Stainless Steel Plastic Bottle Filling Machine , Beverage Production Line For Red Wine
Stainless Steel Plastic Bottle Filling Machine , Beverage Production Line For Red Wine
Stainless Steel Plastic Bottle Filling Machine , Beverage Production Line For Red Wine
Stainless Steel Plastic Bottle Filling Machine , Beverage Production Line For Red Wine
Stainless Steel Plastic Bottle Filling Machine , Beverage Production Line For Red Wine
Stainless Steel Plastic Bottle Filling Machine , Beverage Production Line For Red Wine
Specifications
Model Number :
KaiQuan Series
Certification :
CE
MOQ :
1 Set
Price :
Negotiable depend on the technical details
Payment Terms :
T/T, L/C
Supply Ability :
30 Set per month
Delivery Time :
40 days after get your advance payment
Packaging Details :
Standard Wooden Box
Name :
beverage production equipment
Function :
Washing, Filling, Capping
Bottle Material :
Plastic & PVC
Capacity :
150MLto 5000ML
Bottle /Hour :
3000-12000 Bottles /Hour
Gas Source Pressure :
0.6Mpa
Packing :
Wooden Pallet
Bottle Size :
250ml~2000ml (Special Can Be Order)
Description

Stainless Steel Yogurt Beverage Juice Red Wine Beverage Filling Machine

1. Introduction of Beverage Filling Machine :

General Descriptions


This machine works harmoniously with air-conveyor belt; it holds the bottles by the neck when transporting
This machine is used to fill water into pet bottle and with screw caps capping function.
Integrated three function: 1. Rinse the empty pet bottle, 2. filling the rinsed bottles, 3. capping the filled bottles

2. Technical Parameter :

Item Technical Parameter
Production Output 16000BPH @ 500ml PET bottle
Rinsing heads 10pcs
Filling nozzles 8pcs
Capping heads 4pcs
Suitable to PET bottle Size Diameter Φ50~Φ95mm
Highness:160~320mm,
Bottle neck: 28mm,
Bottle volume from 200 to 2250ml
Suitable to Caps PCO28
Washing Water Required 2000 liter per hour
Washing Pressure Required 0.2Mpa
Washing time 3 second
Drip water time 3 second
Working Power 380V AC 3-phase
Compressed Air Pressure (for caps arranger) 0.8MPa
Compressed Air Consumption (for caps arranger) 2m3/min
Control Panel Power 24V DC
Filling Pressure gravity
Filling temperature 85 degree
Machine Size 2800x2650x2700mm
Gross Weight 6,000kg approximately
Total Power 3.92KW

Stainless Steel Plastic Bottle Filling Machine , Beverage Production Line For Red Wine
