6mm 8mm 10mm 12mm Thickness Hastelloy C276 Plate Laser Cutting Round Square Irregular Shape
6mm 8mm 10mm 12mm Thickness Hastelloy C276 Plate Laser Cutting Round Square Irregular Shape
6mm 8mm 10mm 12mm Thickness Hastelloy C276 Plate Laser Cutting Round Square Irregular Shape
6mm 8mm 10mm 12mm Thickness Hastelloy C276 Plate Laser Cutting Round Square Irregular Shape
6mm 8mm 10mm 12mm Thickness Hastelloy C276 Plate Laser Cutting Round Square Irregular Shape
6mm 8mm 10mm 12mm Thickness Hastelloy C276 Plate Laser Cutting Round Square Irregular Shape
6mm 8mm 10mm 12mm Thickness Hastelloy C276 Plate Laser Cutting Round Square Irregular Shape
6mm 8mm 10mm 12mm Thickness Hastelloy C276 Plate Laser Cutting Round Square Irregular Shape
Specifications
Brand Name :
DELTA
Model Number :
hastelloy C276
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
40-45 USD/Kg
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3 Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Nickel Alloy Plate
Grade :
hastelloy C276
Thickness :
1.0 - 20.0mm
Width :
1000mm 1219mm 1500mm
Standard :
ASTM EN
Service :
Cutting
Loading Port :
Shanghai Port
Surface :
2B NO.1
Description

6mm 8mm 10mm 12mm Thickness Hastelloy C276 Plate Laser Cutting Round Square and Irregular Shape

Products Specification

Product Type Hastelloy C276 ASTM B575 Sheet, Hastelloy C276 ASTM B575 Plate
Specification ASTM B575 / ASME SB575
Tolerances (width / thickness)
  • EN 10258/ DIN 59381)
  • EN 10151 2.4819 Hastelloy C-276 Strips
  • EN 10088 Hastelloy C276 SB575 strips
Dimensions
  • Cold rolled Alloy C276 Sheets1.0 - 3.0mmmm
  • Hot rolled Alloy C276 Plates 4.0 - 25.0 mm
Thickness 1.0 - 25.0mm
Width 10 - 1500mm
Length 2m, 2.44m, 3m, or as required
Finish SATIN, 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), No.1 finish hot rolled, 1D, No.4, BA, 8K, hairline, brush, mirror etc.
Hardness Soft, Hard, Half Hard, Quarter Hard, Spring Hard
variety of shapes Coils, Foils, Plates, Sheet, Strip, Plain Sheet, Checker Plates, Rolling Sheet, Flats, Clad Plates, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), Rolling Plates, Flat Shim, soft annealed, descaled, tread Plates, sheared, annealed

Description of Hastelloy C276

Hastelloy C-276 is a nickel-molybdenum-chromium-tungsten alloy with excellent general corrosion resistance and good fabricability. The alloy should be considered for use in environments where resistance to hot contaminated mineral acids, organic and inorganic chloride-contaminated media, chlorine, formic and acetic acids, acetic , acetic anhydride, sea water and brine solutions is desired.
Hastelloy C-276 has resisted the formation of grain boundary precipitates in the weld heat-affected zone, making it a candidate for most chemical and petrochemical processing applications in the as-welded condition. The alloy has resisted both general and localized corrosion, including pitting, crevice corrosion, and stress corrosion cracking.
Hastelloy C-276 is readily fabricated by welding, using methods similar to those utilized for nickel-based alloys.


Our Hastelloy C276 Sheet and Plate in Stock

Cold Rolled Hastelloy C276 Sheet

  • Thickness: 1.0mm ,1.2mm,1.5mm,2.0mm,2.5mm,3.0mm
  • Standard Size: 1219*2438mm(4ft*8ft)

Hot Rolled Hastelloy C276 Plate

  • Thickness: 4.0mm,5.0mm,6.0mm,8.0mm,10.0mm,12.0mm,14.0mm,16.0mm,20.0mm,25.0mm
  • Standard Size: 1500*6000mm, custom laser cutting any size as request

Forged Hastelloy C276 Plate

  • Thickness: >25.0mm custom as request
  • Size: any size as request


Small MOQ Quantity at least 2KG

Standard Specifications

  • Plate, Sheet & Strip: ASTM B575, ASME SB575
  • Rod & Bar: ASTM B574, ASME SB574
  • Seamless Pipe & Tube: ASTM B622, ASME SB622
  • Welded Pipe & Tube: ASTM B619, ASME SB619
  • Fittings: ASTM B366, ASME SB366
  • Forgings: ASTM B564, ASME SB564
  • Technischer Überwachungsverein (TÜV): Werkstoffblatt 400, Kennblatt 320, Kennblatt 319
  • Others: NACE MR0175, ISO 15156

Hastelloy C276 Composition

The chemical makeup of Hastelloy C276 is what provides its robust resistance to corrosion and its mechanical strength. The alloy primarily consists of the following chemical composition range as defined in ASTM B574 specification:

  • 57% – Nickel (Ni)
  • 15% – 17% – Molybdenum (Mo)
  • 14.5 – 16.5% – Chromium (Cr)
  • 4% – 7% – Iron (Fe)
  • 3% – 4.5% – Tungsten (W)
  • ≤2.5% – Cobalt (Co)
  • ≤1% – Manganese (Mn)
  • ≤0.35% – Vanadium (V)
  • ≤0.04% – Phosphorus (Ph)
  • ≤0.03% – Sulfur (S)
  • ≤0.010% – Carbon (C)
