
thickness :
5-250mm
Type :
hot rolled
Description

CCS ABS DNV LR Certification EH36 Marine Steel Plate Ship Plank Marine Plate

The EH36 shipbuilding steel plate is the mainly kinds of steel for shipbuilding and oil platform, the shipbuilding gradeEH32 can be used in the manufacture of the ship's hull structure, whose weight is more then 10000 tons. Shipbuilding grade EH32 is the high tensile strength steel, EH32 steel for shipbuilding and oil platform must be good toughness properties, higher strength, strong corrosion-resistance, the processing properties, and welding properties.

EH36 shipbuilding steel plate Chemical Composition %


Grade

C max

Si max

Mn

P max

S max

Als min

Ti max

Cu max

Cr
max

Ni
max

Mo
max

EH36

0.18

0.50

0.90-1.60

0.035

0.035

0.015

0.02

0.35

0.20

0.40

0.08

EH36 shipbuilding steel plate Mechanical Property


Grade

Rm
(MPa)

Re(MPa) min

A% min

Akv/J min

EH36

440-570

315

22

E.T °C

Thickness (mm)

-40

≤ 50

>50-70

>70-100

L

C

L

C

L

C

31

22

38

26

46

31

EH36 shipbuilding steel plate Condition Of Delivery


Grade

Fine grains elements

category

The thickness of steel

≤ 12

>12.5-20

>20-25

>25-35

>35-50

>50-100

EH36

Any

Plate/sheet

N,TM

Profile steel

N(25),TM(25),AR*(15),CR*(15)

-

Note: 1. delivery condition: A =Any ; N=Normalized ; CR=Control Rolled ; TM=TMPC, Temperature - deformation control rolling; AR*= Can be hot rolled with the agreement of Classification Society ; CR*=Can be control rolled with the agreement of Classification Society .


2. The Figure in the ( ) means the sampling volume to do the impact test, the unit is Ton.(-) means without impact test.

EH32 shipbuilding steel plate Contrast in the different standard


ASTM A131M

TOCT 5521

JIS G3106

BS LR

GB712

EH36

E36

SM490B
SM490C

EH36

E36

Application

1)Petroleum, Chemical enterprise, superheater of boiler,
heat exchanger
2)High temperature resistant transmission fluid pipe
in power station
3)Ship with pressure pipe
4)The exhaust purification devices
5)Home appliance, electrical components, decorate pipe
6)Precision instrument manufacture

CCS ABS DNV LR Certification EH36 Marine Steel Plate Ship Plank Marine PlateCCS ABS DNV LR Certification EH36 Marine Steel Plate Ship Plank Marine PlateCCS ABS DNV LR Certification EH36 Marine Steel Plate Ship Plank Marine Plate

FAQ

1.Will you deliver the goods on time?

Yes,we promise to provide best quality products and delivery in time no matter if the price change lot or not, Honesty is our company's tenet.
2.How can I get your quotation as soon as possible?
The email and fax will bechecked in 24 hours, meanwhile, the skype will be online in 24 hours Please tell us the order information about quantity,Specification(steel type, material, size )and destination port, you will get the latest price.
3.How about the sample if i need?
The sample will be offered for free if you need, but the freight will be covered by our customer. If we have cooperation, the
freight will be covered by our company.
4.How about the MOQ?
Generally, the trail order will be accepted.The MOQ can be confirmedaccording to the different products. For example, the MOQ of PPGI will be 10MT.
5.How about the delivery time?
Within 15-30daysafter receiving the deposit or L/C at sight. Of course, the detail will be confirmed by the quantity and the different products.
6.How to order?
Please send us your purchase order by email. Or you can ask us to send you a proforma invoice for your order. We
need to know the following information for your order.
7.What is shipment terms?
1. Container ship 2. bulk ship 3. Train
8.Do youhave English Mill Test Certificates?
Yes,that is what we give gurantee to our clients
9.Do you accept the third party inspection?
Yes,absolutely we accept.
